Wells BWB-1S Specifications

W M
E L L S A N U F A C T U R I N G
BWB-1S BELGIAN WAFFLE BAKER

Specifications

Dimensions:

Width
Depth
Height

Pre-Heat Time:

Typical Production:

Waffles

Weights:

Installed
Shipping
Wells BWB-1S Belgian waffle baker is designed
to cook Belgian-style waffles quickly and easily.
Its rotating feature allows the batter to evenly fill
the grids. A self-activating timer assures consistent
BWB-1S
waffle color.
Inches MM
10 1/8 257
14 356
10 5/8 270
20 min.
Per Hour
20
Lbs. KG
167 75
217 98
I T E M N O .

Features

• Elements are cast into the upper and lower
grids to provide superior temperature uniformity.
• A solid-state temperature controller regulates
the elements.
• Grids are seven-inch diameter, one-half inch
deep cast aluminum.
• Stainless steel shell provides maximum
strength and durability.
• Solid-state, self-activating timer with buzzer
indicates end of cooking cycle.
• ON/OFF toggle switch is located on the front
of the unit and is protected by a stainless steel
guard. An indicator light will illuminate when
cooking cycle is on.
• Die-stamped stainless steel drip tray removes
easily for cleaning.
• Handle is nickel-plated steel with an open-coil
design and heat-resistant coating.
• The BWB-1S waffle baker is Underwriters
Laboratories, Inc. LISTED and meets NSF
International standards.
• A one-year warranty against defects covers
parts and labor.

Accessories / Options

Replacement drip tray, 21107
WELLS
