HP StorageWorks Modular Smart Array 500 Overview page 4

QuickSpecs
Product Highlights
Modular Smart Array 500 Highlights Modular Smart Array 500 Highlights Modular Smart Array 500 Highlights Modular Smart Array 500 Highlights
High Levels of High Levels of High Levels of High Levels of
Performance, Data Performance, Data Performance, Data Performance, Data
Protection and Protection and
Protection and Protection and
Functionality Functionality Functionality Functionality
DtS (DAS to SAN) DtS (DAS to SAN) DtS (DAS to SAN) DtS (DAS to SAN)
Technology Technology Technology Technology
Low Total Cost of Low Total Cost of Low Total Cost of Low Total Cost of
Ownership Ownership Ownership Ownership
Modular Smart Array 500 Modular Smart Array 500 Modular Smart Array 500 Modular Smart Array 500
High Availability – supports a broad range of clustering options for Microsoft Windows Server, Linux Server and High Availability High Availability High Availability
Novell NetWare environments.
High Performance – Data transmission rate of 14,000 IOPS – 2 Node cluster configuration using Smart Array 5i High Performance
High Performance High Performance
Plus embedded controller in the ProLiant servers.
Storage Capacity Storage Capacity – The Modular Smart Array 500 cabinet supports up to fourteen 1" Universal hard drives, for a Storage Capacity Storage Capacity
maximum of 2TB of shared storage capacity using HP 146.8 Ultra320 SCSI Universal 1" hard drives.
Data Protection Data Protection Data Protection Data Protection – Modular Smart Array 500 is designed for a high level of data protection. It includes redundant
controllers (optional), redundant fans and power supplies (standard); multiple I/O path capability with Smart Array
Multipath software option, support for Hot Pluggable AIT and DAT tape drives in the storage enclosure,
transportable battery-backed cache and RAID ADG (standard).
Storage Manageability Storage Manageability Storage Manageability – The Smart Array Controllers feature familiar configuration and management tools Storage Manageability
such as Smart Array Configuration Utility and Insight Manager. Online Management Features: Online Capacity
Expansion (single path only), Online RAID Level Migration, Online Stripe Size Migration, Online Spares (Global),
User Selectable Read/Write cache, User Selectable Expand and Rebuild Priority.
Choice of Computing Platform Choice of Computing Platform – The Modular Smart Array 500 is designed and qualified for ProLiant servers. Choice of Computing Platform Choice of Computing Platform
Advanced Data Guarding (RAID ADG) Fault Tolerance – This is the highest level of RAID fault Advanced Data Guarding (RAID ADG) Fault Tolerance Advanced Data Guarding (RAID ADG) Fault Tolerance Advanced Data Guarding (RAID ADG) Fault Tolerance
tolerance. It allocates two sets of parity data across drives and allows simultaneous write operations. This level of
fault tolerance can withstand two simultaneous drive failures without downtime or data loss.
The Smart Array architecture provides a quick and easy way to migrate from the Modular Smart Array 500 to the Modular
Storage Array 1000 (MSA 1000).
In order to convert the Modular Smart Array 500 to a SAN, simply remove the Modular Smart Array Controller(s) and replace
them with StorageWorks MSA 1000 Controller(s) and add FC I/O board or FC Switch (please refer to MSA 1000
Quickspecs for additional SAN requirements information). This is referred to as DtS technology (DAS-to-SAN technology).
In addition to convertibility to the SAN, the Modular Smart Array 500 allows the seamless migration of stored data in
ProLiant servers protected by Smart Array PCI controllers to a Modular Smart Array 500 system. Data that is currently stored
on 1" Universal disk drives using HP Smart Array controllers, as well as data on an RA4100 can easily be migrated to the
Modular Smart Array 500. Simply remove the drives from the older systems and insert them into the Modular Smart Array
500. Existing data and configuration will remain intact. In addition, the RAID set and data will be preserved allowing
migration to be completed in minutes, not hours.
The modular, scalable design of the Modular Smart Array 500 provides an extremely flexible platform. You can buy what
you need today and purchase additional capacity and performance as your data storage needs grow, instead of making a
large up-front investment. Additional drives, controllers, and cache can be easily added as your needs dictate.
Storage Consolidation Storage Consolidation – Improve storage utilization and lower storage management cost through moving Storage Consolidation Storage Consolidation
internal storage to the Modular Smart Array 500.
Universal Hard Drive Universal Hard Drive Universal Hard Drive – Since the Modular Smart Array 500 supports Universal 1" SCSI drives, your investment in Universal Hard Drive
disk drives is protected and cost is minimized as you add new drives. Sharing of a common universal drive form
factor between your server and storage can significantly reduce needs for hardware and spare inventory, and offer
overall reduction in storage management and business costs.
Pre-Failure Warranty Pre-Failure Warranty Pre-Failure Warranty Pre-Failure Warranty – Drives installed in a Modular Smart Array 500 and monitored under Insight Manager
are supported by a Pre-Failure (replacement) Warranty. Pre-Failure Warranty allows for the replacement of
designated drives in Modular Smart Array 500 before they actually fail when using Insight Manager on ProLiant
servers. NOTE: Some operating systems may not support all of these features. NOTE: NOTE: NOTE:
Integrated Configuration and Management Tools – The Modular Smart Array 500 utilizes the standard, Integrated Configuration and Management Tools Integrated Configuration and Management Tools Integrated Configuration and Management Tools
integrated set of Smart Array management and utility software. These tools consistently lower the cost of ownership
by reducing training and technical expertise necessary to install and maintain HP server storage.
The 4U array houses up to fourteen 1" Universal hot pluggable Ultra320, Ultra3 and/or Ultra2 drives. Each Modular Smart
Array 500 includes the following standard components: Modular Smart Array 500 Controller, 2-port Ultra3 SCSI I/O
Module, dual hot pluggable fans/power supplies, two power cables, two VHDCI SCSI cables and a crossover Ethernet
cable.
DA - 11050
HP StorageWorks Modular Smart Array 500 HP StorageWorks Modular Smart Array 500 HP StorageWorks Modular Smart Array 500 HP StorageWorks Modular Smart Array 500
Canada — Version 13 — July 19, 2004 Page 4
