WHITEBOARD TOOLS

The Whiteboard feature is only available for monitors with model numbers that contain "LC" or "WB." (You can review
the part number on the back of the monitor.)
Icon Tool Name Description
Previous
Current tool Tap to use the current tool.
Eraser
Color
Wheel
submenu
Color wheel Tap to choose a color using a color ramp. The current selected color appears in
Segmented
color wheel
Size
Opacity
Tools
submenu
Pen
Highlighter
Rectangle
INF6502WB User Guide
Tap to go to the previous page.
Tap Eraser, and then tap and drag across the drawing object to erase the portion
you touched.
Tap to access the color submenu.
the middle of the color wheel.
Tap to choose a color from the segmented color wheel. The current selected color
appears in the middle of the color wheel.
Tap and drag the thumbnail button along the slider path to adjust the size of the
pen/line width.
Tap and drag the thumbnail button along the slider path to adjust the size of the
highlighter/shape opacity.
Tap to select a drawing object.
and pen transparency setting.
NOTE
Tap to use a pen.
Tap to use a highlighter.
Tap to draw a rectangle.
NOTE
: Each object has its own color, pen width,
: Opacity control is not available for the pen object.
Page 23
