- Page 1 Part No. 902400 Model IM250A Li CORDLESS 16 GAUGE ANGLED LITHIUM-ION FINISH NAILER OPERATING MANUAL IMPORTANT! DO NOT DESTROY It is the customer's responsibility to have all operators and service personnel read and understand this manual.
- Page 2 Cordless Finish Nailer, it is your responsibility to make sure that they also read and comply This manual is intended to acquaint you with the Paslode with the instructions in this manual before attempting to Cordless 16 ga.
-
Page 3: Specifications
The Handle Assembly contains the fuel cartridge, indicator By using the Paslode Cordless 16 ga. Angled Lithium-ion light, and the trigger. Finish Nailer at its recommended cycle rate, you will be able to drive several thousand nails in a typical workday. -
Page 4: Safety Instructions
The following safety instructions have been included in this booklet to provide you with basic information neces- WARNING sary for safe operation of the Paslode Cordless 16 ga. Angled Lithium-ion Finish Nailer. Do not expose the tool to DO NOT ATTEMPT TO OPERATE THIS TOOL UNTIL... - Page 5 Paslode Cordless 16 ga. Angled Lithium-ion Finish NEVER operate the tool if the work contacting element Nailer.
- Page 6 INSTRUCTIONS! IMPORTANT SAFETY INSTRUCTIONS! SAVE THESE INSTRUCTIONS! Battery Disposal: The Paslode batteries contain lithium and should be DANGER recycled or disposed of properly. It is illegal in some areas to place a lithium battery into the trash or solid TO REDUCE THE RISK OF FIRE OR waste stream.
-
Page 7: Battery And Charging System
This charging system is stable surface. A green light will come on to indicate the only one that will work with the Paslode the power is on and the charger circuit is ready. lithium-ion batteries. The first step in preparing a new tool for operation is to fully charge the battery. -
Page 8: Inserting Battery
Battery and Charging System Battery Indicator Light On the right side of the handle is a small plastic lens. This is the battery indicator light. When you insert a fully-charged battery into the tool, you will see a blinking green light. If the indicator light blinks red, recharge the battery. -
Page 9: Fuel Cartridge
NOTE: Altitude Restriction WARNING Paslode Cordless technology is powered by an internal combustion engine and are effected by altitude. The Sunlight can raise the inside temperature of an tool may lose power or become erratic at elevations of unventilated car or van to above 140°F (60°C). - Page 10 Paslode Cordless Fuel Cell/Cartridge Disposal Guidelines Paslode the industry leader in cordless technology provides this information to assist users with the proper disposal of discarded fuel cells/cartridges. Acceptable disposal options vary depending on the type of fuel cell/cartridge users. All users must consider federal, state and local solid waste regulations to ensure that discarded fuel cells/cartridges are disposed of properly.
- Page 11 Fuel Ca rtridge Inserting Fuel Cartridge A. When loading a fuel cartridge, lift the tool off of the work C. Release the adaptor so it is centered on the fuel surface so the work contact element (WCE) is not depres- cartridge.
- Page 12 ✕ Loading Fasteners STEP 1: Align the heads of the Paslode 16 ga. Angled Finish nails to the silver brad channel in the rear of the magazine s l i STEP 2: Next, while applying pressure to the release lever, pull the follower toward the rear of the magazine until the follower passes the last strip of fasteners.
- Page 13 The Cordless Finish Nailer should not be used unconsciousness. in the rain or where excessive moisture is present. The use of the Paslode Cordless Technology under ® these conditions may result in damage to tool components and cause the tool to malfunction.
-
Page 14: Fasteners And Applications
The Paslode Cordless 16 ga. Angled Finish Nailer drives Paslode 16 Gauge Angled Finish Nails. Fasteners are collated into strips of 50 for easy loading. Paslode fasteners are designed to be used in Paslode tools, use of other fasteners may cause damage to the tool or injury to the tool operator. -
Page 15: Battery Check
If you have An occasional problem you may encounter is a jammed any reason to believe that your problem is beyond the service procedures in this manual, contact your Paslode ® Finish Nailer, clearing a jammed fastener is easy: representative immediately. -
Page 16: Air Filter
Battery - Part No. 902650 Tool Cleaner - P a r t No . 219348 Clear Safety Glasses - Part No. 401382 Paslode Cordless Lubricating Oil - Part No. 401482 Battery Charger - Part No. 902672 Paslode Cordless Finish Nailer Case - Part No. -
Page 17: Troubleshooting
Spark wire out of spark plug. Remove cap and check spark lead, insert in spark plug and replace cover. Spark plug is dirty. Clean tool cylinder head. No spark is generated. Return tool to authorized Paslode ® dealer for service. - Page 18 ® specifications. Check Fasteners and Ap- Tool operates, but no fastener is driven. plications section for fastener types and sizes recommended for use in Paslode Cordless tool. Follower not properly engaged behind fastener Position follower behind fastener strip and strip.
