ACTi ACD-2400 Quick Installation Manual

16-channel mpeg-4 1u video encoder
Hide thumbs Also See for ACD-2400:

Advertisement

Quick Links

Download this manual See also: User Manual
16-channel MPEG-4 1U Video Encoder
ACD-2400
Quick Installation Guide
Ver.080331

Advertisement

loading
Need help?

Need help?

Do you have a question about the ACD-2400 and is the answer not in the manual?

Questions and answers

Related Manuals for ACTi ACD-2400

Summary of Contents for ACTi ACD-2400

  • Page 1 16-channel MPEG-4 1U Video Encoder ACD-2400 Quick Installation Guide Ver.080331...

  • Page 3: Getting Started

    Getting Started PACKAGE CONTENTS ACD-2400 Warranty Card Software CD Terminal Blocks Power Cord Bracket...

  • Page 4: Physical Description

    1.2 PHYSICAL DESCRIPTION Channel Number Action LED Indicator The LED will light up after this video channel has successfully completed the boot process. LAN LED Indicator The LEDs indicating when this video channel is transmitting data. Serial Port LED Indicator LEDs indicating when serial port is active.
  • Page 5 AC Power Input 100-240V AC 50/60Hz Power Input. Power Switch 16-channel MPEG-4 1U Video Encoder power switch. 10. Terminal Blocks The 16-channel MPEG-4 1U Video Encoder supports two alarm input and two alarm output. DI: Logic Level 0: 0~0.4V; Logic Level 1: 3.3~30V DO: Logic Level 0: 0.1~0.6V;...
  • Page 6 AUDIO GND Audio Ground Pin AUDIO OUT Audio Output AUDIO GND Audio Ground Pin AUDIO IN Audio Input * RS-232 mode requires user to set the jumpers inside the 16-channel MPEG-4 1U Video Encoder. Bcause opening the 16-channel MPEG-4 1U Video Encoder will void the warranty, please contact your distributor for how to switch to RS-232 mode.

  • Page 7: Quick Tour

    Quick Tour This section guides you with a quick tour on 16-channel MPEG-4 1U Video Encoder. 2.1 Configure the 16-channel MPEG-4 1U Video Encoder 2.1.1 Make sure network environment Default IP of 16-channel MPEG-4 1U Video Encoder is 192.168.0.100. Please make sure 16-channel MPEG-4 1U Video Encoder and your PC are on the same network segment before running the installation.
  • Page 8 2.1.2 Open Internet Explorer with IP address  STEP1: Open a browser  STEP2: Enter the IP address of the IP device. The default IP address is “192.168.0.100” The “Login Page” is now displayed as below.  STEP3: Enter the Account name (factory default: Admin) and the Password (factory default: 123456).
  • Page 9  STEP1: Click to set system configurations of 4-CH 16-channel MPEG-4 1U Video Encoder  STEP2: Click to apply the choice...
  • Page 11 2.1.3 Set New IP Click the [WAN Setting] on the “Main Setup page”. The “WAN setting page” is displayed as below. *IP Address : The IP address of the LAN interface. The default IP address is 192.168.0.100. *Subnet Mask : The subnet mask of the LAN interface.The default subnet mask is 255.255.255.0 *Click button...
  • Page 12 NOTE: Check with your MIS department, if Client PC and IP rugged dome are setting in different VLANs, please connect to WAN port. NOTE: In your Client PC, please make sure the setting of Network Connections Type is set to Auto Negotation, since IP rugged dome follows MII standard.
  • Page 13 2.1.4 Save Reboot  STEP1: Click the [Save and reboot] on the “Main Setup page”. The “Save and reboot page” is displayed as below.  STEP2: The Action LED indicator will light down to indicate that the IP device is rebooting. After around 30 seconds, the Action LED will light up again to indicate that the reboot is completed.
  • Page 15 2.1.5 Configuring the IP device – Channel This section describes how to configure the system part of IP device.  STEP1: Click to set configurations of every single channel of 4-CH 16-channel MPEG-4 1U Video Encoder  STEP2: Click to apply the choice...
  • Page 17 2.1.6 Preview the video STEP1: Click the [Video Display] on the “Main Setup page”.  The “Video Display page” is displayed as below.  STEP2: Check the [Mute] checkbox to select mute enable/disable  STEP3: Click the [Audio Out] checkbox to enable/disable audio output from control PC to IP device.
  • Page 19 2.1.7 Check Default Video Setting STEP1: Click the [Video Setting] on the “Main Setup page”.  The “Video setting page” is displayed as below.  STEP2: Clieck to enter the configuration table...
  • Page 20 Click the [Apply] button of each setting to confirm the settings or click the [Reset] button to re-enter the parameters. NOTE: Please make sure the TV Input (NTSC / PAL) is meet your requirement, and click button.
