InFocus INF6500E Quick Start Manual

HARDWARE SETUP

1) The display should be installed in an upright position.
2) Connect one end of the AC power cord to the AC In jack on the back of the display.
3) Connect the other end of the AC power cord to an AC outlet.
4) Connect a source to the display, if desired.
5) Toggle the power switch to the ON position.
6) Press the Power button. (The LED on the front of the display turns on.)
7) The display shows the connected source image or built-in features, depending on the model. Refer to the display's
user guide on www.infocus.com/support for more information.
Notes:
• Your display should only be operated from the power source indicated on the label.
• Always unplug the AC power cord from the power outlet when you are not using your display for an extended period of
time.

EXTERNAL PC TOUCHSCREEN CONTROL SETUP

1) Connect an external computer to the display using an HDMI or VGA cable.
2) Connect a USB cable from the USB-A jack on the source computer to the display. If you are using a USB-A to USB-A
cable, connect to the USB Touch jack on the front of the display. If you are using a USB-A to USB-B cable, connect to
the USB Touch jack on the back of the display.
3) The computer can now be controlled by using touchscreen gestures on the display.

TURNING THE DISPLAY ON/OFF

1) Verify that the power cord is connected to a power outlet and that the power switch is ON.
2) Press the Power button on the remote or the side of the display.
For more information:
INF6500E
Quick Start Guide
Go to www.infocus.com/support
p/n 009-1651-01
