Set Applies the setting to the selected port
Group Lets you select the ports to group in VLANs and Port
Trunk

LED indicators

The following table describes the meaning of the LEDs:
LED
Power On (green)
Off
VLAN On (green)
On (orange)
Off
TRUNK On (green)
On (orange)
Off
LINK/ACT On (green)
On (flashing
green)
Off
100Mbps On (green)
Off
FDX/COL On (green)
On (flashing
orange)
Off
Expansion On (green)
slot Off
VLAN On (green)
group 1 - 6
Off
State
The unit is receiving power.
The unit is not receiving power.
Indicates VLAN is configured
VLAN is being configured.
VLAN is not configured.
Port Trunk is configured.
Port Trunk is being configured.
Port Trunk is not configured.
Link is established
Packet transmit or receive activity
No Link activity
The connection speed is 100 Mbps.
The connection speed is 10 Mbps.
Full-duplex mode
Collision has occurred
Half-duplex mode
Expansion module installed
No expansion module installed
The selected VLAN group is being
configured.
The VLAN group is not selected.
3
Introduction
MEANING
