CSB200 Class B AIS

PROGRAMMING THE CSB200

proAIS Program

Before the CSB200 can transmit it requires to be programmed with your
own vessels information. This is done via the CSB200 field programmer
proAIS
Requirements
The proAIS application is designed to operate with Microsoft Windows
200, XP and above. Recommended minimum system requirements are:
•
Microsoft Windows XP SP2
•
Display resolution of at least 1024 x 768
•
At least one RS232 serial port (or USB to serial converter
already installed*)
*If you are using a USB to serial converter please ensure this is fully
installed before proceeding.
This software uses the Microsoft .Net Framework V2.0. The Framework
will be automatically installed during setup if not already present on the
system.
Setup
1. Insert the installation CD and locate the Setup.exe file.
2. Double click the Setup.exe file to begin the installation.
3. Follow on screen prompts to install the .Net Framework if
required
4. When the security warning below is displayed, select 'Install'
R2.0 13
www.busse-yachtshop.de | info@busse-yachtshop.de
CSB200 Class B AIS
5. The application will install and launch automatically
6. A Start Menu folder and shortcut will be created with the name
'proAIS'. This short cut should be used to re-launch the
application as required
Removal
The proAIS application can be removed at any time via the Windows
Control Panel 'Add or Remove Programs' tool.
AIS Connection
1. Launch the proAIS application by navigating to the 'proAIS'
shortcut on the Start Menu.
2. The initial application screen will appear as shown below (exact
screen display depends on version installed)
3. The application requires a serial connection to the CSB200.
Connect the CSB200 transponder to an available serial port.
R2.0 14
