Alpha XM3 Quick Start Manual

High efficiency cableups

Advertisement

CableUPS
Quick Start Guide
®
11
10
9
Battery Connector
1
2
Battery Breaker
Precision Temperature Sensor
3
(PTS) Connector
4
LRI Connector
5
Smart Display
WARNING!
Verify battery voltage, cable color, connection and polarity are correct before proceeding.
Total Power Solutions
6
DOCSIS Transponder Battery Sense
Harness Connector
7
RF Connector
8
Tamper Switch Connector
9
Output 1 (Primary) / Output 2 (AlphaDOC)
10
APPs Card
11
Smart AlphaGuard Connector
8
5
7
4
3
2
6
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XM3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Alpha XM3

  • Page 1 CableUPS Quick Start Guide ® Battery Connector DOCSIS Transponder Battery Sense Harness Connector Battery Breaker RF Connector Precision Temperature Sensor Tamper Switch Connector (PTS) Connector Output 1 (Primary) / Output 2 (AlphaDOC) LRI Connector APPs Card Smart Display Smart AlphaGuard Connector WARNING! Verify battery voltage, cable color, connection and polarity are correct before proceeding.
  • Page 2 (3 battery strings) — use p/n 875-910-22, (4 battery strings) — use p/n 875-910-23. NOTE: The compatibility of the XM3 SAG system with certain vaults is dictated by the length of the SAG harness. Contact your local sales representative for more information. Threaded Insert Terminals CAUTION! Use 1/4-20 x 3/4”...
  • Page 3: Front Panel Connections

    Front Panel Connections 1. Connect the Battery Sense Harness to the A/B or C/D Connector (6). For XM3 units with the Smart AlphaGuard (SAG) option, connect the Battery Harness to the SAG Connector (11) located on the left side of the XM3 Power Supply.
  • Page 4: Power Module Configuration

    Battery MHOs measurements. ENTR to save 18. Switch SPI / ALT Box Switch to ON, verifying the load on the XM3. ENTR 19. Perform a self-test by pressing and holding the Test Button (H) for 1-2 seconds.
  • Page 5 Verify Alpha DOCSIS Transponder communication parameters such as IP Address, RF Power Levels and Signal/ Noise Ratio on the COMM menu of the XM3 Smart Display. Press Enter <ENTR> to open the COMM-GENERAL Menu enabling the operator to view values for the following parameters. Pressing the up or down arrow softkeys will show two lines of information for each submenu item.
  • Page 6: Final Verification

    6.0 Final Verification Local Web Server Access The ethernet port of the Alpha DOCSIS Transponder can be used as a local connection point, allowing the user to connect to the transponder web page. To access the web page, proceed as outlined below: NOTE: A Static IP address (192.168.100.2) may need to be set on your network interface card to connect to the...

This manual is also suitable for:

Xm3-918hp
