Yaesu FTM-3100R Quick Manual

FTM-3100R
Quick Manual
1 2 3
VOL
DIAL
REV M H z V / M
SQL TXPO
D W M W
SETUP
10 9 8 7 6 5 4
1 VOL knob
2 LCD display
3 DIAL knob
4 Power/LOCK key
5 V/M MW key ( )
6 MHz SETUP key ( )
7 TXPO key ( )
TXPO
8 REV DW key ( )
9 SQL key ( )
SQL
10 External MIC jack
Rotate the volume clockwise/counterclockwise to adjust
the volume level.

Tuning in to the frequency

Press to switch to VFO mode, then rotate the DIAL.
Press to make the first three digits of the frequency
display blink, then rotate the DIAL to set the frequency
by one MHz increments.

Changing the transmit power level

Press , then rotate DIAL to select the transmit pow-
TXPO
er level.
Press to set the transmit power level.
TXPO

Restoring defaults (All Reset)

All transceiver settings and memory content may be
restored to the default settings.
Turn the power OFF.
While pressing
ON.
When "ALL RESET PUSH V/M KEY" appears, release
the keys.
Press to reset.

Locking the keys and DIAL

Press Power/LOCK to lock the keys and knobs.
Press Power/LOCK again to unlock.
EH052N560

Adjusting the volume

"HIGH" à "LOW" à "MID"
, , and , turn the power
TXPO

Returning to the operating screen

Press and hold for over one second to return to the
operating screen from the Setup menu.
Supplements • Press to return to the previous
screen.
• Press and hold
ond to return to the operating screen.
for over one sec-
