USER’'S MANUAL

www.iconeurope.com

Table of Contents

Need help?

Do you have a question about the PETL10812.1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-Form PETL10812.1

Page 1 Model No. PETL10812.1 Serial No. Write the serial number in the space USER’’S MANUAL above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd.
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . . 2 IMPORTANT PRECAUTIONS .
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
Page 4 21. Do not attempt to move the treadmill until it DANGER: Always unplug the power is properly assembled. (See ASSEMBLY on cord immediately after use, before clean- page 7, and HOW TO FOLD AND MOVE ing the treadmill, and before performing the THE TREADMILL on page 25.) You must be maintenance and adjustment procedures able to safely lift 45 lbs.
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new PROFORM ® 910 ZLT manual. To help us assist you, note the product model treadmill. The 910 ZLT treadmill provides an impressive number and serial number before contacting us. The selection of features designed to make your workouts model number and the location of the serial number at home more effective and enjoyable.
Page 6: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
Page 7: Assembly
ASSEMBLY •• Assembly requires two persons. •• To identify small parts, see page 6. •• Place all parts in a cleared area and remove the •• Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex keys materials until you ...
Page 8 3. Identify the Left Upright (75). Have a second person hold the Left Upright near the Base (80). See the inset drawing. Tie the wire tie in the Wire Left Upright (75) securely around the end of the Upright Wire (70). Then, insert the Upright Wire into the lower end of the Left Upright as you pull Wire the other end of the wire tie upward through the...
Page 9: The Left Handrail, Remove And Discard It
5. Identify the Left and Right Base Covers (73, 74). Slide the Left and Right Base Covers onto the Left and Right Uprights (75, 76) as shown. 6. Identify the Left Handrail (71). If there is a wire in the Left Handrail, remove and discard it. Hold the Left Handrail (71) near the Left Upright (75).
Page 10 7. Attach the Right Handrail (72) to the Right Upright (76) with two 3/8" x 3 1/2" Screws (9) and two 3/8" Star Washers (5); do not fully tighten the Screws yet. 8. Insert the Console Frame (87) into the Handrails (71, 72).
Page 11 9. With the help of a second person, hold the con- sole assembly near the Left Handrail (71) and Console the Right Handrail (not shown). Assembly Connect the Upright Wire (70) to the console wire. See the inset drawing. The connectors should slide together easily and snap into place.
Page 12 11. Attach two Console Clamps (96) to the console assembly with four #8 x 3/4" Screws (6). Console Assembly See step 4. Tighten all six 3/8" x 4" Screws (4). 12. Identify the Left and Right Trays (97, 85). Orient the Trays as shown, and attach each Tray with four #8 x 3/4"...
Page 13 13. Raise the Frame (49) to the position shown. Have a second person hold the Frame during the next three assembly steps. Attach the Latch Crossbar (100) to the Frame (49) with two 1/4" x 1 3/4" Screws (107). 14. Orient the Storage Latch (51) so that the large barrel and the latch knob are in the positions shown.
Page 14 15. Attach a Wheel (81) to the Base (80) with a 3/8" x 2 1/2" Bolt (2) and a 3/8" Nut (3). Do not over- tighten the Nut; the Wheel must turn freely. Attach the other Wheel (81) to the other side of the Base (80) in the same way.
Page 15: The Chest Heart Rate Monitor
THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR •• Do not expose the heart rate monitor to direct sun- light for extended periods of time; do not expose it to The heart rate temperatures above 122° F (50° C) or below 14° F monitor consists of (-10°...
Page 16: Operation And Adjustment
OPERATION AND ADJUSTMENT HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
Page 17 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’’s premium stereo sound The treadmill console offers an impressive array of system while you get in shape. features designed to make your workouts more effec- tive and enjoyable.
Page 18 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power. If you do not See HOW TO TURN ON THE POWER at the left.
Page 19 4. Change the incline of the treadmill as desired. The My Trail tab will show a track that represents 400 m (1/4 mile). As you exercise, the flashing To change the incline of the treadmill, press the rectangle will show your progress. The My Trail tab Incline increase or decrease button or one of the will also show the number of laps you complete.
Page 20 6. Measure your heart rate if desired. When you are finished using the treadmill, press the power switch into the off position and unplug Note: If you use the handgrip heart rate monitor the power cord. IMPORTANT: If you do not do and the chest heart rate monitor at the same time, this, the treadmill’’s electrical components may the console will not display your heart rate accu-...
Page 21 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the pro le  ashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop.
Page 22 HOW TO USE A SET-A-GOAL WORKOUT 4. Follow your progress with the displays. 1. Insert the key into the console. See step 5 on page 19. See HOW TO TURN ON THE POWER on 5. Measure your heart rate if desired. page 18.
Page 23 3. Select a user. 5. Start the workout. If more than one user is registered, you can switch See step 3 on page 21. users in the iFit main screen. Press the increase and decrease buttons next to the Enter button to During some workouts, the voice of a personal select a user.
Page 24 THE INFORMATION MODE console. However, when you remove the key, the displays will remain lit, although the buttons will not The console features an information mode that keeps function. If the demo mode is turned on, the word track of treadmill information and allows you to person- ON will appear in the matrix.
Page 25: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.
Page 26: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the key, the demo mode is turned on. To turn off the simple steps below. Find the symptom that the demo mode, hold down the Stop button for a applies, and follow the steps listed. If further assis- few seconds.
Page 27 Locate the Reed Switch (95) and the Magnet (44) b. If the walking belt is overtightened, treadmill per- on the left side of the Pulley (43). Turn the Pulley formance may decrease and the walking belt may until the Magnet is aligned with the Reed Switch. become damaged.
Page 28 SYMPTOM: The walking belt is not centered SYMPTOM: The walking belt slips when walked on between the foot rails. IMPORTANT: If the walking belt rubs against the foot rails, the walking belt a. First, remove the key and UNPLUG THE POWER may be damaged.
Page 29: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
Page 30: Part List
PART LIST Model No. PETL10812.1 R0513A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Ground Screw Storage Latch 3/8" x 2 1/2" Bolt Right Rear Foot 3/8" Nut Left Rear Foot 3/8" x 4" Screw #8 x 1/2" Pulse Ground Screw 3/8"...
Page 31 Key No. Qty. Description Key No. Qty. Description Motor Isolator Small Cushion Motor Bushing 1/4" x 1 3/4" Screw Chest Strap M8 Nut M8 x 50mm Bolt –– User’’s Manual #8 Flat Washer Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.
Page 32: Exploded Drawing
EXPLODED DRAWING A Model No. PETL10812.1 R0513A...
Page 33 EXPLODED DRAWING B Model No. PETL10812.1 R0513A...
Page 34 EXPLODED DRAWING C Model No. PETL10812.1 R0513A 67 1...
Page 35 EXPLODED DRAWING D Model No. PETL10812.1 R0513A...
Page 36: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...
