5. Connect the Reed Switch Wire (13) and the Pulse
Wires (55) to the corresponding wires on the Console
(8). If your Console has a ground wire, attach it to the
Upright (2) with the M4 x 16 mm Screw (81).
Next, attach the Console (8) to the Upright (2) with
four #8 x 5/8" Screws (22).
Press the Resistance Knob (9) onto the Resistance
Control (10). Be sure that the mark on the Knob is
correctly aligned.
6. Finish attaching the Handlebar (4) to the Upright (2)
with two additional M6 x 25mm Hex Screws (14)
and M6 Split Washers (67). Tighten all four Hex
Head Screws.
7. Attach the Seat Bracket (69) to the Seat Frame (3)
with four M6 x 48mm Button Bolts (70) and four M6
Flat Washers (34).
8. Attach the Seat (16) to the Seat Bracket (69) with
four M6 x 16mm Phillips Screws (24).
5
8
9
Console
Wires
55
2
13
10
22
22
6
14
67
67
4
14
2
7
70
70
34
34
3
8
16
24
24
6

MAINTENANCE AND STORAGE

Inspect and tighten all parts of the PROFORM
regularly. The 975R can be cleaned with a soft, damp
cloth. To prevent damage to the console, keep liquids
away from the console and keep the console out of
direct sunlight.
TIGHTENING THE PEDALS
For best performance, the pedals must be kept prop-
erly tightened. Regularly tighten both pedals.
BATTERY REPLACEMENT
If the console does not function properly, the batteries
should be replaced. To replace the batteries, refer to
assembly step 12 on page 8.
69
69
® 975R HOW TO STORE THE PROFORM ® 975R
When the PRO-
1
FORM ® 975R is
68
not in use, the
Seat Frame (3)
can be adjusted
to the storage
position. First,
loosen the Lock
Knob (68) on the
right side of the
Frame (1). Slide
the Seat Frame
(3) into the Frame
as far as possible. Tighten the Lock Knob. Store the
PROFORM ® 975R indoors, away from moisture and
dust.
11
3
