IEI Technology WAFER-PV-D5252 User Manual

3.5" sbc with intel atom processor
Hide thumbs Also See for WAFER-PV-D5252:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
WAFER-PV-D5252/D4252/N4552 SBC
MODEL:
WAFER-PV-D5252/D4252/N4552
3.5" SBC with Intel® Atom™ Processor
Up to 2.0 GB DDR3, VGA, LVDS, PCIe Mini, RS-232/422/485,
SATA 3Gb/s, CompactFlash®, Eight USB, RoHS

User Manual

Page i
Rev. 1.11 – December 17, 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAFER-PV-D5252 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology WAFER-PV-D5252

Summary of Contents for IEI Technology WAFER-PV-D5252

  • Page 1: User Manual

    WAFER-PV-D5252/D4252/N4552 SBC MODEL: WAFER-PV-D5252/D4252/N4552 3.5" SBC with Intel® Atom™ Processor Up to 2.0 GB DDR3, VGA, LVDS, PCIe Mini, RS-232/422/485, SATA 3Gb/s, CompactFlash®, Eight USB, RoHS User Manual Page i Rev. 1.11 – December 17, 2014...
  • Page 2 WAFER-PV-D5252/D4252/N4552 SBC Revision Date Version Changes December 17, 2014 1.11 Added WAFER-PV-D4252 information November 24, 2014 1.10 Updated for R11 version - Changed audio controller from ALC888 to ALC662 - Updated Chapter 5: BIOS November 7, 2014 1.03 Modified COM port information to...
  • Page 3 WAFER-PV-D5252/D4252/N4552 SBC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    WAFER-PV-D5252/D4252/N4552 SBC Table of Contents 1 INTRODUCTION......................1 1.1 I ......................2 NTRODUCTION 1.2 B ........................2 ENEFITS 1.3 F ........................3 EATURES 1.4 C ......................3 ONNECTORS 1.5 D ....................... 4 IMENSIONS 1.6 D ........................ 6 1.7 T ..................7...
  • Page 5 WAFER-PV-D5252/D4252/N4552 SBC 3.2.11 PCIe Mini Card Slot..................26 3.2.12 Power Button Connector................28 3.2.13 Reset Button Connector ................. 28 3.2.14 RS-232/422/485 Serial Port Connector (COM6) .......... 29 3.2.15 RS-232 Serial Port Connector (COM2~COM5)..........30 3.2.16 SATA Drive Connectors ................. 31 3.2.17 SATA Power Connectors ................
  • Page 6 WAFER-PV-D5252/D4252/N4552 SBC 4.7.2 Audio Kit Installation..................53 4.7.3 Keyboard/Mouse Connector ................55 4.7.4 Four Serial Port Connector ................57 4.8 S ..................58 OFTWARE NSTALLATION 5 BIOS ..........................60 5.1 I ......................61 NTRODUCTION 5.1.1 Starting Setup....................61 5.1.2 Using Setup ...................... 61 5.1.3 Getting Help.....................
  • Page 7 WAFER-PV-D5252/D4252/N4552 SBC C.1 I ......................99 NTRODUCTION C.2 A 1................100 SSEMBLY ANGUAGE AMPLE C.3 A 2................100 SSEMBLY ANGUAGE AMPLE D HAZARDOUS MATERIALS DISCLOSURE ............101 D.1 H IPB P AZARDOUS ATERIALS ISCLOSURE ABLE FOR RODUCTS ERTIFIED AS HS C 2002/95/EC W ........
  • Page 8 WAFER-PV-D5252/D4252/N4552 SBC List of Figures Figure 1-1: WAFER-PV-D5252/D4252/N4552................2 Figure 1-2: Connectors ........................3 Figure 1-3: Dimensions without Heatsink (mm) ................4 Figure 1-4: Dimensions with Heatsink (mm)................5 Figure 1-5: Data Flow Diagram......................6 Figure 3-1: Connector and Jumper Locations................14 Figure 3-2: ATX Power Connector Location ................17 Figure 3-3: Audio Connector Location ..................17...
  • Page 9 WAFER-PV-D5252/D4252/N4552 SBC Figure 3-26: VGA Connector .......................39 Figure 4-1: SO-DIMM Installation ....................43 Figure 4-2: CompactFlash® Card Installation ................44 Figure 4-3: AT/ATX Mode Selection Jumper Location..............46 Figure 4-4: Clear CMOS Jumper Location .................47 Figure 4-5: LVDS Voltage Selection Jumper Location .............48 Figure 4-6: LVDS Resolution Selection Jumper Location............49...
  • Page 10 WAFER-PV-D5252/D4252/N4552 SBC List of Tables Table 1-1: Technical Specifications....................8 Table 2-1: Packing List.........................12 Table 2-2: Optional Items......................12 Table 3-1: Peripheral Interface Connectors ................16 Table 3-2: Rear Panel Connectors ....................16 Table 3-3: ATX Power Connector Pinouts .................17 Table 3-4: Audio Connector Pinouts ..................18 Table 3-5: Battery Connector Pinouts ..................18...
  • Page 11 WAFER-PV-D5252/D4252/N4552 SBC Table 4-1: Jumpers ........................45 Table 4-2: AT/ATX Mode Selection .....................46 Table 4-3: Clear CMOS Jumper Settings..................47 Table 4-4: LVDS Voltage Selection .....................48 Table 4-5: LVDS Resolution Selection..................48 Table 4-6: CompactFlash® Master/Slave Selection ..............49 Table 4-7: COM6 RS-232/422/485 Selection ................50 Table 4-8: COM 1 Pin 9 Setting Jumper Settings ..............51...
  • Page 12 WAFER-PV-D5252/D4252/N4552 SBC BIOS Menus BIOS Menu 1: Main ........................63 BIOS Menu 2: Advanced ......................64 BIOS Menu 3: ACPI Configuration ....................65 BIOS Menu 4: RTC Wake Settings ....................66 BIOS Menu 5: CPU Configuration ....................67 BIOS Menu 6: IDE Configuration....................68 BIOS Menu 7: USB Configuration ....................70 BIOS Menu 8: Super IO Configuration..................71...

  • Page 13: Introduction

    WAFER-PV-D5252/D4252/N4552 SBC Chapter Introduction Page 1...

  • Page 14: Introduction

    WAFER-PV-D5252/D4252/N4552 SBC 1.1 Introduction Figure 1-1: WAFER-PV-D5252/D4252/N4552 The WAFER-PV-D5252/D4252/N4552 is a 3.5" SBC with a Intel® Atom™ D525, D425 or N455 CPU. The WAFER-PV-D5252/D4252/N4552 is designed for fanless operation. The low power CPUs don't require active cooling and stay within specified heat range using the included heatsink.

  • Page 15: Features

     Eight USB 2.0 ports  Six serial ports  PCIe Mini card slot  CompactFlash® Type II slot  Gigabit Ethernet 1.4 Connectors The connectors on the WAFER-PV-D5252/D4252/N4552 are shown in the figure below. Figure 1-2: Connectors Page 3...

  • Page 16: Dimensions

    WAFER-PV-D5252/D4252/N4552 SBC 1.5 Dimensions The main dimensions of the WAFER-PV-D5252/D4252/N4552 are shown in the diagram below. Figure 1-3: Dimensions without Heatsink (mm) Page 4...

  • Page 17: Figure 1-4: Dimensions With Heatsink (Mm)

    WAFER-PV-D5252/D4252/N4552 SBC Figure 1-4: Dimensions with Heatsink (mm) Page 5...

  • Page 18: Data Flow

    WAFER-PV-D5252/D4252/N4552 SBC 1.6 Data Flow Figure 1-5 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-5: Data Flow Diagram Page 6...

  • Page 19: Technical Specifications

    WAFER-PV-D5252/D4252/N4552 SBC 1.7 Technical Specifications WAFER-PV-D5252/D4252/N4552 technical specifications are listed in Table 1-1. Specification WAFER-PV-D5252/D4252/N4552 Form Factor 3.5" Socket Embedded 1.8 GHz Intel® Atom™ D525 dual-core CPU with 1 MB L2 cache CPU Supported 1.8 GHz Intel® Atom™ D425 single-core CPU with 512 KB L2 cache 1.66 GHz Intel®...

  • Page 20: Table 1-1: Technical Specifications

    WAFER-PV-D5252/D4252/N4552 SBC I/O Interface Connectors Two 3-pin wafer for system fan Fan connector Keyboard/Mouse One internal 6-pin wafer connector Serial Ports Five RS-232 COM connectors One RS-232/422/485 COM connector USB 2.0/1.1 ports Six internal via pin header Two external USB ports...

  • Page 21: Packing List

    WAFER-PV-D5252/D4252/N4552 SBC Chapter Packing List Page 9...

  • Page 22: Anti-Static Precautions

    Only handle the edges of the PCB:- Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the WAFER-PV-D5252/D4252/N4552 is unpacked, please do the following:  Follow the antistatic guidelines above.

  • Page 23: Packing List

    Contact the IEI reseller or vendor the WAFER-PV-D5252/D4252/N4552 was purchased from or contact an sales representative directly sending email sales@ieiworld.com. The WAFER-PV-D5252/D4252/N4552 is shipped with the following components: Quantity Item and Part Number Image WAFER-PV-D5252, WAFER-PV-D4252 or WAFER-PV-N4552 SATA and power cable...

  • Page 24: Optional Items

    WAFER-PV-D5252/D4252/N4552 SBC Quantity Item and Part Number Image Mini jumper pack (2.0mm) (P/N:33100-000033-RS) Utility CD Quick installation guide Table 2-1: Packing List 2.4 Optional Items These optional items are available. Item and Part Number Image Dual USB cable (wo bracket)

  • Page 25: Connector Pinouts

    WAFER-PV-D5252/D4252/N4552 SBC Chapter Connector Pinouts Page 13...

  • Page 26: Peripheral Interface Connectors

    WAFER-PV-D5252/D4252/N4552 SBC 3.1 Peripheral Interface Connectors Section 3.1.2 shows peripheral interface connector locations. Section 3.1.2 lists all the peripheral interface connectors seen in Section 3.1.2. 3.1.1 Layout The figure below shows the on-board peripheral connectors, rear panel peripheral connectors and on-board jumpers.

  • Page 27: Peripheral Interface Connectors

    WAFER-PV-D5252/D4252/N4552 SBC 3.1.2 Peripheral Interface Connectors The table below shows a list of the peripheral interface connectors on the WAFER-PV-D5252/D4252/N4552. Detailed descriptions of these connectors can be found below. Connector Type Label +12 V ATX power connector 4-pin connector Audio connector...

  • Page 28: External Interface Panel Connectors

    8-pin header USB2, USB3, USB4 Table 3-1: Peripheral Interface Connectors 3.1.3 External Interface Panel Connectors The table below lists the rear panel connectors on the WAFER-PV-D5252/D4252/N4552. Detailed descriptions of these connectors can be found in a later section. Connector Type Label...

  • Page 29: Audio Connector

    WAFER-PV-D5252/D4252/N4552 SBC Figure 3-2: ATX Power Connector Location Description Description Ground Ground +12 V +12V Table 3-3: ATX Power Connector Pinouts 3.2.2 Audio Connector CN Label: AUDIO1 CN Type: 10-pin header CN Location: See Figure 3-3 CN Pinouts: See Table 3-4 This connector connects to speakers, a microphone and an audio input.

  • Page 30: Battery Connector

    WAFER-PV-D5252/D4252/N4552 SBC Description Description GND_AUDIO GND_AUDIO MICIN MICIN Table 3-4: Audio Connector Pinouts 3.2.3 Battery Connector CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations.

  • Page 31: Compactflash® Slot

    WAFER-PV-D5252/D4252/N4552 SBC 3.2.4 CompactFlash® Slot CN Label: CompactFlash® card slot CN Type: CN Location: See Figure 3-5 CN Pinouts: See Table 3-6 NOTE: 1. Both CompactFlash® Type I and Type II cards are supported. 2. To use SATA and CF, CF must be set to slave.

  • Page 32: Digital I/O Connector

    WAFER-PV-D5252/D4252/N4552 SBC Description Description VS1# IOR# IOW# CSEL# VS2# RESET# WAIT# INPACK# REG# BVD2 BVD1 IOCS16# CD2# GND2 Table 3-6: CompactFlash® Slot Pinouts 3.2.5 Digital I/O Connector CN Label: DIO1 CN Type: 10-pin header CN Location: See Figure 3-6 See Table 3-7 CN Pinouts: The digital I/O connector provides programmable input and output for external devices.

  • Page 33: Fan Connectors

    WAFER-PV-D5252/D4252/N4552 SBC Figure 3-6: Digital I/O Connector Location Description Description Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 Table 3-7: Digital I/O Connector Pinouts 3.2.6 Fan Connectors CN Label: FAN1, FAN2 3-pin wafer...

  • Page 34: Keyboard/Mouse Connector

    WAFER-PV-D5252/D4252/N4552 SBC Figure 3-7: Fan Connector Locations Description FANIO1 +12V (PWM) Table 3-8: Fan Connector Pinouts 3.2.7 Keyboard/Mouse Connector CN Label: KB/MS1 6-pin wafer CN Type: CN Location: See Figure 3-8 CN Pinouts: See Table 3-9 The keyboard/mouse connector connects to a PS/2 Y-cable that can be connected to a PS/2 keyboard and mouse.

  • Page 35: Led And +5 V Power Output Connector

    WAFER-PV-D5252/D4252/N4552 SBC Figure 3-8: Keyboard/Mouse Connector Location Description Mouse Data Mouse Clock Keyboard Data Keyboard Clock Table 3-9: Keyboard/Mouse Connector Pinouts 3.2.8 LED and +5 V Power Output Connector CN Label: CN Type: 6-pin wafer CN Location: See Figure 3-9...

  • Page 36: Lvds Connector

    WAFER-PV-D5252/D4252/N4552 SBC Figure 3-9: LED and +5 V Power Output Connector Location Description +5 V +5 V Power Output Power LED HDD LED -HDLED Table 3-10: LED and +5 V Power Output Connector Pinouts 3.2.9 LVDS Connector CN Label: LVDS1...

  • Page 37: Lvds Backlight Connector

    WAFER-PV-D5252/D4252/N4552 SBC Figure 3-10: LVDS Connector Location Description Description GROUND GROUND LVDS_A_TX0-P LVDS_A_TX0-N LVDS_A_TX1-P LVDS_A_TX1-N LVDS_A_TX2-P LVDS_A_TX2-N LVDS_A_TXCLK-P LVDS_A_TXCLK-N LVDS_A_TX3-P LVDS_A_TX3-N GROUND GROUND LVDS_B_TX0-P LVDS_B_TX0-N LVDS_B_TX1-P LVDS_B_TX1-N LVDS_B_TX2-P LVDS_B_TX2-N LVDS_B_TXCLK-P LVDS_B_TXCLK-N LVDS_B_TX3-P LVDS_B_TX3-N GROUND GROUND +LCD VCC +LCD VCC +LCD VCC...

  • Page 38: Pcie Mini Card Slot

    WAFER-PV-D5252/D4252/N4552 SBC CN Pinouts: See Table 3-12 The backlight inverter connector provides power to an LCD panel. Figure 3-11: Backlight Inverter Connector Description LCD_BKLTCTL GROUND +12V GROUND BACKLIGHT ENABLE Table 3-12: Backlight Inverter Connector 3.2.11 PCIe Mini Card Slot CN Label:...

  • Page 39: Figure 3-12: Pcie Mini Card Slot Location

    WAFER-PV-D5252/D4252/N4552 SBC Figure 3-12: PCIe Mini Card Slot Location Description Description PCIE_WAKE# VCC3 1.5V CLKREQ# LFRAME# LAD3 CLK- LAD2 CLK+ LAD1 LAD0 PCIRST# VCC3 PCIRST# PERN2 3VDual PERP2 1.5V SMBCLK PETN2 SMBDATA PETP2 USBD- USBD+ SATARXP SATARXN RF_LINK# SATATXN BLUELED# SATATXP 1.5V...

  • Page 40: Power Button Connector

    WAFER-PV-D5252/D4252/N4552 SBC Description Description VCC3 Table 3-13: PCIe Mini Card Slot Pinouts 3.2.12 Power Button Connector CN Label: PWR_BTN CN Type: 2-pin wafer CN Location: See Figure 3-13 CN Pinouts: See Table 3-14 The power button connector is connected to a power switch on the system chassis.

  • Page 41: Rs-232/422/485 Serial Port Connector (Com6)

    WAFER-PV-D5252/D4252/N4552 SBC The reset button connector is connected to a reset switch on the system chassis. Figure 3-14: Reset Button Connector Location Description PM_RESET Table 3-15: Reset Button Connector Pinouts 3.2.14 RS-232/422/485 Serial Port Connector (COM6) CN Label: COM6 14-pin header...

  • Page 42: Serial Port Connector (Com2~Com5)

    WAFER-PV-D5252/D4252/N4552 SBC Description Description Data Carrier Direct (DCD) Data Set Ready (DSR) Receive Data (RXD) Request To Send (RTS) Transmit Data (TXD) Clear To Send (CTS) Data Terminal Ready (DTR) Ring Indicator (RI) Ground (GND) TXD485+ TXD485# RXD485+ RXD485# Table 3-16: RS-232/422/485 Serial Port Connector Pinouts 3.2.15 RS-232 Serial Port Connector (COM2~COM5)

  • Page 43: Sata Drive Connectors

    WAFER-PV-D5252/D4252/N4552 SBC Description Description DATA CARRIER DETECT (DCD3) DATA SET READY (DSR3) RECEIVE DATA (RXD3) REQUEST TO SEND (RTS3) TRANSMIT DATA (TXD3) CLEAR TO SEND (CTS3) DATA TERMINAL READY (DTR3) RING INDICATOR (RI3) DATA CARRIER DETECT (DCD4) DATA SET READY (DSR4)

  • Page 44: Sata Power Connectors

    WAFER-PV-D5252/D4252/N4552 SBC Description Table 3-18: SATA Drive Connector Pinouts 3.2.17 SATA Power Connectors CN Label: SATA_PWR1, SATA_PWR2 CN Type: 2-pin wafer CN Location: See Figure 3-18 CN Pinouts: See Table 3-19 Use the SATA Power Connector to connect to SATA device power connections.

  • Page 45: Smbus Connector

    WAFER-PV-D5252/D4252/N4552 SBC 3.2.18 SMBus Connector CN Label: 4-pin wafer CN Type: CN Location: See Figure 3-19 CN Pinouts: See Table 3-20 The SMBus (System Management Bus) connector provides low-speed system management communications. Figure 3-19: SMBus Connector Location Description SMBDATA SMBCLK Table 3-20: SMBus Connector Pinouts 3.2.19 SO-DIMM Connector...

  • Page 46: Spi Flash Connector

    WAFER-PV-D5252/D4252/N4552 SBC Figure 3-20: SO-DIMM Connector Location 3.2.20 SPI Flash Connector CN Label: JSPI1 CN Type: 8-pin header CN Location: See Figure 3-21 CN Pinouts: See Table 3-21 The 8-pin SPI Flash connector is used to flash the BIOS. Figure 3-21: SPI Flash Connector Location...

  • Page 47: Usb Connectors

    WAFER-PV-D5252/D4252/N4552 SBC 3.2.21 USB Connectors CN Label: USB2, USB3, USB4 8-pin header CN Type: CN Location: See Figure 3-22 CN Pinouts: See Table 3-22 The USB header can connect to two USB devices. Figure 3-22: USB Connector Location Description Description...

  • Page 48: External Interface Connectors

    WAFER-PV-D5252/D4252/N4552 SBC 3.3 External Interface Connectors Figure 3-23 shows the WAFER-PV-D5252/D4252/N4552 motherboard external interface connectors. WAFER-PV-D5252/D4252/N4552 on-board external interface connectors are shown in Figure 3-23. Figure 3-23: External Interface Connectors 3.3.1 Ethernet Connectors CN Label: LAN1, LAN2 CN Type: RJ-45...

  • Page 49: Serial Port Connector

    WAFER-PV-D5252/D4252/N4552 SBC Figure 3-24: Ethernet Connector The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green LED indicates activity on the port and the yellow LED indicates the port is linked. See Table 3-24. SPEED LED...

  • Page 50: Usb Ports

    WAFER-PV-D5252/D4252/N4552 SBC Figure 3-25: Serial Port Pinout Locations 3.3.3 USB Ports CN Label: USB1 CN Type: USB Combo ports See Figure 3-23 CN Location: CN Pinouts: See Table 3-26 The USB ports attach to standard USB devices. Description Data1- Data1+...

  • Page 51: Figure 3-26: Vga Connector

    WAFER-PV-D5252/D4252/N4552 SBC The standard 15-pin female VGA connector connects to a CRT or LCD monitor. Description Description Description GROUND GREEN GROUND BLUE GROUND HSYNC VSYNC GROUND GROUND Table 3-27: VGA Connector Pinouts Figure 3-26: VGA Connector Page 39...

  • Page 52: Installation

    WAFER-PV-D5252/D4252/N4552 SBC Chapter Installation Page 40...

  • Page 53: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the WAFER-PV-D5252/D4252/N4552. Dry climates are especially susceptible to ESD. It is therefore critical to strictly adhere to the following anti-static precautions whenever the WAFER-PV-D5252/D4252/N4552, or any other electrical component, is handled.

  • Page 54: Installation Considerations

    4.2 Installation Considerations NOTE: The following installation notices and installation considerations should be read and understood before the WAFER-PV-D5252/D4252/N4552 is installed. All installation notices pertaining to the installation of WAFER-PV-D5252/D4252/N4552 should be strictly adhered to. Failing to adhere to these precautions may lead to severe damage of the WAFER-PV-D5252/D4252/N4552 and injury to the person installing the motherboard.

  • Page 55: So-Dimm Installation

    WAFER-PV-D5252/D4252/N4552 SBC Before and during the installation of the WAFER-PV-D5252/D4252/N4552 DO NOT:  DO NOT remove any of the stickers on the PCB board. These stickers are required for warranty validation.  DO NOT use the product before verifying all the cables and power connectors are properly connected.

  • Page 56: Compactflash® Installation

    WAFER-PV-D5252/D4252/N4552 SBC 4.4 CompactFlash® Installation NOTE: Both CompactFlash® Type I and Type II cards are supported. To install the CompactFlash® card, please follow the steps below. Step 1: Locate the CF card socket. Locate the CompactFlash® slot. Step 2: Align the CF card. Align the CompactFlash® card. The label side should be facing away from the board.

  • Page 57: Jumper Settings

    OPEN a jumper means removing the plastic clip from a jumper. Before the WAFER-PV-D5252/D4252/N4552 is installed in the system, the jumpers must be set in accordance with the desired configuration. The jumpers on the WAFER-PV-D5252/D4252/N4552 are listed in Table 4-1.

  • Page 58: Clear Cmos Jumper

    Jumper Location: See Figure 4-4 If the WAFER-PV-D5252/D4252/N4552 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2.

  • Page 59: Lvds Voltage Selection

    WAFER-PV-D5252/D4252/N4552 SBC If the “CMOS Settings Wrong” message is displayed during the boot up process, the fault may be corrected by pressing the F1 to enter the CMOS Setup menu. Do one of the following:  Enter the correct CMOS setting ...

  • Page 60: Lvds Resolution Selection

    WAFER-PV-D5252/D4252/N4552 SBC Description Short 1-2 +5 V Short 2-3 +3.3 V (Default) Table 4-4: LVDS Voltage Selection Figure 4-5: LVDS Voltage Selection Jumper Location 4.5.4 LVDS Resolution Selection Jumper Label: J_LCD_TYPE1 8-pin header Jumper Type: Jumper Settings: See Table 4-5...

  • Page 61: Compactflash® Master/Slave Selection

    WAFER-PV-D5252/D4252/N4552 SBC Figure 4-6: LVDS Resolution Selection Jumper Location 4.5.5 CompactFlash® Master/Slave Selection Jumper Label: JCF1 Jumper Type: 2-pin header Jumper Settings: See Table 4-6 See Figure 4-7 Jumper Location: NOTE: To use SATA and CF, CF must be set as slave Sets the CompactFlash®...

  • Page 62: Com6 Rs-232/422/485 Selection

    WAFER-PV-D5252/D4252/N4552 SBC Figure 4-7: CompactFlash® Master/Slave Selection Jumper Location 4.5.6 COM6 RS-232/422/485 Selection Jumper Label: Jumper Type: 8-pin header Jumper Settings: See Table 4-7 See Figure 4-8 Jumper Location: Selects the communication method of COM6 serial port. Description Short 1-2...

  • Page 63: Com 1 Pin 9 Setting Jumper

    WAFER-PV-D5252/D4252/N4552 SBC 4.5.7 COM 1 Pin 9 Setting Jumper Jumper Label: 6-pin header Jumper Type: See Table 4-8 Jumper Settings: Jumper Location: See Figure 4-9 The COM 1 Pin 9 Setting jumper configures pin 9 on COM 1 as either a +5 V, +12 V power source or as a ring-in (RI) line.

  • Page 64: Chassis Installation

    The chassis should have fans and vents as necessary to keep things cool. The WAFER-PV-D5252/D4252/N4552 must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface. In a system with an individual power supply unit, the cooling fan of a power supply can also help generate airflow through the board surface.

  • Page 65: Audio Kit Installation

    AT power supply. See Figure 4-12. 4.7.2 Audio Kit Installation The Audio Kit that came with the WAFER-PV-D5252/D4252/N4552 connects to the audio connector on the WAFER-PV-D5252/D4252/N4552. The audio kit consists of three audio jacks. Mic-in connects to a microphone. Line-in provides a stereo line-level input to connect to the output of an audio device.

  • Page 66: Figure 4-11: Audio Kit Cable Connection

    WAFER-PV-D5252/D4252/N4552 SBC Step 1: Locate the audio connector. The location of the 10-pin audio connector is shown in Chapter 3. Step 2: Align pin 1. Align pin 1 on the on-board connector with pin 1 on the audio kit connector. Pin 1 on the audio kit connector is indicated with a white dot. See Figure 4-11.

  • Page 67: Keyboard/Mouse Connector

    The WAFER-PV-D5252/D4252/N4552 is shipped with a keyboard/mouse Y-cable connector. The keyboard/mouse Y-cable connector connects to a keyboard/mouse connector on the WAFER-PV-D5252/D4252/N4552 and branches into two cables that are each connected to a PS/2 connector, one for a mouse and one for a keyboard. To connect the keyboard/mouse Y-cable connector please follow the steps below.

  • Page 68: Figure 4-13: Keyboard/Mouse Y-Cable Connection

    Step 3: Insert the cable connectors. Once the cable connector is properly aligned with the keyboard/mouse connector on the WAFER-PV-D5252/D4252/N4552, connect the cable connector to the on-board connectors. See Figure 4-13. Figure 4-13: Keyboard/mouse Y-cable Connection Step 4: Attach PS/2 connectors to the chassis. The keyboard/mouse Y-cable connector is connected to two PS/2 connectors.

  • Page 69: Four Serial Port Connector

    WAFER-PV-D5252/D4252/N4552 SBC 4.7.4 Four Serial Port Connector The 40-pin serial port connector connects the board connector to four DB-9 connectors. To install, please follow the steps below. Step 1: Locate the COM connector. The locations of the COM port connectors are shown in Chapter 4.

  • Page 70: Software Installation

    WAFER-PV-D5252/D4252/N4552 SBC Figure 4-15: Serial Device Connector 4.8 Software Installation All the drivers for the WAFER-PV-D5252/D4252/N4552 are on the CD that came with the system. To install the drivers, please follow the steps below. Step 1: Insert the CD into a CD drive connected to the system.

  • Page 71: Figure 4-16: Introduction Screen

    WAFER-PV-D5252/D4252/N4552 SBC Figure 4-16: Introduction Screen Step 3: Click WAFER-PV-D5252/D4252/N4552. Step 4: A new screen with a list of available drivers appears (Figure 4-17). Figure 4-17: Available Drivers Step 5: Install all of the necessary drivers in this menu. S t e p 0 :...

  • Page 72: Bios

    WAFER-PV-D5252/D4252/N4552 SBC Chapter BIOS Page 60...

  • Page 73: Introduction

    WAFER-PV-D5252/D4252/N4552 SBC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 74: Getting Help

    WAFER-PV-D5252/D4252/N4552 SBC Function Decrease the numeric value or make changes Page up Move to the next page Page down Move to the previous page Main Menu – Quit and do not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu --...

  • Page 75: Main

    WAFER-PV-D5252/D4252/N4552 SBC  Save & Exit – Selects exit options and loads default settings The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above. 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.

  • Page 76: Advanced

    WAFER-PV-D5252/D4252/N4552 SBC  System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

  • Page 77: Acpi Configuration

    WAFER-PV-D5252/D4252/N4552 SBC 5.3.1 ACPI Configuration The ACPI Configuration menu (BIOS Menu 3) configures the Advanced Configuration and Power Interface (ACPI) options. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced ACPI Sleep State [S1 (CPU Stop Clock)] Select the highest ACPI...

  • Page 78: Rtc Wake Settings

    WAFER-PV-D5252/D4252/N4552 SBC 5.3.2 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 4) configures RTC wake event. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Wake system with Dynamic Time [Disabled] Enable or disable System wake on alarm event. When...

  • Page 79: Cpu Configuration

    WAFER-PV-D5252/D4252/N4552 SBC 5.3.3 CPU Configuration Use the CPU Configuration menu (BIOS Menu 5) to view detailed CPU specifications and configure the CPU. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced CPU Configuration Processor Type Intel(R) Atom(TM) CPU N455 @1.66GHz...

  • Page 80: Ide Configuration

    WAFER-PV-D5252/D4252/N4552 SBC  Hyper-Threading [Enabled] Use the Hyper-Threading option to enable or disable Intel Hyper-Threading technology.  Disables Intel Hyper-Threading Disabled technology  Enables Intel Hyper-Threading Enabled EFAULT technology 5.3.4 IDE Configuration Use the IDE Configuration menu (BIOS Menu 6) to change and/or set the configuration of the IDE devices installed in the system.
  • Page 81 WAFER-PV-D5252/D4252/N4552 SBC  Compatible Configures the on-board ATA/IDE controller to be in compatible mode. In this mode, a SATA channel will replace one of the IDE channels. This mode supports up to 4 storage devices.  Configures the on-board ATA/IDE controller to be in...

  • Page 82: Usb Configuration

    WAFER-PV-D5252/D4252/N4552 SBC 5.3.5 USB Configuration Use the USB Configuration menu (BIOS Menu 7) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support. AUTO option...

  • Page 83: Super Io Configuration

    WAFER-PV-D5252/D4252/N4552 SBC  Enabled Legacy USB support enabled EFAULT  Legacy USB support disabled Disabled  Auto Legacy USB support disabled if no USB devices are connected 5.3.6 Super IO Configuration Use the Super IO Configuration menu (BIOS Menu 8) to set or change the configurations for the FDD controllers, parallel ports and serial ports.

  • Page 84: Serial Port N Configuration

    WAFER-PV-D5252/D4252/N4552 SBC 5.3.6.1 Serial Port n Configuration Use the Serial Port n Configuration menu (BIOS Menu 9) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced Serial Port 0 Configuration Enable or Disable Serial...
  • Page 85 WAFER-PV-D5252/D4252/N4552 SBC  IO=3F8h; Serial Port I/O port address is 3E8h and the interrupt IRQ=3, 4 address is IRQ3, 4  Serial Port I/O port address is 2F8h and the interrupt IO=2F8h; address is IRQ3, 4 IRQ=3, 4 5.3.6.1.2 Serial Port 2 Configuration ...
  • Page 86 WAFER-PV-D5252/D4252/N4552 SBC  Enabled Enable the serial port EFAULT  Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.  The serial port IO port address and interrupt address Auto EFAULT are automatically detected.
  • Page 87 WAFER-PV-D5252/D4252/N4552 SBC  IO=3E8h; Serial Port I/O port address is 3E8h and the interrupt IRQ=10, 11 address is IRQ10, 11  Serial Port I/O port address is 2E8h and the interrupt IO=2E8h; address is IRQ10, 11 IRQ=10, 11 5.3.6.1.5 Serial Port 5 Configuration ...
  • Page 88 WAFER-PV-D5252/D4252/N4552 SBC 5.3.6.1.6 Serial Port 6 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.  Disabled Disable the serial port  Enable the serial port Enabled EFAULT  Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.

  • Page 89: H/W Monitor

    WAFER-PV-D5252/D4252/N4552 SBC 5.3.7 H/W Monitor The H/W Monitor menu (BIOS Menu 10) shows the operating temperature, fan speeds and system voltages. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced PC Health Status CPU Temperature :+50 C SYS Temperature...

  • Page 90: Serial Port Console Redirection

    WAFER-PV-D5252/D4252/N4552 SBC  Voltages: VCC3V V_core V1_05V VCC3V VSB3V VBAT  CPU Smart Fan control [Auto Mode] Use the CPU Smart Fan control option to configure the CPU fan.  Auto Mode The fan adjusts its speed using these settings:...

  • Page 91: Bios Menu 11: Serial Port Console Redirection

    WAFER-PV-D5252/D4252/N4552 SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced COM1 Console Redirection Console Redirection [Disabled] Enable/Disable > Console Redirection Settings COM2 Console Redirection [Disabled] > Console Redirection Settings COM3 Console Redirection [Disabled] > Console Redirection Settings --------------------- : Select Screen...

  • Page 92: Iei Feature

    WAFER-PV-D5252/D4252/N4552 SBC 5.3.9 IEI Feature Use the IEI Feature menu (BIOS Menu 12) to configure One Key Recovery function. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced iEi Feature Auto Recovery Function Reboot and recover Auto Recovery Function...

  • Page 93: Chipset

    WAFER-PV-D5252/D4252/N4552 SBC 5.4 Chipset Use the Chipset menu (BIOS Menu 13) to access the Northbridge and Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 94: Host Bridge

    WAFER-PV-D5252/D4252/N4552 SBC 5.4.1 Host Bridge Use the Host Bridge menu (BIOS Menu 14) to configure the host bridge chipset. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset ******* Memory Information ******** Config On Chip VGA Memory Frequency...

  • Page 95: South Bridge

    WAFER-PV-D5252/D4252/N4552 SBC 5.4.2 South Bridge Use the South Bridge menu (BIOS Menu 15) to configure the Southbridge chipset. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset Auto Power Button Function [Disable (ATX)] Select AC power state Restore AC Power Loss...
  • Page 96 WAFER-PV-D5252/D4252/N4552 SBC  Enabled The onboard HD audio controller automatically EFAULT detected and enabled  The onboard HD audio controller is disabled Disabled  USB Function [Enabled] Use the USB Function BIOS option to enable or disable USB function support.

  • Page 97: Intel Igd Swsci Opregion

    WAFER-PV-D5252/D4252/N4552 SBC 5.4.3 Intel IGD SWSCI OpRegion Use the Intel IGD SWSCI OpRegion menu (BIOS Menu 16) to configure the video device connected to the system. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced Intel IGD SWSCI OpRegion Configuration...
  • Page 98 WAFER-PV-D5252/D4252/N4552 SBC  IGD - Boot Type [VBIOS Default] Use the IGD - Boot Type option to select the display device used by the system when it boots. Configuration options are listed below.  VBIOS Default EFAULT   ...

  • Page 99: Boot

    WAFER-PV-D5252/D4252/N4552 SBC 5.5 Boot Use the Boot menu (BIOS Menu 17) to configure system boot options. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Boot Configuration Select the keyboard Bootup NumLock State...
  • Page 100 WAFER-PV-D5252/D4252/N4552 SBC  Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.  Normal POST messages displayed Disabled  Enabled OEM Logo displayed instead of POST messages EFAULT  Launch PXE OpROM [Disabled] Use the Launch PXE OpROM option to enable or disable boot option for legacy network devices.

  • Page 101: Security

    WAFER-PV-D5252/D4252/N4552 SBC 5.6 Security Use the Security menu (BIOS Menu 18) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Password Description Set Setup Administrator Password If ONLY the Administrator’s password is set,...

  • Page 102: Bios Menu 19:Exit

    WAFER-PV-D5252/D4252/N4552 SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Save Changes and Reset Reset the system after Discard Changes and Reset saving the changes. Restore Defaults Save as User Defaults...

  • Page 103: Abios Options

    WAFER-PV-D5252/D4252/N4552 SBC Appendix BIOS Options Page 91...
  • Page 104 WAFER-PV-D5252/D4252/N4552 SBC Below is a list of BIOS configuration options in the BIOS chapter. 　 BIOS Information .........................63 　 System Date [xx/xx/xx] ......................64 　 System Time [xx:xx:xx] .......................64 　 ACPI Sleep State [S1 (CPU Stop Clock)] ................65 　 Wake System with Fixed Time [Disabled] .................66 　...
  • Page 105 WAFER-PV-D5252/D4252/N4552 SBC 　 IGD - Boot Type [VBIOS Default] ..................86 　 LCD Panel Type [VBIOS Default]..................86 　 Backlight Control [Inverted]....................86 　 Bootup NumLock State [On]....................87 　 Quiet Boot [Enabled] ......................88 　 Launch PXE OpROM [Disabled] ..................88 　 UEFI Boot [Disabled] ......................88 　...

  • Page 106: B Terminology

    WAFER-PV-D5252/D4252/N4552 SBC Appendix Terminology Page 94...
  • Page 107 WAFER-PV-D5252/D4252/N4552 SBC AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 108 WAFER-PV-D5252/D4252/N4552 SBC Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory. DIMM Dual Inline Memory Modules are a type of RAM that offer a 64-bit data bus and have separate electrical contacts on each side of the module.
  • Page 109 WAFER-PV-D5252/D4252/N4552 SBC Liquid crystal display (LCD) is a flat, low-power display device that consists of two polarizing plates with a liquid crystal panel in between. LVDS Low-voltage differential signaling (LVDS) is a dual-wire, high-speed differential electrical signaling system commonly used to connect LCD displays to a computer.

  • Page 110: C Digital I/O Interface

    WAFER-PV-D5252/D4252/N4552 SBC Appendix Digital I/O Interface Page 98...

  • Page 111: Introduction

    WAFER-PV-D5252/D4252/N4552 SBC C.1 Introduction The DIO connector on the WAFER-PV-D5252/D4252/N4552 is interfaced to GPIO ports on the Super I/O chipset. The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.

  • Page 112: Assembly Language Sample

    WAFER-PV-D5252/D4252/N4552 SBC C.2 Assembly Language Sample 1 AX, 6F08H ;setting the digital port as input AL low byte = value AH – 6FH Sub-function: AL – 9 :Set the digital port as OUTPUT :Digital I/O input value C.3 Assembly Language Sample 2 AX, 6F09H ;setting the digital port as output...

  • Page 113: D Hazardous Materials Disclosure

    WAFER-PV-D5252/D4252/N4552 SBC Appendix Hazardous Materials Disclosure Page 101...

  • Page 114: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    WAFER-PV-D5252/D4252/N4552 SBC D.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 115 WAFER-PV-D5252/D4252/N4552 SBC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl (CR(VI)) (PBB) Ethers (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies...
  • Page 116 WAFER-PV-D5252/D4252/N4552 SBC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

This manual is also suitable for:

Wafer-pv-d4252Wafer-pv-n4552

Table of Contents
