IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
2M-Z19604
p/n
Rev. C
10 Sunnen Dr., St. Louis, MO 63143
Model WB2WHNTB
WELLS MANUFACTURING
telephone: 314-678-6314
fax: 314-781-2714
www.wellsbloomfield.com
WB2WHNTB
OWNERS MANUAL
WAFFLE
BAKER
MODELS
Includes
INSTALLATION
USE & CARE
EXPLODED VIEW
PARTS LIST
WIRING DIAGRAM
15
M213
213
1217
