Getting to Know FLEXware 500
MX60s
AC Breakers
ACA
FX (with DCC)
DCA
HUB
IOB Kit
FW500-AC
FW Mounting Plate
DC Breakers
MX60 DC
FW500-DC
Disconnect
Breaker
Figure 1: Complete FLEXware 500 System installed (vertical installation is acceptable when
mounting space is limited)
Note: Although FLEXware 500 supports two MX Charge Controllers, both locations—top and
side—are shown in Figure 1.
