- Page 1 FlexPoint Series UPS Technical Manual FlexPoint 1208-F / 1232-D / 1250-D Series Indoor UPS Effective: September, 2015...
-
Page 2: Safety Notes
Safety Notes Review the drawings and illustrations contained in this manual before proceeding. If there are any questions regarding the safe installation or operation of the system, contact Alpha Technologies or the nearest Alpha representative. Save this document for future reference. -
Page 3: Contact Information
Alpha representative. Alpha shall not be held liable for any damage or injury involving its enclosures, power supplies, generators, batteries or other hardware if used or operated in any manner or subject to any condition not consistent with its intended purpose or is installed or operated in an unapproved manner or improperly maintained. -
Page 4: Table Of Contents
Table of Contents FlexPoint safety and compliance notes ......................5 Battery safety guidelines ............................ 5 Introduction ............................6 List of terms ..........................6 Theory of operation ........................6 System features ........................7 Options ............................. 8 FlexPoint 1208-F / 1232-D / 1250-D inventory ................ 8 FlexPoint dimensions ....................... -
Page 5: Flexpoint Safety And Compliance Notes
FlexPoint safety and compliance notes Review the drawings and illustrations contained in this manual before proceeding. If there are any questions regarding the safe installation or operation of the system, contact Alpha Technologies or the nearest Alpha representative. Save this document for future reference. -
Page 6: Introduction
1.0 Introduction List of terms Terms used in this document: FlexPoint Terminology End of Discharge Federal Communications Commission Dual output FlexPoint Series Indoor 32W/50W UPS with 7-position FP1232-D / 1250-D connector and F-type coaxial connector FP1208-F FlexPoint Series Indoor RFoG power supply FTTH/FTTx Fiber To The Home/House/etc. -
Page 7: System Features
Introduction, continued System features • The FP1232-D and FP 1250-D units are robust power systems which can provide either 32W or 50W (respectively) of 12Vdc primary and standby power for FTTx and RFoG activity. The FP1208-F provides 8W of 12Vdc standby power for RFoG applications. •... -
Page 8: Options
Review the drawings and illustrations contained in this guide before proceeding. For additional details on installation and operation, visit www.alpha.com and download a copy of the FlexPoint 1215, 1232, 1250 Series Technical Manual (p/n 010-353-B0). The FlexPoint 1215, 1232 and 1250 units are optical network terminal (ONT) providing of 12Vdc primary and standby power. -
Page 9: Flexpoint Dimensions
Introduction, continued FlexPoint dimensions 2.83" [71.8 mm] 4.29" 6.57" [108.9 mm] [166.9 mm] 2.52" [64.0 mm] 4.23" 3.19" 3.23" [107.4 mm] [81.0 mm] [82.0 mm] 7.48" [190.0 mm] (Cover removed for clarity) Fig. 1-5, FlexPoint dimensions (in/[mm]) 010-353-B9-001 Rev. A1 (09/2015) -
Page 10: Installation
2.0 Installation Installation and connection CAUTION! Note the polarity of the wiring harness. Improperly connecting these wires can cause faulty operation and void the warranty. The power supply cord is used as the main disconnect device. Verify that the equipment is installed near the AC receptacle and that the cord is easily accessible. -
Page 11: Fig. 2-2 Flexpoint Connections And Components
Installation, continued Installation and connection, continued D. Determine the necessary cable length to provide appropriate service loops between the unit, the ONT, and the AC receptacle. Plug the line cord into the receptacle (1) in the unit. Secure line cord at one of the cable tie holes (2) with one included cable tie. DO NOT plug the unit into an AC receptacle until the last step of the installation procedure. -
Page 12: Installing The Battery
Installation, continued Installing the battery NOTICE: • Battery installation is similar for the FP1208-F, FP1232-D and FP1250-D. • The unit will not start from batteries unless the DC Start button is pushed. 1. Remove the battery cover, see Fig. 2-4. 2. -
Page 13: Operation
3.0 Operation Power on 1. Plug the unit into AC power (if no AC power is present and if the battery is installed, press DC start button for 2 seconds to run the unit using battery power). 2. The AC present LED (Green) should light. Additional LEDs on the front panel of the FlexPoint indicate the state of the system (see Fig. -
Page 14: Audible Alarms And Visual Indicators
ON button is pressed. Table 3-1, Audible Alarms and Visual Indicators Battery Battery construction varies significantly between manufacturers. Alpha Technologies recommends the use of Alpha batteries or qualified batteries only. Battery Options Part Description AX-STDBAT-5 Battery 5.1Ah AGM, 1-year Warranty AX-STDBAT-7 Battery 7.2Ah AGM, 1-year Warranty... -
Page 15: Operational Modes
Operation, continued Operational modes 3.4.1 Normal mode This mode is defined as a state where the load is being supplied from AC input, and the battery is floating, charging or in the process of being tested. When the unit is initially powered up, or whenever the input supply has been restored after an outage, the unit operates in charge mode. -
Page 16: Specifications
4.0 Specifications 4.1 FlexPoint 1208-F specifications Models Power Line Cords FP1208-F-5A: 120Vac 3-Conductor NEMA 5-15 power cord (875-698-19) FP1208-F-5B: 240Vac 3-Conductor Schuko input power cord (876-042-19) FP1208-F-5C: 240Vac 3-Conductor United Kingdom input power cord (876-046-19) FP1208-F-5D: 240Vac 3-Conductor Australia/New Zealand input power cord (876-043-19) -
Page 17: Flexpoint 1232-D Specifications
4.0 Specifications, continued 4.2 Flexpoint 1232-D specifications Models Power Line Cords (Alpha p/n) FP1232-D-8A: 120Vac 3-Conductor NEMA 5-15 power cord (875-698-19) FP1232-D-8B: 230Vac 3-Conductor Schuko input power cord (876-042-19) FP1232-D-8C: 230Vac 3-Conductor United Kingdom input power cord (876-046-19) FP1232-D-8D: 240Vac 3-Conductor Australia/New Zealand input power cord (876-043-19) -
Page 18: Flexpoint 1250-D Specifications
4.0 Specifications 4.3 Flexpoint 1250-D specifications Models Power Line Cords FP1250-D-8A: 120Vac 3-Conductor NEMA 5-15 power cord (875-698-19) FP1250-D-8B: 230Vac 3-Conductor Schuko input power cord (876-042-19) FP1250-D-8C: 230Vac 3-Conductor United Kingdom input power cord (876-046-19) FP1250-D-8D: 240Vac 3-Conductor Australia/New Zealand input power cord (876-043-19) FP1250-D-8E: 250Vac 3-Conductor Brazilian 14136 input power cord (876-044-19) FP1250-D-8-6C:... - Page 20 Fax: +55 11 2476 0150 Visit us at www.alpha.com Due to continuing product development, Alpha Technologies reserves the right to change specifications without notice. Copyright © 2015 Alpha Technologies. All Rights Reserved. Alpha® is a registered trademark of Alpha Technologies. 010-353-B9-001 Rev. A1 (09/2015)
