Page 1: Freestanding Dishwasher
Freestanding Dishwasher Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu... -
Page 2: Appliance Information
Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model Serial Number This appliance has been designed for domestic use only. - Page 3 CE Declarations of Conformity: This appliance has been designed, constructed and marketed in compliance with safety requirements of EEC Directives 2004/108/EC, 2006/95/EC, IEC436/DIN44990 & EN 50242. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
- Page 4 • Only put dishwasher safe items into the dishwasher. If in doubt, check with the manufacturer of the items. • Take care when loading the dishwasher to observe the recommendations for best loading practice, and also to ensure that sharp objects such as knives are placed blade down to prevent accidents.
-
Page 5: Before First Use
Recommendations • To reduce energy and water consumption, remove all dirt residues from the dishes prior to loading the dishwasher. • Only run the dishwasher when fully loaded. • Place hollow items (bowls, glasses and pans) face down in the basket. •... - Page 6 Control Panel wf610 Power button (1) • To switch the dishwasher on or off, press the power button (1). When you switch on the dishwasher, the end of programme light will illuminate, and two dashes will appear on the display. Programme display (2) The programme display shows the selected programme and the remaining time to run.
- Page 7 • To cancel the delay timer, press the delay timer button again until “0h” shows on the display. 3 in 1 function button (5) The dishwasher is equipped with a tablet function that automatically adjusts the amount of rinse aid and dishwasher salt used during a programme.
- Page 8 • To use this function, press the half-load button (7) until the indicator light shows next to the required section of the dishwasher, either upper, lower or both lights (if both baskets are to be washed together). Salt and rinse aid warning lights (8) When the dishwasher salt or rinse aid begins to run out, the warning light will illuminate to advise that it needs refilling.
- Page 9 • If required, set the delay timer by pressing the Delay Timer button • Once a programme is selected, the end of programme light will switch off. • When you close the dishwasher door, the programme will start automatically. Please note: The dishwasher stores the most recently used programme in its memory.
-
Page 10: Interior Lighting
• Press and hold in the Programme Selection button for three seconds until the end of programme indicator flashes and a “1” shows on the display. • Then close the door. The dishwasher will run a drain cycle which will take approximately 30 seconds. - Page 11 • Normal mode - The interior light comes on when the door is opened and stays on until the door is shut again. This will stay on however long the door stays open, as long as the power supply is connected to the machine.
- Page 12 As a result, it is recommended that powder detergents should be used in the shorter programmes to allow better performance. CDA recommends the use of separate detergent, rinse aid and dishwasher salt rather than combination tablets as separates achieve better wash performance.
- Page 13 If you do use combination detergents, add salt and rinse aid to the dishwasher. Then adjust the water hardness setting and rinse aid setting to the minimum. When you then use separate detergents again, you should fill the salt and rinse aid compartments, adjust the water hardness setting to the maximum and run an empty wash, then adjust the water hardness setting and the rinse aid setting to the appropriate level.
- Page 14 To add dishwasher salt, follow the steps below: 1. Remove the lower dishwasher basket and then unscrew the salt compartment cap, as shown in figure fig. 2 2. Fill the compartment with dishwasher salt (do not use table salt), carefully to prevent unnecessary spillage (figure 3).
-
Page 15: Softener Adjustment
Softener Adjustment The efficiency of your dishwasher depends on the softness of the tap water. To ensure best efficiency, the dishwasher is equipped with a system that reduces the hardness in the mains water supply. The efficiency will increase when the system is correctly set. To find out the water hardness level of your water supply you can use the test strip supplied or alternatively contact your local water board. - Page 16 Please note: The level of water hardness is preset to level 3. 1. Press and hold down the programme selection button 2. Press the Power button to switch on the dishwasher 3. Keep the programme selection button pressed until “SL” shows on the display and then disappears 4.
-
Page 17: Rinse Aid
Rinse Aid To fill the rinse aid compartment 1. Open the rinse aid compartment by turning and removing the cap as shown in figure 5. fig. 5 2. Fill the rinse aid compartment until the rinse aid indicator goes dark, as shown in figure 6 (where “a”... - Page 18 Please note: Rinse aid ensures better quality wash results and increased drying performance. Always refill the rinse aid when the rinse aid indicator light on the control panel is illuminated.
-
Page 19: Dishwasher Baskets
Top basket height adjustment while it Dishwasher Baskets Basket The middle basket has two different your ma Top basket height adjustment while it is full Top basket height adjustment while it is full top bask heights available, to allow for larger Basket height adjustment mechanism on the top basket of Basket height adjustment mechanism on the top basket of your machine is designed to let you adjust the height of you... - Page 20 Adjustable cup racks The dishwasher is equipped with adjustable cup racks on the middle basket to allow long stemmed glasses to rest securely during washing, or stacking of smaller cups. The cup Fig. 10 racks can also be folded up when not required to allow more space for larger items.
- Page 21 Top basket height adjustable racks The top basket is equipped with adjustable side racks as shown in fig. 12. After placing glasses in the upper basket these side racks can be placed at one of two heights to stand further items on: These may be used to hold longer knives/forks etc placed horizontally.
-
Page 22: Standard Loading And Test Data
Standard Loading and Test Data Capacity • Middle and lower baskets: 15 place settings. • The middle basket should be adjusted to the lowest position. Detergent / Rinse aid • 5 + 25 cm , in accordance with EN50242-DIN 44990 IEC 436 (international norms) / Rinse aid dosage adjustment: 4. -
Page 23: Programme Listing
Programme Listing Intensive+ Auto Auto- Auto- 70° (Inten- Programme name Intensive Prewash Express Quick Intensive normal delicate sive 60° and and temperature 60-70 50-60 prewash 30-50 function) Level of soil High High High Medium Medium High Detergent req’d A: 5cm B: 25cm / 15cm Prewash... -
Page 24: Care And Maintenance
Care and Maintenance Before beginning any care or maintenance, you should always disconnect the appliance from the electricity supply, and also turn off the water supply. fig. 15 Door seals Wipe the dishwasher door seals regularly with a damp cloth to remove any residues. -
Page 25: Dishwasher Interior
Please note: Never run a programme without the filters in place. Incorrect fitting of the filters may reduce wash performance and potentially damage your appliance. Spray arms You should clean the spray arms at least once a month. 1. Remove the lower basket 2. -
Page 26: Failure Codes And Troubleshooting
The filters of your machine might be blocked The waste water cannot be discharged • Restart the dishwasher and cancel the programme • If the error continues, contact CDA Customer Care Continual fill error • Contact CDA Customer Care Faulty flow meter •... - Page 27 Failure Codes and Troubleshooting Problem Possible cause Check the plug, fuse and circuit breakers of the mains supply. The water tap is turned off. The programme will not start The dishwasher door is not fully closed. The water inlet filter or the machine filters are blocked. The water drain hose is blocked or kinked.
-
Page 28: Electrical Information
Electrical information Warning! This appliance must be earthed. Green and yellow to Earth Brown to Live 13 Amp fuse Cord clamp Blue to Neutral The mains lead of this appliance has been fitted with a BS1363A 13Amp fused plug. To change a fuse in this type of plug, follow the steps below: 1. - Page 29 As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:- • The wire which is coloured GREEN and YELLOW must be connected to the terminal which is marked with letter (E) or by the Earth symbol or coloured GREEN and YELLOW.
-
Page 30: Installation
Installation • Do not install this appliance if it is damaged in any way. Installing a damaged appliance may invalidate the guarantee. • The water supply tap should be located in an adjacent cupboard so that it can be accessed after installation. - Page 31 The drain hose should be no longer than 4m in length to ensure good performance from the dishwasher. • To prevent siphoning, ensure that the water outlet is not pushed too far into the waste standpipe. The lowest part of the water outlet should be level with the bottom basket of the dishwasher.
- Page 32 Notes...
- Page 33 Notes...
- Page 34 Notes...
- Page 35 This programme is suitable to clean normally soiled tableware and it is the most efficient programme in terms of combined energy and water consumption. E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice.
- Page 36 T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu Copyright © CDA 2015...
