PRECAUTIONS
R WARNING! NEVER connect the transceiver to an AC outlet.
This may pose a fire hazard or result in an electric shock.
R WARNING! NEVER connect the transceiver to a power source
of more than 16 V DC such as a 24 V battery. This could cause a
fire or damage the transceiver.
R WARNING! NEVER reverse the DC power cable polarity when
connecting to a power source. This could damage the transceiver.
R WARNING! NEVER cut the DC power cable between the DC
plug at the back of the transceiver and fuse holder. If an incorrect
connection is made after cutting, the transceiver may be damaged.
R WARNING! NEVER operate the transceiver during a lightning
storm. It may result in an electric shock, cause a fire or damage the
transceiver. Always disconnect the power souce and antenna before
a storm.
CAUTION: NEVER place the transceiver where normal operation of
the vessel may be hindered or where it could cause bodily injury.
DO NOT use or place the transceiver in areas with temperatures
below -20°C or above +60°C or, in areas subject to direct sunlight,
such as the dashboard.
DO NOT use harsh solvents such as Benzine or alcohol to clean
the transceiver, as they will damage the transceiver's surfaces. If
the transceiver becomes dusty or dirty, wipe it clean with a soft, dry
cloth.
DO NOT disassemble or modify the transceiver for any reason.
BE CAREFUL! The transceiver rear panel will become hot when
operating continuously for long periods of time.
BE CAREFUL! The transceiver and the hand microphone meet
IPX7 requirements for waterproof protection. However, once the
transceiver or the microphone has been dropped, waterproof
protection cannot be guaranteed because of possible damage to
the transceiver or microphone's case or their waterproof seals.
Keep the transceiver at least 1 m away from the ship's navigation
compass.

TABLE OF CONTENTS

1. OPERATING RULES ............................................. 1
2. PANEL DESCRIPTION.......................................... 2
3. BASIC OPERATION .............................................. 4
4. SCAN OPERATION ............................................... 9
5. DUALWATCH/TRI-WATCH ...................................11
6. SET MODE .......................................................... 12
7. CONNECTIONS AND MAINTENANCE .............. 14
8. TROUBLESHOOTING ........................................ 17
9. CHANNEL LIST ................................................... 18
10. SPECIFICATIONS AND OPTIONS ................... 19
INDEX...................................................................... 20
