ACTi V2 Series Quick Installation Manual

Device Overview

V21 / V22
4 5 6 7 8 9
1
2
3
10 11 12
1 Power LED 7 Reset Button
Serial Port Activity LED DC 12V Power Connector
2 8
Video In Activity LED Ethernet Port
3 9
Digital Input / Output
Memory Card Slot
4 10
Connector
Audio Input / Output
5 11 Video Out Connector
Connector
6 Serial Port Connector 12 Video In Connector
V23 / V24
3 4 5 6 7 8
1
2
9 10
1 Power LED 6 Reset Button
Serial Port Activity LED DC 12V Power Connector
2 7
Digital Input / Output
Ethernet Port
3 8
Connector
Audio Input / Output
Memory Card Slot
4 9
Connector
Serial Port Connector Video In Connectors (1~4)
5 10

Introduction

This guide contains all the information you need to quickly setup
the Video Encoder. For detailed information on installations or
operations, please refer to the Hardware Manual and Firmware
Manual on ACTi website (www.acti.com).

Step 1: Unpack the Device

Check if the package comes with the following items:
Video Encoder Mounting Screw Terminal Blocks
Pack
• Power
• Audio
• Digital Input/Output
• Serial Communication

Step 2: Mount the Device

The device can be directly mounted on a surface, such as walls.
Attach the 4 supplied screws
to secure the device.

Step 3: Connect the Device

V21 / V22 Basic Connection Example
Analog Camera
Power Source
(optional)
PC
PoE Switch
V23 / V24 Basic Connection Example
Analog Camera 1
Power Source
(optional)
Analog Camera 2
PC
Analog Camera 3
PoE Switch
Analog Camera 4
Monitor
