Apollo XP95 Installation & Maintenance Manual

Technical Data
Supply voltage
Quiescent current
Alarm current
Switch-on surge current
Power-up time
Remote LED voltage
Remote LED current
Fire alarm threshold
Operating range
Field of view/angle of reception
Operating temperature
Storage temperature
Relative humidity
IP rating
Housing material
Size and weight
Cable gland entries
Approval and Regulatory Information
14
0832 010an/13 CD0006/FLAME
010an/14
Additional Equipment
Flame detector weathershield, part no 29600-206
Flame detector weathershield for fl ameproof version, part no 29600-228
Flame sensor test unit, part no 29600-226
Flame detector bracket, part no 29600-203
© Apollo Fire Detectors Limited 2014
36 Brookside Road, Havant, Hants, PO9 1JR, UK
Tel +44 (0) 23 9249 2412 Fax +44 (0) 23 9249 2754
www.apollo-fi re.co.uk
14–28V DC
2.2mA
4.2mA
30mA (peak) for 15mS
4 seconds
0–28V DC
limited to 2mA
Analogue value 55 returned after 10Hz fl ame
fl icker for 1.5 seconds
25m for 0.1m² n-heptane fi re
35m for 0.2m² n-heptane fi re
45m for 0.4m² n-heptane fi re
90° Cone
–10°C to +55°C
–20°C to +65°C
95% (no condensation)
65
Die cast zinc alloy (ZA 12)
142 x 108 x 82mm, 2 kg
2 x 20mm
EN54-10 Flame Detectors - Point Detectors
8
PP2271/Issue 3
Installation & Maintenance Guide
General
The XP95 Triple Infra-red (IR) Flame Detectors, part no 55000-020 and 55000-021 are
designed for use where open fl aming fi res may be expected. They are sensitive to low-
frequency, fl ickering infra-red radiation emitted by fl ames during combustion. False alarms
due to such factors as fl ickering sunlight are avoided by a combination of fi lters and signal
processing techniques.
Response to Flames
In quiescent condition, ie, in the absence of a fl ame, the detector returns an analogue
value of 25. When a fl ame is visible, the detector signals an alarm by increasing the ana-
logue value returned to 55, usually within 1.5 seconds. The analogue value may continue to
rise until it reaches a pre-set maximum of 64.
In the alarm state the XP95 Flame Detector latches for 20 seconds, with the analogue value
decreasing to 25 once the fl ame is no longer detected.
Electrical Considerations
The XP95 IR Flame Detector is loop powered and needs no external supply. It is connected
to a control panel using either the XP95 or Discovery protocol. A remote LED alarm indicator
may be connected to the fl ame detector.
Sensor Window Contamination
It is important to keep the sensor window clean and checks should be carried out at
regular intervals–determined locally according to the type and degree of contamination
encountered–to ensure optimal performance of the fl ame detector. Although fl ames can
be detected when the window is contaminated, there may be a reduction of sensitivity as
shown in the table overleaf.
It is recommended that the fl ame detector is disabled when the window is being cleaned.
XP95 Triple IR Flame Detector
