- Page 1 SC SERIES OWNER’S MANUAL SC 2000i SC 3000i SC 3000i SC 4000i SC 6000i SC 8000i The Coolest Thing In Wine Storage...
- Page 2 WhisperKOOL. Every effort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for printing or clerical errors.
-
Page 3: Table Of Contents
SC Series TABLE OF CONTENTS Quick Reference Guide ............2 Controller Layout . -
Page 4: Quick Reference Guide
QUICK REFERENCE GUIDE Front / Side View Controller Probe Input Control Panel (see page 10 for details) Bottle Probe Rear / Side View Rear Power Inlet Drain Port SC 060815 Page 2 | 1-800-343-9463... -
Page 5: Controller Layout
! Not Recommended ! — Can only be done if the outside temperature does not exceed 85°F, the Outside Venting optional external grille cover is required Duct Options Exhaust air can be ducted using the optional ducting kit Warranty 2-year parts and labor / 5-year compressor www.whisperkool.com | Page 3... -
Page 6: Introduction
Customer Service Thank you for purchasing a WhisperKOOL SC Series cooling unit. We strive to provide the highest quality products and the best possible customer service. If you have any questions about your WhisperKOOL unit, please call us at 1-800-343-9463 or visit whisperkool.com. -
Page 7: Receiving And Inspecting The Unit
• Magnetic Deflectors for Airflow Control (2) Please leave the WhisperKOOL unit in its original box until you are ready for installation. This will allow you to move the product safely without damaging it. When you are ready to remove the product from the box, refer to the installation instructions. -
Page 8: Quick Start Guide
GFI (Ground Fault Interrupter) line. 4. For your convenience, the WhisperKOOL unit has two power inlets: one on the side of the unit, and the other on the back. Use the selector switch, located on the right side of the unit, to select the inlet you would like to use. -
Page 9: Preparing The Wine Cellar
PREPARING THE WINE CELLAR The performance and life of your WhisperKOOL unit is contingent upon the steps you take in preparing the wine cellar. Note: Improperly preparing your enclosure or incorrectly installing your WhisperKOOL unit may cause unit failure, leaking of condensation, and other negative side effects. -
Page 10: Mounting The Unit
In cases where glass doors are used and the room size is close to the recommended unit size, the next larger size WhisperKOOL should be used. This will compensate for the insulation loss due to the lower insulating rating of glass. - Page 11 In some cases, it may be advisable to install a vent fan to dissipate heat from within the exhaust area. However, you must have a fresh air inlet as well. If your unit requires ducting, please contact WhisperKOOL to obtain a specially designed ducting plenum for the unit.
-
Page 12: Pre-Installation
Electrical Needs The WhisperKOOL unit requires a dedicated 115V 20A circuit. The unit draws a large amount of amps at initial start up. By designating a dedicated circuit breaker, you will guarantee the unit has enough power to run effectively. Contact an electrician for assistance with the installation of this dedicated electrical circuit: •... -
Page 13: Airflow Control
Two Side Selective Airfl ow Options OPTION 5 OPTION 6 OPTION 7 OPTION 8 Note: Do not cover both of the openings on the same side of the unit for any reason. This will cause cooling issues and premature failure. www.whisperkool.com | Page 11... -
Page 14: Through-The-Wall Installation
Make sure that the internal height remains at 16” (2000/3000/4000) or 22.75” (6000/8000) so that the WhisperKOOL unit will fit snugly through the framed cut-out. SC 060815 Page 12 | 1-800-343-9463... -
Page 15: Preparing The Unit For Installation
5” inch thick wall Mounting Bracket (wall thickness may vary) Wine Cellar Exhaust Area #1 2000i/3000i/4000i 5–6 inches In Cellar 6000i/8000i 9.5–10.5 inches In Cellar #2 2000i/3000i/4000i 9–10 inches In Cellar 6000i/8000i 14–15 inches In Cellar www.whisperkool.com | Page 13... -
Page 16: Installing The Unit
The screws should penetrate the studs as well as the upper and lower supports to provide adequate support for the WhisperKOOL unit (see illustration). Seal all cracks and gaps around the WhisperKOOL unit with an air- tight sealant or caulking to prevent air leakage. -
Page 17: Condensation Drain Line
The drain line will prevent overfl ow and leaking by allowing for discharge of the additional condensate. To prevent mold from growing, allow the drain line to hang above the water line. WRONG: Drain line is under water. www.whisperkool.com | Page 15... -
Page 18: Liquid Measuring Thermostat System
LIQUID MEASURING THERMOSTAT SYSTEM The WhisperKOOL Series cooling units come equipped with a liquid temperature-measuring thermostat. This system incorporates the following advantages: Self-Calibrating Bottle Probe The bottle probe contains a sensor chip, which communicates back and forth with the thermostat. This results in a consistent temperature setting and accuracy. -
Page 19: Unit Operation
40F°, the display will blink three times and continue normal operation. Set Point The set point is set from the factory (WhisperKool) at 55F°. It can Bottle Probe Failure Protection be adjusted by the customer between 50–70F° in one degree In the event that a bottle probe should fail, the APST (Advance increments. -
Page 20: Controller
CONTROLLER Functions Button/Symbol Normal Functions ON/OFF • Press and hold the on/off button for approximately 3 seconds to turn the unit on or off. Note: This does not disconnect power from the unit. In order for the power to be shut off from the unit, the power cord must be unplugged from the wall receptacle. -
Page 21: Alarm Codes
Use this parameter to calibrate the bottle probe to a known temperature. This parameter can be adjusted between -12°F and 12°F. Example: Bottle temperature reading = 58°F Known temperature reading = 55°F CA1 parameter setting to match known temperature = -3 www.whisperkool.com | Page 19... -
Page 22: Wiring Schematic
WIRING SCHEMATIC SC 060815 Page 20 | 1-800-343-9463... -
Page 23: Maintenance Schedule
1. Use a vacuum with brush attachment to clean coils. Be careful not to crush coil fins when cleaning Annually 1. Inspect for corrosion 2. Check wiring connections and integrity of cords 3. Pour a 50/50 bleach solution into the drain line every spring www.whisperkool.com | Page 21... -
Page 24: Troubleshooting Guide
TROUBLESHOOTING GUIDE Unit Has Ice Forming on the Evaporator Possible Cause Solution Evaporator coil is dirty Clean coil with a vacuum If coil is very dirty, use a spray bottle with a small amount of liquid dish washing detergent. Spray coil, let set for 5 min, then flush with fresh water Something is blocking the supply and/or return air Remove blockage... - Page 25 Condensing fan motor/capacitor faulty Call Customer Service at 1-800-343-9463 Compressor and/or starting components faulty Call Customer Service at 1-800-343-9463 Humidity in Cellar too Low Possible Cause Solution Not enough moisture Raise the Fdc setting to increase the humidity level www.whisperkool.com | Page 23...
-
Page 26: Technical Assistance
TECHNICAL ASSISTANCE WhisperKOOL Customer Service is available Monday through Friday from 6:00 a.m. to 4:00 p.m. Pacific Standard Time. The appointed customer service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: The model and serial number of your WhisperKOOL unit. -
Page 27: Notes
SC Series NOTES www.whisperkool.com | Page 25... -
Page 28: Product Warranty Information
A. Two (2) Year Limited Warranty: For the period of TWO (2) YEARS (the “Limited Warranty Period”) from the date of original sale of a Product by WhisperKOOL, if a WhisperKOOL Product is found to be defective in material or workmanship after undergoing WhisperKOOL’s Customer Service troubleshooting, then, subject to the WhisperKOOL Product Limited... - Page 29 16. No one has any authority to add to or vary the limited warranty on this Product. 3. Product Installation Requirements: A. Prior to installing a WhisperKOOL Product, the End User must read the WhisperKOOL Owner’s Manual and thereafter the End User must follow the required installation, use and maintenance procedures set forth by WhisperKOOL in WhisperKOOL’s Owner’s Manual.
- Page 30 Product Limited Warranty And Product Installation Requirements), and further these Terms and Conditions of Sale shall be interpreted as though drafted jointly by WhisperKOOL and Purchaser. Any dispute will be resolved by the courts in and for the County of San Joaquin, State of California, and all parties, WhisperKOOL, Purchaser and End User, hereby irrevocably submit to the personal jurisdiction of such courts for that purpose.
- Page 31 E-mail: support@whisperkool.com Web: www.whisperkool.com B. Technical Assistance: WhisperKOOL Customer Service is available Monday through Friday from 6:00 a.m. to 4:00 p.m. (PST). The Customer Service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: 1.
- Page 32 WhisperKOOL 1738 E. Alpine Ave Stockton, CA 95205 1-800-343-9463 www.whisperkool.com...
