CSB200 Class B AIS
VDO Message VDO Message Description
Number
AIS Target Display Information
13 Safety Related Acknowledgement
18 Standard Class B position report (Includes MMSI, SOG,
position accuracy, lat, long, COG, true heading,)
24a Class B "CS" Static data Part A (Includes MMSI and vessel
name)
24b Class B "CS" Static data Part B (Includes MMSI, ship type,
cargo type, call sign, ship dimensions)
ACA Message Format
The CSB200 unit can receive regional channel management information
(ACA) in two ways: ITU-R M.1371 message 22 or a DSC telecommand
received on channel 70,
Message Format
$--ACA,x,llll.ll,a,yyyyy.yy,a,llll.ll,a1,y1y1y1y1y.y1y1,a2,x1,x2x2x2x2,
x3,x4x4x4x4, x5,x6,x7,a3,x8,hhmmss.ss*hh <CR><LF>
•
x = Sequence Number , 0 to 9
•
IIII, II, a = Region Northeast corner latitude – N/S
•
yyyyy.yy,a1 = Region Northeast corner longitude – E/W
•
llll.ll,a = Region Southwest corner latitude – N/S
•
y1y1y1y1y1.y1y1,a2 = Region Southwest corner longitude –
E/W
•
x1 = Transition Zone Size
•
x2x2x2x2 = Channel A
•
x3 = Channel A bandwidth
•
x4x4x4x4 = Channel B
•
x5 = Channel B bandwidth
•
x6 = Tx/Rx mode control
R2.0 39
www.busse-yachtshop.de | info@busse-yachtshop.de
CSB200 Class B AIS
•
x7 = Power level control
•
a3 = Information source
•
x8 = In-Use Flag
•
hhmmss.ss = Time of "in-use" change
ACS Message Format
This sentence is used in conjunction with the ACA sentence and
identifies the originator of an ACA message.
$--ACS,x,xxxxxxxxx, hhmmss.ss,xx,xx,xxxx*hh <CR><LF>
•
x = Sequence Number , 0 to 9
•
xxxxxxxxx = MMSI of originator
•
hhmmss.ss = UTC of receipt of channel management
information
•
xx = UTC Day, 01 -31
•
xx = UTC Month, 01 -12
•
xxxx = UTC Year
ALR Message Format
Alarm message
$--ALR,hhmmss.ss,xxx,A,A,c--c*hh<CR><LF>
•
hhmmss.ss = Time of alarm (UTC)
•
xxx = Unique alarm number
•
A = Alarm condition
•
A = Alarm acknowledge state
•
c--c = Alarm description, text
Alarms descriptions presented are:
•
AIS: TX malfunction
•
AIS: Antenna VSWR exceeds limit
•
AIS: Rx channel 1 malfunction
