FTM-3100R
Advance Manual
VHF FM TRANSCEIVER
VOL
SQL
REV
M H z
V / M
TXPO
D W
M W
SETUP
DIAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FTM-3100R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yaesu FTM-3100R

Summary of Contents for Yaesu FTM-3100R

  • Page 1 FTM-3100R Advance Manual VHF FM TRANSCEIVER DIAL M H z V / M TXPO SETUP...

  • Page 2: Table Of Contents

    Scanning the programmable memory channels ............20 Band Edge Beeper ....................... 20 Priority Channel Scanning (Dual Watch) ..............21 Priority Revert Mode ....................21 Clone ..........................22 Setup (Menu) Mode ...................... 23 Menu Selection Details ....................26 FTM-3100R Advance Manual...

  • Page 3: Basic Operation

    (S1 - S8 or OFF). Default: OFF 4. Press and hold in the [ MHz ( SETUP )] key for one second to save the new setting and exit to normal operation. FTM-3100R Advance Manual...

  • Page 4: Advanced Operation

    Programming the Key Assignments Default FTM-3100R key functions have been assigned to the Microphone [ P1 ] / [ P2 ] / [ P3 ] / [ P4 ] keys at the factory. The user may change these key function assignments, if quick access to another function is desired.

  • Page 5: Split Tone Operation

    Advanced Operation Split Tone Operation The FTM-3100R can be configured to operate in a “Split Tone” system via the Setup menu, to facilitate operation on repeaters using a mix of both CTCSS and DCS control. 1. Press and hold in the [ MHz ( SETUP )] key for one second to enter the Set mode.

  • Page 6: Tone Search

    3. Press the [ MHz ( SETUP )] key, and then rotate the DIAL knob to select “TSQL”. 4. Press and hold in the [ MHz ( SETUP )] key for one second to save the new setting and exit to normal operation. FTM-3100R Advance Manual...

  • Page 7: Dcs Search

    3. Press the [ MHz ( SETUP )] key, and then rotate the DIAL knob to select “DCS”. 4. Press and hold in the [ MHz ( SETUP )] key for one second to save the new setting and exit to normal operation. FTM-3100R Advance Manual...

  • Page 8: Epcs (Enhanced Paging & Code Squelch) Operation

    6. Press and hold in the [ MHz ( SETUP )] key for one second to lock in that tone and exit to normal operation. Note: The FTM-3100R does not recognize the order of the 1st tone and the 2nd tone. In other words, for example, the FTM-3100R considers both CTCSS pairs “05, 47”...

  • Page 9: Activating The Enhanced Paging & Code Squelch System

    5. To disable the Enhanced Paging & Code Squelch, just repeat the above procedure, rotating the DIAL knob to select “OFF” in step 3 above. When the Enhanced Paging & Code Squelch feature is activated, the “P” notation will appear on the right of the frequency display. FTM-3100R Advance Manual...

  • Page 10: Dtmf Operation

    DTMF Operation DTMF tones (Dual Tone Multi Frequencies) are the tones you hear when dialing from a telephone keypad. The FTM-3100R transceiver can transmit the DTMF codes by using the keys on the microphone or recalling registered number strings from memories.

  • Page 11: Registering A Dtmf Code

    7. When entry of all digits is complete, press and hold in the [ MHz ( SETUP )] key for one second to set the DTMF code and exit to normal operation. FTM-3100R Advance Manual...

  • Page 12: Transmitting The Registered Dtmf Code

    DIAL knob to select the desired speed (“50 MS”: High speed or “100 MS”: Low speed). 4. Press and hold in the [ MHz ( SETUP )] key for one second to save the new setting and exit to normal operation. FTM-3100R Advance Manual...

  • Page 13: Setting Dtmf Autodialer Tx Delay Time

    (50 MS / 250 MS / 450 MS / 750 MS / 1000 MS). Default: 450 MS 4. Press and hold in the [ MHz ( SETUP )] key for one second to save the new setting and exit to normal operation. FTM-3100R Advance Manual...

  • Page 14: Memory Operation

    To place the radio into the Memory Only mode, turn the transceiver OFF. Now press and hold in the [ V/M ( MW )] key while turning the transceiver ON. The VFO and Home Channel will now be disabled. To return to normal operation, repeat the above power-on procedure. FTM-3100R Advance Manual...

  • Page 15: Naming A Memory Channel

    [ V/M ( MW )] key for one second to save the label and exit. While operating in the Memory Recall mode, press the [ MHz ( SETUP )] key to toggle the display between indication of the frequency, and indication of the Alpha/Numeric label. FTM-3100R Advance Manual...

  • Page 16: Scanning

    DIAL knob to select the desired scan-re- sume mode. Default: 5.0 SEC 4. Press and hold in the [ MHz ( SETUP )] key for one second to save the new setting and exit to normal operation. FTM-3100R Advance Manual...

  • Page 17: Memory Skip Scanning

    “OFF” in step 4 above, after first recalling the currently blocked channel (the “Skipped” channel is accessible via manual channel selection methods using the DIAL knob in the Memory mode, whether or not it is locked out of the scanning loop). FTM-3100R Advance Manual...

  • Page 18: Preferential Memory Scan

    Scanning Preferential Memory Scan The FTM-3100R also allows setting up a “Preferential Scan List” of channels, which you can “flag” within the memory system. The flagged channels are designated by an “ ” icon when they are selected, one by one, for the Preferential Scan List.

  • Page 19: Programmable Memory Scan (Pms)

    Scanning Programmable Memory Scan (PMS) The FTM-3100R can be set to tune or scan only the frequencies between user-defined lower and band limits. Example: Set up a PMS channel by registering a lower frequency of 144.300 MHz, and an upper frequency of 148.000 MHz to the L1/U1 memory channels.

  • Page 20: Scanning The Programmable Memory Channels

    MH-48A6JA Microphone. Band Edge Beeper The FTM-3100R will automatically “beep” when the receive band edge is encountered during scanning (either in standard VFO scanning or during PMS operation). Additionally, the band edge beep feature may be enabled to sound when the band edge frequency is reached while tuning the VFO, using the DIAL knob.

  • Page 21: Priority Channel Scanning (Dual Watch)

    Scanning Priority Channel Scanning (Dual Watch) The FTM-3100R’s scanning features include a two-channel scanning capability which allows operating on a VFO, Memory channel, or Home channel, while periodically checking a user- defined Memory Channel for activity. If a station received on the Memory Channel is strong enough to open the Squelch, the scanner will pause on that station in accordance with the Scan-Resume mode setting of Menu item “SCAN RSM 31.”...

  • Page 22: Clone

    Clone The FTM-3100R includes a convenient “Clone” feature, which allows the memory and configuration data from one transceiver to be transferred to another FTM-3100R. This can be particularly useful when configuring a number of transceivers for a public service operation.

  • Page 23: Setup (Menu) Mode

    Setup (Menu) Mode The FTM-3100R Setup (Menu) mode, already described in parts of many previous chapters, is easy to activate and setup. The Menus may be used to configure many of transceiver parameters, some of which have not been detailed previously. Use the following procedure to activate the Setup (Menu) mode: 1.
  • Page 24 67.0 to 254.1 (Hz) 100.0 HZ 38: TOT Sets the Time-Out Timer. 0.5 to 10.0 (MIN)/OFF 3.0 MIN Enables/Disables the receiver audio out- 39: TS MUTE put while the Tone Search or DCS Search ON/OFF Scanner is activated. FTM-3100R Advance Manual...
  • Page 25 Selects the audio output level of the 43: WX VOL NOR VOL/MAX VOL NOR VOL Weather Alert. Reduction of the Microphone Gain/Devia- 44: W/N DEV WIDE/NARROW WIDE tion and receiver bandwidth. ø: Depends on the transceiver version. FTM-3100R Advance Manual...

  • Page 26: Menu Selection Details

    Available Values: A / B Default: A This function is only used to move a spurious response “birdie”, should it fall on a desired frequency. Select “A” for the normal operation. 7 DC VOLT Function: Indicates the DC Supply Voltage. FTM-3100R Advance Manual...

  • Page 27: Dcs Code

    Function: Enables/disables the “Priority Channel Revert” feature. Available Values: ON / OFF Default: OFF See page 21 for details. 15 LCD DMMR Function: Setting of the front panel display’s illumination level. Available Values: LEVEL 1 - LEVEL 4 Default: LEVEL 4 FTM-3100R Advance Manual...
  • Page 28 6. When the desired opening message is completed, press the [ TXPO ] key momentarily to confirm the message, then press and hold in the [ MHz ( SETUP )] key for one second to save the settings and exit to normal operation. FTM-3100R Advance Manual...
  • Page 29 Set mode items (except Set mode items #23 through 26; initial setting is “Set mode item #32 SCAN SKP”). Default: Depends on the transceiver version. 27 RF SQL Function: Adjusts the RF Squelch threshold level. Available Values: S1 - S8 / OFF Default: OFF FTM-3100R Advance Manual...
  • Page 30 “PAGER” parameter when configuring Set Mode Item “34 SQL TYPE”: D CODE: DCS Encode only. T DCS: Encodes a CTCSS tone and Decodes a DCS code. D TONE: Encodes a DCS code and Decodes a CTCSS tone. FTM-3100R Advance Manual...
  • Page 31 The time-out timer shuts off the transmitter after continuous transmission of the programmed time. 39 TS MUTE Function: Enables/Disables the receiver audio output while the Tone Search or DCS Search Scanner is activated. Available Values: ON / OFF Default: ON FTM-3100R Advance Manual...
  • Page 32 Function: Selects the audio output level of the Weather Alert. Available Values: NOR VOL / MAX VOL Default: NOR VOL 44 W/N DEV Function: Reduction of the Microphone Gain/Deviation and receiver bandwidth. Available Values: WIDE / NARROW Default: WIDE FTM-3100R Advance Manual...
  • Page 33 YAESU MUSEN CO., LTD. All rights reserved. No portion of this manual YAESU MUSEN CO., LTD. may be reproduced Tennozu Parkside Building without the permission of 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan YAESU MUSEN CO., LTD. YAESU USA 6125 Phyllis Drive, Cypress, CA 90630, U.S.A.
