Summary of Contents for Hayward Navigator Series
- Page 1 NAVIGATOR ® /POOLVAC SERIES Suction Pool Cleaner Owner’s Manual Hayward Pool Products 620 Division Street, Elizabeth, NJ 07201 908.351.5400 • Hayward.com...
-
Page 2: Safety Warnings
Store the cleaner in a shaded safe area. Hayward Turbine Cleaners are powered by your pool’s filter system and are Hoses must be stored straight. DO NOT coil the hose. designed to work well with most systems. The performance of the Cleaner in your pool will be relative to its power source. -
Page 3: Carton Contents
CARTON CONTENTS PREPARING THE POOL Please complete the following steps to prepare your pool for installation: DEBRIS Remove any large objects and excessive debris from the pool. WATER LEVEL Confirm that water level is at the recommended level. Navigator Pro ®... -
Page 4: Installation
INSTALLATION Sizing Suction Hose Step 2 Pull hose to farthest point of the pool + 2 extra hose sections. Step 1 Connect hose sections. Note: Make sure all connections are tight to prevent air leaks. TIP: Wetting the hose ends will make it easier to connect the hose sections. - Page 5 • Hayward V094 Regulator Valve cone. • An optional Hayward Automatic Skimmer Vacuum Plate* To install the VO94 Regulator Valve: Remove the hose from the V093C Skimmer Cone Close the Regulator Valve by rotating the blue collar clockwise until tight.
- Page 6 Cleaner. The Regulator Valve and Skimmer Vacuum Plate cannot be used to INCREASE the initial vacuum reading. View our YouTube video or contact your authorized Hayward Dealer for assistance. Step 6 Step 8...
-
Page 7: Fine Adjustments
FINE ADJUSTMENTS • Sticking on Steps/Liner/Obstacles Be aware that your Cleaner will climb the vertical walls in concrete and fiberglass pools if there is at least a seven inch (7”) radius Your Cleaner should move about where the walls and floor meet. the pool without spending an Due to the programmed steering, the Cleaner will not climb a wall excessive amount of time against... -
Page 8: Important Tips
A coiled hose will create a memory in the hose that will impede the Cleaner’s ability to move properly. Coiled hoses are not covered under the Hayward Warranty. Use only original Hayward spare parts and hoses to insure proper operation. -
Page 9: Maintenance Tips
Check the condition of the “shoes, wings, and flaps” periodically. Step 1 WEAR MARK GOOD SHOE WORN SHOE Step 2 WEAR LINE Hayward not responsible for damage caused by worn or broken parts. Or damage caused by misuse of the cleaner. - Page 10 MAINTENANCE TIPS Wing Replacement: Step 3 Step 1 Step 4 Step 2...
-
Page 11: Troubleshooting
MAINTENANCE TIPS TROUBLESHOOTING “Easy Opening Bottom”: For Turbine FOR TECHNICAL ASSISTANCE, CALL: 1-800-227-1477 Access and Inspection PROBLEM CAUSE SOLUTION Step 1 Slow or no forward Low or no water pressure. Check filtration and booster movement. pumps, valves, cleaner connections. Check cleaner pressure Cleaner does not reach Hose too short... -
Page 12: Warranty
Purchase Date warranties expressed or implied, including warranties of merchantability or Address E-Mail Address fitness for a particular purpose. In no event shall Hayward Pool products be City State Serial Number responsible for any consequential, special or incidental damages of any nature. - Page 13 Hayward Pool Products 620 Division Street, Elizabeth, NJ 07201 908.351.5400 • Hayward.com ISM0925 rev A...
