Battery protection system

There is a protection system for the battery
that prevents the compressor from operating if
the available voltage becomes too low. Battery
protection level is set up for working under
normal circumstances in most appliances. Cut-
out and cut-in values are:
12V system: cut-out = 10.0V; cut-in = 11.5V
24V system: cut-out = 22.0V; cut-in = 24.5V
42V system: cut-out = 36.0V; cut-in = 38.5 V
Other values can be set up if a FDC programming
kit is available.
