USER GUIDE
INF6502WB, INF6502LC
INF7002WB, INF7002LC
009-1609-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INF6502WB and is the answer not in the manual?

Questions and answers

Related Manuals for InFocus INF6502WB

Summary of Contents for InFocus INF6502WB

  • Page 1 USER GUIDE INF6502WB, INF6502LC INF7002WB, INF7002LC 009-1609-00...

  • Page 3: Table Of Contents

    CONTENTS Declaration of Conformity ..............................3 Safety Considerations .................................4 安全資訊 ..................................5 What’s Included ..................................7 Setup ....................................8 Mounting ..................................8 Connecting to Other Devices ............................9 Insert LightCast key (INF6502LC/INF7002LC only) ....................12 Connecting AC Power ..............................12 External PC Touchscreen Control Setup ........................12 Turning the Monitor On/Off ...............................12 Using the Remote ................................13 Using the Keypad ................................15 First Time Use ...................................16...
  • Page 4 Reset the registration parameters ..........................37 Resize the image .................................37 Define the default email address ..........................38 Request desktop site ..............................38 Define the default browser home page ........................39 Update a Monitor without LightCast Key ..........................40 OSD (On-Screen Display) Menu System ...........................41 Picture Menu ................................42 Screen Menu ................................43 Audio menu .................................44 PIP menu ..................................45...

  • Page 5: Declaration Of Conformity

    Operation of the equipment in a residential area is likely to cause harmful interference in which case the user will be required to cor - rect the interference at his own expense. Changes or modifications not expressly approved by InFocus Corporation may void author - ity to operate the equipment.

  • Page 7: Safety Considerations

    SAFETY CONSIDERATIONS Please read and follow all safety instructions provided below and on the monitor before connecting the monitor to a power source. Failure to comply with safety instructions may result in fire, electrical shock, or personal injury and may damage or impair protection provided by the equipment.

  • Page 8: 安全資訊

    • Refer all service to qualified service personnel. Do not remove the cover or back. Servicing your own monitor can be dangerous to you and will void the warranty. • Only use replacement parts specified by InFocus. Unauthorized substitutions may result in fire, electrical shock or injury and may void the warranty.
  • Page 9 • 防止踩踏或擠壓電源線，尤其是電源插頭、插座以及在顯示幕上的出入點。 • 如果您長時間不打算使用顯示器，請拔掉顯示器插頭。 • 如果您需要使用附帶的超細纖維清潔布進行清潔，請拔掉顯示器插頭。電源關閉時，可使用清潔布擦拭螢幕。切勿在顯 示器上使用酒精、溶劑或含氨 液體。 • 操作顯示器附帶的線纜後需要洗手。 • 顯示器遙控器利用電池工作。一些型號在發運時還附有採用電池工作的滑鼠和鍵盤。請確保電池極性 (+/-) 正確對齊。按 照當地廢棄物品處理法規處理 廢舊電池。 • 僅使用符合此產品規格的適當耐火等級牆和支架安裝硬體，並遵守製造商的安裝指示。由額定安裝硬體使用不當或安裝 不當造成的任何損壞均不在保 修範圍內。 • 請向專業維修人員諮詢所有維修資訊。請勿卸下封蓋或封底。自行維修顯示器不僅會對您造成傷害，而且也會使保修失 效。 • 僅使用 InFocus 指定的更換零件。未經授權進行更換可能會造成火災、電擊或人身傷害，並可能使保修失效。 • 將顯示器安裝到牆上時，必須使用 8 枚公制（12 毫米）螺絲。此外，安裝介面應符合北美地區的 UL1678 標準。安裝方 法應結實牢固，足以承受顯 示器的重量（參見產品技術規格）。 • 遵守這些指示有助於確保使用壽命內顯示器的圖像品質。不遵守這些指示可能會影響保修。 Page 6...

  • Page 10: What's Included

    Warranty Quick Start Guide Remote control Documentation LightCast key (batteries not included) (INF6502LC/INF7002LC only) For additional accessory options, such as stands, feet, carts and wall mounts, see the InFocus website (www.infocus.com/store) or your local dealer. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 7...

  • Page 11: Setup

    SETUP Mounting This product does not ship with mounting accessories. Only use commercially manufactured mounting accessories which meet this product's specifications and follow the manufacturer installation instructions. • Only use properly rated wall and stand mounting hardware that meet this product’s specifications and follow the manufacturer installation instructions.
  • Page 12 Connect a Type A to Type B USB cable from the monitor to an external CONTROL computer in order to use the touchscreen gestures on the monitor. Connect a wireless mouse, USB thumb drive or other USB device to this USB 1-4 USB Type A 2.0 connector. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 9...
  • Page 13 VIDEO HDMI4 HDMI3 HDMI2 HDMI1 PC IN COMPONENT RJ45 For Lightcast use only. Connect to an Ethernet network. For Lightcast use only. Connect a wireless mouse, USB thumb drive or other USB device to this USB Type A 2.0 connector. For Lightcast use only.

  • Page 14: Insert Lightcast Key (Inf6502Lc/Inf7002Lc Only)

    If your monitor did not ship with a LightCast key and you would like to use the LightCast features, you can purchase a LightCast key (p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www. infocusstore.com) or your local dealer.

  • Page 15: Using The Remote

    • Do not mix new and old batteries or different types of batteries together. • Replace the batteries as soon as they run out. • Remove batteries from the remote control when storing or not in use for a prolonged period. INF6502WB/INF7002WB INF6502LC/INF7002LC (No LightCast key)
  • Page 16 Onscreen Menu features. Info: Displays source information. INFO Vol up: Increases the audio volume. VOL UP Vol down: Decreases the audio volume. VOL DOWN Mute: Switches the audio on or off. MUTE INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 13...

  • Page 17: Using The Keypad

    Freeze: When enabled, freezes the image which is currently displayed. Blank: Toggles between the source and a blank black screen. Dimming: Adjusts brightness level. USING THE KEYPAD The keypad, located on the side of the monitor, has the following buttons: Power button: Switches the power on or puts the monitor into Standby.

  • Page 18: First Time Use

    If your monitor did not ship with a LightCast key and you would like to use the LightCast features, you can purchase a LightCast key (p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www. infocusstore.com) or your local dealer.
  • Page 19 Enter your registration information and tap the arrow to move to the next screen. Enter the Device Name and WiFi Connection information, and tap the arrow. A confirmation page displays. (The LAN information populates when a LAN connection is detected.) Tap the arrow again and the Home page displays.

  • Page 20: Lightcast Casting

    If your monitor did not ship with a LightCast key and you would like to use the LightCast features, you can purchase a LightCast key (p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www. infocusstore.com) or your local dealer.

  • Page 21: Airplay

    AirPlay Airplay sends content over either a wired or wireless network. You must have an Apple device with embedded AirPlay in order to use this AirPlay feature on this monitor. In addition, your network must follow Airplay configuration guidelines as specified by Apple.

  • Page 22: Miracast

    Open the Charms menu on the right side of the Windows PC desktop. Select Devices. Select Project. Select Add a Wireless Device. Select the device name listed in step 5 of the Connect with Miracast window. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 19...

  • Page 23: Whiteboard

    WHITEBOARD Create a drawing object Tap a drawing object from the Tools submenu. Select the color, size, and opacity desired. Draw on the whiteboard canvas with your finger or the stylus. : Keep other objects, including writing utensils, other fingers, and knuckles away from the drawing surface to draw your image cleanly. Use Eraser, Select, Undo, and Redo to modify the drawing.

  • Page 24: Import An Image

    Choose Internal to import an image that has been saved to the monitor or External Storage to import an image that is located on an external device, such as a USB thumb drive. Navigate to the associated folder and tap the desired image. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 21...
  • Page 25 Tap Done. While the object is highlighted, drag it to the desired location and re-size it as needed using the sizing handles. In addition, you can cut, copy, paste, and delete it using the features in the Select submenu. Tap Cancel when finished. Page 22...

  • Page 26: Modify Whiteboard Canvas Objects

    To cut the objects and place them on a different page of the whiteboard canvas: tap Cut. Then navigate to the desired page and tap More and Paste. While the objects are selected, drag them to the desired location. To delete the objects: tap Delete. The objects are deleted immediately. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 23...

  • Page 27: Save The Whiteboard Canvas

    Save the whiteboard canvas Tap More. Tap Save. Type a file name in the Name text box. Select the file type: File Type Option Choose this file type if you want to... DigiEasel saves the whiteboard file for future editing. creates an image file.

  • Page 28: Save The Whiteboard Canvas To A Usb Thumb Drive

    Open a new whiteboard canvas Tap More. Tap New. Then select Save to save the existing canvas or select Don't save to delete the existing canvas and open a new one. Cancel returns the user to the current canvas. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 25...

  • Page 29: Open A Whiteboard File

    Open a whiteboard file Tap More. Tap Open. If the whiteboard canvas contains objects, you will be prompted to save the existing canvas. Select Save to save the existing canvas or select Don't save to delete the existing canvas and open a new one. (Cancel returns the user to the current canvas.) By default, the Open Files window displays Whiteboard files saved internally onto the Whiteboard Device.

  • Page 30: Open A Whiteboard File From A Usb Thumb Drive

    Tap Next to add or go to the next page. Note: Whiteboard supports up to 3 pages total. Tap Previous to add or go to the previous page. Note: Whiteboard supports up to 3 pages total. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 27...

  • Page 31: Whiteboard Tools

    WHITEBOARD TOOLS Icon Tool Name Description Previous Tap to go to the previous page. Current tool Tap to use the current tool. Tap Eraser, and then tap and drag across the drawing object to erase the portion Eraser you touched. Color Tap to access the color submenu.
  • Page 32 Tap to save the file as a JPG image or PDF file. Import Tap to import an image onto the whiteboard canvas. To remove an imported image, tap the red in the top right-hand corner of the image. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 29...
  • Page 33 Copy Tap to copy the selected object(s). Paste Tap to paste the last copied or cut object(s) on the whiteboard canvas. Tap to save or open files from an external USB thumb drive. Setting Tap to access the Setting menu. Next Tap to go to the next page.

  • Page 34: Lightcast Browser

    If your monitor did not ship with a LightCast key and you would like to use the LightCast Browser features, you can purchase a LightCast key (p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www.infocusstore.com) or your local dealer.

  • Page 35: Lightcast Settings

    If your monitor did not ship with a LightCast key and you would like to use the LightCast features, you can purchase a LightCast key (p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www. infocusstore.com) or your local dealer.

  • Page 36: Set Up Bluetooth

    Tap the desired device and follow the onscreen prompts to pair your device to this monitor. Change the monitor name From the Device section of the Settings menu, tap Name. The Name window displays. Type or edit the name, using the onscreen keypad or an attached keyboard. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 33...

  • Page 37: Software Version

    Tap OK. Software version From the Systems and Security section of the Settings menu, tap About LIghtCast to display the current software version. Update the monitor From the Systems and Security section of the Settings menu, tap Firmware Update. Insert a USB thumb drive into the side of the monitor. Tap Select to choose which file to use for the upgrade.

  • Page 38: Reboot The Monitor

    Reboot the monitor From the Systems and Security section of the Settings menu, tap Reboot to reboot this monitor. The monitor reboots immediately. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 35...

  • Page 39: Reset The Registration Parameters

    Reset the registration parameters From the Systems and Security section of the Settings menu, tap Reset to register the monitor with new information. Tap Yes to initiate the registration process. Resize the image From the Systems and Security section of the Settings menu, tap Resize to digitally zoom the Display window smaller or larger, up to 100%.

  • Page 40: Define The Default Email Address

    From the Accounts section of the Settings menu, tap to update the default email address. Tap OK when done. Request desktop site To use a desktop formatted website, tap to select the Request Desktop site check box. Otherwise a mobile web site will be used. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 37...

  • Page 41: Define The Default Browser Home Page

    Define the default browser home page From the Browser Preferences section of the Settings menu, tap to update the default browser home page. Tap OK when done. Page 38...

  • Page 42: Update A Monitor Without Lightcast Key

    Insert a USB thumb drive with the software update on it into an available USB slot or navigate to the network . Follow the prompts to update the software, or tap OK, if the software is already up-to-date. Tap the X in the upper-right corner to close the Settings window. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 39...

  • Page 43: Osd (On-Screen Display) Menu System

    OSD (ON-SCREEN DISPLAY) MENU SYSTEM The OSD provides the user the ability to control the monitor display. To access the OSD, press the Menu button on the remote or the keypad located on the right-hand side of the monitor. Use the up and down arrows on the remote or keypad to scroll through the menu options and press OK to enter the highlighted menu.

  • Page 44: Picture Menu

    User to access this feature. Range: 0-100 for each color. Picture Mode: provides different preset picture modes to choose from. Options include: Standard (default), HighBright, and Soft. Picture Reset: resets all Picture menu items to factory default settings. Options: Yes and No. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 41...

  • Page 45: Screen Menu

    Screen Menu SCREEN H POSITION V POSITION CLOCK CLOCK PHASE BLANK DIMMING ASPECT RATIO WIDE SCREEN RESET < > Adjust Enter Back Quit H Position: adjusts the horizontal position of the image. Range: 0-100. (Default 50.) V Position: adjusts the vertical position of the image. Range: 0-100. (Default 50.) Clock: adjusts the width of the image (For VGA input only).

  • Page 46: Audio Menu

    Audio Source: selects the audio input source. Options include: HDMI 1, HDMI 2, HDMI 3, HDMI 4, Lightcast, Audio 1, and Audio 2. Audio Reset: resets all Audio menu items to factory default settings. Options: Yes and No. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 43...

  • Page 47: Pip Menu

    PIP menu PIP MODE PIP INPUT PIP POSITION TOP-RIGHT PIP SWAP PIP SIZE SMALL PIP AUDIO MAIN PIP RESET < > Adjust Enter Back Quit PIP Mode: enables or disables Picture-in-Picture mode. Options include: Yes and No. PiP Input: selects the source input for the PiP window. Options include: VGA, component, video, HDMI1, HDMI2, HDMI3, HDMI4, LightCast.

  • Page 48: Configuration 1

    Options: Auto (default), Lightcast, and External. Configuration Reset: resets all Configuration 1 and Configuration 2 menu items to factory default settings. Options: Yes and No. Factory Reset: resets all menu items to factory default settings. Options: Yes and No. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 45...

  • Page 49: Configuration 2

    Configuration 2 CONFIGURATION 2 OSD TURN OFF FREEZE OSD H POSITION OSD V POSITION OSD ROTATION PORTRAIT MONITOR INFORMATION < > Adjust Enter Back Quit OSD Turn Off: controls how many seconds the OSD menu remains on the screen Range: 5-120 (seconds). (Default: 10) Freeze: When enabled, freezes the image which is currently displayed.

  • Page 50: Advanced Option

    Unlock (default; keypad is enabled). DDC/CI: enables and disables DDC/CI communication. Options include: On (default) and Off. Advanced Option Reset: resets all Advanced Option menu items to factory default settings. Options: Yes and No. INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 47...

  • Page 51: Troubleshooting

    TROUBLESHOOTING SYMPTOM POSSIBLE SOLUTIONS No power • Verify the power cord is properly connected to the power outlet and to the monitor. • Verify the power switch is ON and that the Power button on the remote or keypad has been turned on (the front LED should be on). • Plug another electrical device to the power outlet to verify that the outlet is supplying the proper voltage.
  • Page 52 • The monitor is in standby mode. Press the Power button on the remote or keypad. Green • The monitor is powered on. Orange • The source signal is out of range. For additional troubleshooting support, please contact: InFocus Corporation - Technical Support 6am-5pm PST 877-388-8385 www.infocus.com/support INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 49...

  • Page 53: Limited Warranty

    If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, InFocus will either (1) repair the hardware defect at no charge, using new parts or refurbished...
  • Page 54 (l) if the product is not used under normal operating conditions which are defined as use not in excess of 16 hours continuously per day with a minimum 8 hour period of continuous rest in the powered off state; or (m) if any InFocus serial number has been removed or defaced.
  • Page 55 InFocus will provide it. You must assist in diagnosing issues with your product and follow InFocus’s warranty processes. InFocus may restrict service to the country where InFocus or its Authorized Distributors originally sold the hardware product. InFocus will provide warranty service either (i) at an ASP location, where service is performed at the Page 52...
  • Page 56 If during the diagnosis period, InFocus identifies that the repair can be accomplished by the use of a CSR part, InFocus will ship that part directly to you for replacement. There are two categories of CSR parts: • Parts for which customer self repair is mandatory. ...
  • Page 57 InFocus Corporation, 13190 SW 68th Parkway, Suite 200, Portland, OR 97223-8368 USA © 2015 InFocus Corp. All rights reserved. InFocus and the InFocus logo are trademarks of InFocus Corp., registered in the U.S. and other countries.

  • Page 58: 安全注意事項

    不應將明火火源如點燃的蠟燭等放在顯示器上。 • 使用所提供的電源線。將電源線連接到有安全保護（接地）接地端子的插座上。建議使用電湧保護電源排插。 • 建議將第 1 級顯示器接地。 • 不要將顯示器安裝在承受機械振動的地方。 • 不要將顯示器安置在不穩定的表面上，否則可能導致嚴重的人身傷害和顯示器損壞。將顯示器安裝到支架上時，一定要 遵守製造商的說明。僅使用制 造商推薦的安裝硬體。 • 在斷開電源線時，請握住插頭而非電線。 • 保護電源線使其免於踩踏或擠壓，尤其是插頭、電源插座處以及它們從顯示器退出的部位。 • 如果您不打算較長時間使用顯示器，則應拔下顯示器的電源線。 • 在需要使用附帶的超細纖維清潔布清潔顯示器時，應拔下顯示器的電源線。螢幕的擦拭工作應當在電源關閉時使用清潔 布進行。切勿在顯示器上使用 酒精、溶劑或腐蝕性的液體。 • 處理此顯示器隨附的線纜後請洗手。 • 顯示器遙控器使用電池。確保電池的極性（+/-）正確對齊。根據當地處理法規處理廢舊電池。 • 只使用符合本產品規格的適當規格的牆面和支架安裝硬體，並遵照製造商的安裝說明。保修範圍不包括因使用不當規格 安裝硬體或安裝不當而造成的 任何損壞。 • 應向合格的維修人員諮詢所有服務資訊。不要取下蓋子或背板。自行維修顯示器是危險的做法，將導致保修失效。 • 只使用富可視公司指定的更換零部件。未經認可的代用品可能會導致火災、觸電或人身傷害，並可能導致保修失效。 INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 55...
  • Page 59 • 在將顯示器安裝到牆上時，必須使用 M8 (12 毫米) 規格的螺栓。此外，安裝介面應符合北美 UL1678 標準。安裝方 式應牢固到足以承受顯示器的重量。 • 請遵照以下說明，以確保顯示器使用壽命期間的圖像品質。不遵守這些說明可能會影響保修。 Page 56...

  • Page 60: Jtouch 65"顯示器I/O Port 介紹前/後面板

    JTouch 65”顯示器I/O port 介紹前/後面板 TOUCH CONTROL RS232 IN 1 Audio IN 2 Audio OUT VIDEO HDMI4 HDMI3 HDMI2 HDMI1 PC IN COMPONENT TOUCH TOUCH CONTROL CONTROL 將USB纜線從顯示器連接至外部電腦，以便使用觸控模組。 直接存取USB磁碟機上的多媒體檔案。 INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 57...
  • Page 61 HDMI4 HDMI3 HDMI2 HDMI1 VIDEO PC IN COMPONENT VIDEO 接受來自外部裝置（例如VCR或DVD播放器）的VIDEO信號。 HDMI4 接收外部裝置的HDMI信號。 HDMI3 接收外部裝置的HDMI信號。 HDMI2 接收外部裝置的HDMI信號。 HDMI1 接收外部裝置的HDMI信號。 PC IN 接收來自外部裝置（例如電腦）的類比RGB訊號。 COMPONENT 接收來自外部裝置（例如DVD播放器,HDTV裝置或雷射光碟播放器）的色 差視訊(YPbpr)訊號。 RS232 連接外部數據機。 連接至麥克風。 RS232 AUDIO IN1 接收來自外部裝置（例如iPod播放器）所發出的音頻訊號。 AUDIO IN2 IN 1 接收來自外部裝置（例如DVD播放器）所發出的音頻訊號。 Audio AUDIO OUT IN 2 連接到外接式立體聲喇叭。...
  • Page 62 開啟或關閉顯示器。 選取/確認屏幕顯示(OSD) 功能表中的選項。 在OSD 功能表中向上捲動瀏覽各個設定和選項。 在OSD 功能表中向下捲動瀏覽各個設定和選項。 在OSD 功能表中向左捲動瀏覽各個設定和選項。 在OSD 功能表中向右捲動瀏覽各個設定和選項。 開啟或關閉OSD 功能表。 INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 59...
  • Page 63 Page 60...
  • Page 64 INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide Page 61...
  • Page 65 Page 62...
