- Page 1 ® Instruction Manual...
-
Page 2: Safety Precautions And Warnings
NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury. -
Page 3: Table Of Contents
® Table of Contents First Flight Preparation ..................4 Using the Video Transmitter ...................9 Flying Checklist ....................4 Focusing the FPV Camera ...................10 FPV Ready Version Assembly ................4 Installing an Optional HD Video Camera...............10 Airframe Assembly ....................5 Removing the Motor ...................10 Transmitter Setup ....................6 AS3X Troubleshooting Guide ................11 Flight Battery Installation and ESC Arming.............6 Troubleshooting Guide ..................11... -
Page 4: First Flight Preparation
First Flight Preparation Flying Checklist ❏ Always turn the transmitter on fi rst • Remove and inspect contents ❏ Plug the fl ight battery into the lead from the ESC • Begin charging the fl ight battery ❏ Allow the ESC to initialize and arm properly •... -
Page 5: Airframe Assembly
Airframe Assembly Prior to beginning assembly, inspect all of the foam parts. Using a hobby knife or sandpaper, remove any excess fl ash or rough edges. NOTICE: When using cyanoacrylate (CA) adhesive to join or repair the airframe, DO NOT allow the adhesive to contact or get close to the fpv camera lens. The vapors from the adhesive will permanently fog the camera lens. -
Page 6: Transmitter Setup
Transmitter Setup Program Your Transmitter DX6, DX7 (Gen 2), DX8 (Gen 2), DX9, DX18, DX20 1. Start with a clean model memory slot. SETUP LIST FUNCTION LIST 2. Set the model type to “Airplane.” Model Type Timer 3. Assign channel 5 (Gear) to a 3-position switch. In the table at left, Mode Count Down Airplane... -
Page 7: Control Surface Centering And Throws
Control Surface Centering and Throws NOTICE: Remove the propeller from the motor shaft during control surface adjustments. Any movement of the throttle (even accidental) will cause the propeller to spin. With the receiver powered on, center the controls and trims. When the controls are neutral, the outer tip of the elevons should align with the trailing edge of the winglets, as shown in the illustration. -
Page 8: Balance The Airframe
Balance the Airframe NOTICE: DO NOT omit this step. Failure to balance the airframe properly will make the aircraft uncontrolable and will cause a crash. Crash damage is not covered under warranty. The recommended center of gravity is indicated on the bottom of the airframe by two molded-in marks just behind the wing lock access holes. -
Page 9: Post-Flight Inspection
Low Voltage Cutoff (LVC) Repairs When a Li-Po battery is discharged below 3V per cell, it will not hold a charge. Repairs to the foam can be made using virtually any adhesive (hot glue, CA, The ESC protects the fl ight battery from over-discharge using Low Voltage Cutoff epoxy, etc). -
Page 10: Focusing The Fpv Camera
Focusing the FPV Camera To focus your FPV camera: 1. Remove the propeller. 2. Tape the provided focus pattern page to a wall. 3. Place your camera 8-10 feet (2.5-3m) from the wall, pointing at the focus pattern page. 4. Power on your transmitter, fpv monitor or headset and aircraft. 5. -
Page 11: As3X Troubleshooting Guide
AS3X Troubleshooting Guide Problem Possible Cause Solution Damaged propeller Replace propeller Propeller out of balance Balance the propeller Motor vibration Replace parts or correctly align all parts and tighten fasteners as needed Loose receiver Align and secure receiver in fuselage Oscillation in fl... -
Page 12: Parts Explosion
Parts Explosion Replacement Parts Part # Description Part # Description BLH03050 Theory Type W FPV Equipped BNF Basic 6 BLHA1002 5x4 FPV Race Prop, 2Blade, Green BLH03055 Theory Type W FPV Ready BNF Basic 7 BLHA1021 2205-2350Kv FPV Racing Motor... -
Page 13: Limited Warranty
Limited Warranty What this Warranty Covers contact your local distributor or Horizon directly. This will enable Horizon to better answer your questions and service you in the event that you may need any assistance. Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product For questions or assistance, please visit our website at www.horizonhobby.com, purchased (the “Product”) will be free from defects in materials and workmanship at submit a Product Support Inquiry, or call the toll free telephone number referenced in... -
Page 14: Fcc Information
FCC Information This equipment has been tested and found to comply with the limits for Part 15 of This device complies with part 15 of the FCC rules. Operation is subject to the the FCC rules. These limits are designed to provide reasonable protection against following two conditions: (1) This device may not cause harmful interference, and harmful interference in a residential installation. -
Page 15: Focus Pattern
Focus Pattern... - Page 16 ©2016 Horizon Hobby, LLC. Blade, Theory, DSM, DSM2, DSMX, AS3X, ModelMatch, Bind-N-Fly, BNF, the BNF logo, Thrust, EC3 and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
