Toshiba GRE110 Instruction Manual page 292

INF Description
Fault Indications
64 Start/pick-up L1
65 Start/pick-up L2
66 Start/pick-up L3
67 Start/pick-up N
68 General trip
69 Trip L1
70 Trip L2
71 Trip L3
72 Trip I>>(back-up)
73 Fault location X In ohms
74 Fault forward/line
75 Fault reverse/Busbar
Teleprotection Signal
76
transmitted
77 Teleprotection Signal received
78 Zone1
79 Zone2
80 Zone3
81 Zone4
82 Zone5
83 Zone6
84 General Start/Pick-up
85 Breaker Failure
86 Trip measuring system L1
87 Trip measuring system L2
88 Trip measuring system L3
89 Trip measuring system E
90 Trip I>
91 Trip I>>
92 Trip IN>
93 Trip IN>>
Autoreclose indications
128 CB 'ON' by Autoreclose
CB 'ON' by long-time
129
Autoreclose
130 Autoreclose Blocked
Note (*1): Not available if the setting is "0".
(∗2): Not available when neither the EF nor SEF element is used.
Contents
A phase, A-B phase or C-A phase element pick-up
B phase, A-B phase or B-C phase element pick-up
C phase, B-C phase or C-A phase element pick-up
Earth fault element pick-up
BO status specified by IECGT: ON (*1)
BO status specified by IECAT: ON (*1)
BO status specified by IECBT: ON (*1)
BO status specified by IECCT: ON (*1)
Back up trip
Fault location (prim. [ohm] / second. [ohm] / km selectable by
IECFL)
Forward fault
Reverse fault
Carrier signal sending
Carrier signal receiving
Zone 1 trip
Zone 2 trip
Zone 3 trip
Zone 4 trip
Zone 5 trip
Zone 6 trip
Any elements pick-up
CBF trip or CBF retrip
Inverse time OC trip (OC1 trip)
Definite time OC trip (OR logic of OC1 to OC3 trip)
Inverse time earth fault OC trip (OR logic of EF1 and SEF1 trip)
Definite time earth fault OC trip (OR logic of EF1 to EF3 and
SEF1 to SEF3 trip)
CB close command output
Autoreclose block
 293 
6 F 2 T 0 1 7 2
Typ
COT FUN
GI
e ID
GI 2 1, 7, 9 160
GI 2 1, 7, 9 160
GI 2 1, 7, 9 160
GI 2 1, 7, 9 160
-- 2 1, 7 160
-- 2 1, 7 160
-- 2 1, 7 160
-- 2 1, 7 160
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
GI 2 1, 7, 9 160
-- 2 1, 7 160
Not supported
Not supported
Not supported
Not supported
-- 2 1, 7 160
-- 2 1, 7 160
-- 2 1, 7 160
-- 2 1, 7 160
-- 1 1, 7 160
Not supported
GI 1 1, 7, 9 160
