Data Connection - Comar Systems CSB200 Installation And Instruction Manual

CSB200 Class B AIS

Data Connection

If an external display unit is to be used to show other AIS units within
range (such as a chart plotter, PC serial terminal or other display device)
connect the user end of the data interface cable to the display device.
Note that the software in the display device must be configured for AIS
operation .
There is a 9-way D-type female connector mounted at the rear of the
CSB200. The standard wire ended data cable assembly provided mates
with this connector.
9 Pin D Cable Colour
1 BROWN -NMEA Output (RS422)
2 RED
3 ORANGE
4 YELLOW +NMEA Output (RS422)
5 GREEN
6 BLUE Configurable Switch +
7 VIOLET
8 GREY +NMEA Input (RS422)
9 BLACK -NMEA Input (RS422)
R2.0 11
Signal Name
+RS232 Output
+RS232 Input
Ground
Not Used
www.busse-yachtshop.de | info@busse-yachtshop.de
CSB200 Class B AIS
Connections to a PC.
CSB200 PC 9 Pin Serial Port
2- Red -TX Data
3- Orange- RX Data 3- Transmit Data
5 –Green-Ground
Connections to a Plotter.
CSB200
1 – Brown- NMEA Output B
4 – Yellow NMEA Output A
Data
The default baud rate of the data link is 38.4kBaud with 8 data bits, one
stop bit and no parity. No handshaking is used.
The data interface conforms to IEC 61162-1.
VDM, VDO, RMC, ACA, ACS, ALR, TXT and ACK messages conform to
NMEA 0183. Please refer to the SERIAL DATA INTERFACE section of
this manual for full details of these AIS messages.
R2.0 12
2- RX Data
5 -Ground
Plotter/Radar
NMEA Input B- Return
NMEA Input A - Positive
