4/8 CHANNEL DVR
User Manual
SRD-494/894

Advertisement

Table of Contents
loading

Related Manuals for Samsung SRD-494

Summary of Contents for Samsung SRD-494

  • Page 1 4/8 CHANNEL DVR User Manual SRD-494/894...
  • Page 2 Disclaimer Samsung makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user's own responsibility. Samsung reserves the right to change the contents of this document without prior notice.
  • Page 3 overview IMPORTANT SAFETY INSTRUCTIONS Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water.

  • Page 4: Overview

    • SAMSUNG retains the copyright on this manual. • This manual cannot be copied without SAMSUNG’s prior written approval. • We are not liable for any or all losses to the product incurred by your use of non-standard product or violation of instructions mentioned in this manual.
  • Page 5 Operating Temperature The guaranteed operating temperature range of this product is 0°C ~ 40°C (32°F ~ 104°F). This product may not work properly if you run right after a long period of storage at a temperature below the guaranteed one. Prior to using a device that has been stored for a long period in low temperatures, allow the product to stand at room temperature for a period.

  • Page 6: Table Of Contents

    overview CONTENTS OVERVIEW Important Safety Instructions Before Start Contents Features Part Names and Functions (Front) Part Names and Functions (Rear) Remote Control INSTALLATION Checking the installation environment Rack Installation Installing The HDD CONNECTING WITH OTHER DEVICE Connecting External Devices Connecting the Network Getting Started LIVE Live Screen Configuration...
  • Page 7 Search SEARCH & PLAY Playback WEB VIEWER Introducing Web Viewer Connecting Web Viewer (Windows) Using Live Viewer (Windows) Controlling a Connected PTZ Camera 102 Using Search Viewer 105 Viewer Setup 117 Information 118 Connecting Web Viewer (Mac) 120 Using Live Viewer (Mac) 121 Mobile Viewer 122 SEC Backup Viewer BACKUP VIEWER...
  • Page 8 overview FEATURES The product compresses camera inputs from 4/8 channels with H.264 video codec, and supports simultaneous recording and playback of 4/8-channel audio input to/from HDD. These DVRs also supports network connectivity, providing remote monitoring from a remote PC transferring video and audio data.

  • Page 9: Contents

    Please check the following contents are included in addition to the main unit.  The appearance of the components may differ from the image shown.  Accessory category and quantity may differ depending on sales region. SRD-494 ALARM NETWORK BACKUP POWER Adapter Remote Control /...
  • Page 10 overview SRD-894 Power Cable Remote Control / Mouse User Manual or Quick Manual Remote Control Battery (AAA) Network Viewer Software / Terminal Block (15 pin) Terminal Block (20 pin) User Manual CD Bracket Fixing Screw Bracket Rack HDD Fixing Screw SATA Power Cable SATA Data Cable 10_ overview...

  • Page 11: Part Names And Functions (Front)

    LED Indicator NETWORK : Displays both network connection and data transfer status. BACKUP : Displays when Backup is in progress. (SRD-494) POWER : Displays the power ON/OFF status. Used to change a value or move the cursor up/down/left/right (◄ ►).
  • Page 12 overview Part Names Functions Used to turn the DVR ON/OFF. Power  Functions only if the button was held for 3 seconds. USB Port Connects the USB devices. Each time you press the button in Live mode, the screen mode will be switched in sequence. MODE Each time you press the button in play mode, the screen mode will be switched in sequence.

  • Page 13: Part Names And Functions (Rear)

    PART NAMES AND FUNCTIONS (REAR) SRD-494 2 3 4 ALARM IN ALARMRESET POWER VGA OUT AUDIO OUT CONSOLE SERIAL DC12V HD VIDEO IN AUDIO IN ALARM OUT SRD-894 VIDEO IN AUDIO IN AUDIO OUT NETWORK SERIAL NC NO AUDIO IN CH5 ~ CH8...
  • Page 14 Part Names Functions eSATA Ports used for external storage device connections. - ALARM IN : Alarm Input port. SRD-494 : 1~4 CH SRD-894 : 1~8 CH ALARM - ALARM RESET : Alarm Reset port. - ALARM OUT : Alarm Output port.

  • Page 15: Remote Control

    REMOTE CONTROL POWER Starts or ends the live recording. Displays the Exit pop up screen. NUMBER [0~ + 10] Used as the numeric input keys, or displays a single channel. Sets the ID of the system. Select 2 digits from 0 ~ 9 while pressing the ID Key. Displays or ends PTZ.
  • Page 16 overview Using the Numeric buttons 1. Press any button among 1 to 8. 2. Move to the selected channel number. Changing the Remote Control ID Remote control’s ID and DVR’s ID should be matched for proper operation. 1. Press the [ID] button of the remote control and check the ID displayed on the DVR screen. The factory default ID of the remote control is 00.

  • Page 17: Installation

    installation Please take note of the followings before using this product. • Do not use the product outdoor. • Do not spill water or liquid in the connection part of the product. • Do not impose the system to excessive shock or force. •...

  • Page 18: Rack Installation

    installation RACK INSTALLATION Install the Bracket-Rack as shown in the figure, and then fasten the screws on both sides (2 screws on each side).  Remove the screws on the left and right side of the DVR before installation.  Fix the screws not to be loosened by vibrations.
  • Page 19 Installing the HDD  If the installed HDD had been used with other devices, it will be automatically formatted. • If installing HDDs to SRD-494 1. Unfasten the screws on the side and in the rear and remove the cover.
  • Page 20 installation 4. Press the bracket where the HDD is mounted and fix it in with screws. 5. Close the cover and use the screws to fix it. 20_ installation...
  • Page 21 • If installing HDDs to SRD-894 1. First, loosen the screws on both sides and remove the cover. 2. Loosen the screws (x4) in the left/right and upper sides and remove the upper brackets. Bracket AUDIO VIDEO AUDIO SERIAL AUDI O IN CH5 ~ NETWO...
  • Page 22 installation 4. When the installation of additional HDDs is done, insert the brackets into the DVR and fix them with the provided screws. AUDI O IN VIDE O AUDI O AUDI O SERIA AUD IO IN CH5 ~ CH8 NETW CONS eSATA HDM I...

  • Page 23: Connecting With Other Device

    connecting with other device CONNECTING EXTERNAL DEVICES  The following figures are based on Model SRD-894. AC 100-240V~IN ~ CH 8 IN CH 5 AU DIO HDMI VIDEO IN VIDEO OUT (VGA) AUDIO IN AUDIO OUT AUDIO IN SPOT1/2 eSATA HDD Connecting the USB 1.
  • Page 24 Connection setup for the RS-232C port is available in “Main Menu > Device > POS Devices”, press the <POS Device Setup> button and set <Baudrate, Parity, Data, Stop bit>. (Page 58) Connecting the Alarm Input/Output The Alarm In/Out port at the back is composed of the following. SRD-494 AL AR M SE T ALA RM RE...
  • Page 25 SRD-894 ~ CH 8 IN CH 5 AU DIO 4 5 6 1 2 3 NEC TIO NO CON AL AR M Sensors Alarm • ALARM IN 1 ~ 8 : Alarm Input Port • ALARM RESET : On receiving an Alarm Reset signal, the system cancels the current Alarm Input and resumes sensing.

  • Page 26: Connecting The Network

    connecting with other device Connecting the RS-485 Device Connect the [TX/RX +, –] device through the back port. ~ CH 8 IN CH 5 AU DIO system keyboard PTZ camera  You can connect and control the PTZ camera which supports the RS-485 communication. ...
  • Page 27 Connecting to the Network using the router ~ CH 8 IN CH 5 AU DIO Broadband Router xDSL or Cable Modem xDSL or Cable Modem NETWORK External Remote PC DDNS Server (Data Center) Connecting to Network through PPPoE RJ-45 Ethernet Cable (Direct Cable) ~ CH 8 IN CH 5...

  • Page 28: Live

    live GETTING STARTED Starting the system 1. Connect power cable to the product’s rear. 2. Touch and hold the front power button for over 3 seconds.  It takes about 10 seconds to display the start screen after booting. 3. The boot up screen appears. Booting up may take about 3 minute, as indicates progress with icons.
  • Page 29 Shutting Down the System You can shut down the system only if you have logged in to the DVR. You require permission to shut down the system if you are not logged in as admin. 1. Hold the [POWER] button on the front or the remote 2015-01-01 01:10:25 control for over 3 seconds, or right click and click <Shutdown>.
  • Page 30 live  The default administrator ID is “admin”, and the password must be set when the user log in at the first time.  Set password for your wireless network if you use the product with a wireless router. Being not protected with password or using the default wireless router password may expose your video data to potential threat.

  • Page 31: Live Screen Configuration

    LIVE SCREEN CONFIGURATION Icons on the Live Screen You can check the status or operation of the DVR with the icons on the live screen. 2015-01-01 01:10:25 CAM 01 CAM 01 Part Names Functions Current Date, Time Displays the current time and date. Login Information When you are logged in, the “LOG ON”...
  • Page 32 live Part Names Functions Displayed if no input is entered in the condition that the camera is set to <ON>. Video Input Status Nothing will be displayed on the screen if the camera is set to <OFF>. Camera Name/ Channel Displays the camera name and the changed channel, if any.
  • Page 33 Live Screen Menu In addition to the buttons on the front panel or the remote control, you can access a desired menu by right- clicking the mouse any area in live mode. Right click opens the context menu which shows different menu items according to the situation, such as logged in/out state, split screen mode, and various operational conditions.
  • Page 34 live Split Mode Menu The context sensitive menu in split mode differs, depending on the login/logout status. Scene Mode  2015-01-01 01:10:25  Spot Out 1 Spot Out 2  Audio Off Freeze Stop Alarm Record Play Search Backup Main Menu Shutdown Hide Launcher Logout...
  • Page 35 Single Mode Menu The single mode menu is available only in Single Mode. The menu, which appears as <Screen Mode> on a single screen, appears as <Full Screen> after selecting only one channel on a split screen. 2015-01-01 01:10:25 2015-01-01 01:10:25 Scene Mode ...
  • Page 36 If no input is entered for 10 seconds, the menu will disappear.  The Launcher menu can be accessed only by using the mouse.  SRD-494 supports the 4-split screen mode PIP and Auto Sequence only. 2015-01-01 01:10:25 2015-01-01 01:10:25...

  • Page 37: Live Mode

    Press the [MODE] button on the front panel or the remote control to switch the mode in the sequence of the launcher menu items.  SRD-494 supports the 4-split screen mode PIP and Auto Sequence only. 9-split mode 4-split mode...
  • Page 38 live Manual Switching Press the left/right button on the front panel or the remote control, or click the arrow <◄/►> key to move to the next split mode. • If pressing the right [►] button in 4-split mode : Channel (CH 1~4)  Channel (CH 5~8)  Auto Sequence Channel Setting You can display the channel in a desired area of a split screen.

  • Page 39: Spot Out

    SPOT OUT The Spot Out monitoring is independent of the Live mode, which monitors a specific channel through the Spot Out port. Selecting a Spot Out mode If an event occurs such as sensor, motion or alarm from the Spot Out port in connection with a monitor, you can select a output screen mode.

  • Page 40: Audio On/Off

    live AUDIO ON/OFF You can turn the sound on/off corresponding to the channel in Live mode. AUDIO ON/OFF in Single mode Click the audio icon ( ) on the screen, or press the [AUDIO] button on the front panel or the remote control to turn it on/off.

  • Page 41: Event Monitoring

    EVENT MONITORING This will display the channel in sync with a specific event (Sensor/Motion/Video Loss/Tampering) if it occurs. In “Monitor > Event Display”, set the event monitoring to ON/OFF and specify the event display time. (Page 60) • If multiple events occur simultaneously, the screen will switch to a split mode. - 2~4 events : 4-split mode - 5~9 events : 9-split mode •...

  • Page 42: Main Menu

    main menu You can setup the system properties, devices, and options for recording, event, backup and network. SYSTEM SETUP You can setup Date/Time/Language, Permission, System Properties and Log. Date/Time/Language You can check and setup the current Date/Time and time related properties, as well as the language used for the interface on the screen.
  • Page 43 - Time Server : Enter an IP or URL address of the time server. Date/Time/Language - Last Sync Time : Displays the most recent synchronization Date/Time/Language Holiday time from the selected time server. Date Time Synchronization Setup 2015 -01-01 YYYY-MM-DD - Activate as Server : Set to <Use>...
  • Page 44 main menu Permission Management You can set permissions of each user over the DVR's specific function and settings. Setting the Administrator You can set and change Administrator’s ID and password. The administrator can use and set all menu items and functions. Using the mouse may help make setup easier.
  • Page 45 Setting the Group You can create user groups and setup permissions for those user groups. You can register a user for each group in <User>. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <System> window to Permission Management move to <Permission Management>, and press Group...
  • Page 46 main menu To restrict the user permissions If the admin restricts all permissions of an added group, the users belonging to that group can access only the default minimum menus and can change the user’s own password only. 1. Start the DVR. If all permissions are restricted, only the Login dialog should appear.
  • Page 47 Setting the User You can add a user and edit information of a registered user. Users can be added only if a group was created in <Group> menu. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <System> window to Permission Management move to <Permission Management>, and press User...
  • Page 48 main menu • Manual Input of ID : Prompts you to enter the user ID manually for the login process. - Checked ( ) : Encloses the registered user IDs with the [  ] symbols. Login Use the virtual keyboard to enter the user ID. ***** Password •...
  • Page 49 • Updating the Software 1. Connect a device storing the software to be updated. (It may take about 30 seconds to recognize the device.)  Upgradeable devices include USB memory and network device.  To update the network, the current DVR should have been connected to the network. Upgrade via the proxy server may not be enabled due to the restricted access.
  • Page 50 main menu Settings You can copy and import the DVR settings by using a storage media. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <System> window to System Management move to <System Management>, and press [ENTER] Settings System Information button.
  • Page 51 Log Information You can browse logs on the system and events. System Log System Log shows log and timestamp on every system start up, system shutdown, and changes on system settings. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <System> window to Log Information move to <Log Information>, and press [ENTER] button.

  • Page 52: Setting The Device

    main menu SETTING THE DEVICE You can setup Camera, Storage Device, Remote Device, POS Device and Monitor. Camera Setting the Camera You can set Video, Audio, Channel Name and Dwell Time of a Camera. Using the mouse may help make setup easier. 1.
  • Page 53 • SEQ-Dwell Time : You can set the dwell time between channels for the Live screen and Spot Out.  If set to <OFF>, the channel is not listed in the Auto Sequence mode. • Type : Displayed the HD/SD type according to the camera connected. •...
  • Page 54 main menu Setting the PTZ To use Camera’s PTZ functions, ID and protocols of each camera and DVR should be matched. For other settings, refer to the <Remote Device> settings. (Page 58) Using the mouse may help make setup easier. 1.
  • Page 55 Storage Device You can check information on storage devices. Confirming Devices You can check storage devices and their free space, usage as well as status. Devices available are HDD, and USB devices (Memory, HDD). Using the mouse may help make setup easier. 1.
  • Page 56 main menu Formatting You can format a storage device. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Device> window to Storage Device move to <Storage Device>, and press [ENTER] button. Format Device HDD Alarm 2.
  • Page 57 HDD Alarm You can set alarm settings for HDD defects such as Check Alarm Output Port, Replace Alarm Output Port, and its duration. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Device> window to Storage Device move to <Storage Device>, and press [ENTER] button.
  • Page 58 main menu Remote Devices You can set the RS-485 communication for use of PTZ Camera and system keyboard with the DVR. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Device> window to Remote Device move to <Remote Device>, and press [ENTER] button.
  • Page 59 • POS Device Setup : Sets the communication setups for the POS Device POS device and DVR. POS USE POS Device Setup  It is independent to the Remote Device setup. Preset  Port/Ethernet None No preset None  POS Device Setup None No preset None...
  • Page 60 main menu Monitor You can configure information to be displayed and its format for Spot Out monitor. Setting the Monitor Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Device> window to Monitor move to <Monitor>, and press [ENTER] button. Monitor Spot Out Mode...
  • Page 61 Setting the Spot Out You can set the DVR to output information / video apart from the monitor out. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Device> window to Monitor move to <Monitor>, and press [ENTER] button. Spot Out Monitor Mode...

  • Page 62: Setting The Recording

    main menu SETTING THE RECORDING You can setup scheduled recording, event recording and other recording related settings. Recording Schedule Make your reservation on a date and time to schedule the recording on specified time. Using the mouse may help make setup easier. 1.
  • Page 63 Recording Color Tags Color Part Names Functions White No Recording No schedule / event recording Orange Continuous Scheduled recording only Blue Event Event recording only Green Both(Cont&Evnt) Both scheduled / event recordings Each press of a selected cell will cycle through <No Recording>-<Continuous>-<Event>- <Both(Cont&Evnt)>.
  • Page 64 main menu Setting Event Recording Properties You can set each channel’s resolution, quality and FPS for event recordings. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Record> window to REC Quality & Resolution move to <REC Quality &...

  • Page 65: Setting The Event

    SETTING THE EVENT You can set recording options when sensor, motion, video loss detection or tampering event occurs. Sensor Detection You can set the sensor’s operating condition and connected camera, as well as alarm output and its duration. Using the mouse may help make setup easier. 1.
  • Page 66 main menu Motion Detection You can set target detection region and motion, as well as the alarm signal output. When the motion detection region is set, it detects motion within the area. Using the mouse may help make setup easier. 1.
  • Page 67 Video Loss Detection You can set the alarm to be generated on a camera disconnection, which causes a video loss. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Event> window to Video Loss Detection move to <Video Loss Detection>, and press [ENTER] button.

  • Page 68: Backup

    main menu Alarm Schedule You can set the conditions and operating hours for scheduled alarms. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Event> window to Alarm Schedule move to <Alarm Schedule>, and press [ENTER] button. Alarm1 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 2.
  • Page 69 If you need to install a codec in Windows, run the x264_dvr.exe file in the codec folder that is created when you back up an AVI file. - SEC : Saves data in the Samsung’s proprietary format with built-in viewer, which supports immediate playback on a PC.

  • Page 70: Network Configuration

    main menu NETWORK CONFIGURATION It provides networked monitoring of Live screen from a remote place, and supports mail forwarding function with events. You can configure the network environment which enables such functions. Connection Mode You can set the network connection route and protocol. Setting the Connection Sets the protocol and environment of the network.
  • Page 71 • IP Address, Gateway, Subnet Mask, and DNS Connection Mode - For <Static> : You can directly input IP Address, Gateway, Interface Port Alarm Subnet Mask and DNS. IP Type PPPoE Transfer Bandwidth 600kbps - For <DHCP> : IP Address, Gateway, and Subnet Mask IP Address 192.168.1.200 are set automatically.
  • Page 72 main menu Alarm setting 1. In the <Network> setting window, press the top down Connection Mode (▲▼) button to move to the <Connection Mode> mode Alarm Interface Port and press the [ENTER] button. Disconnect Alarm Output Port BEEP 2. Select the <Alarm> menu. Duration 3.
  • Page 73 Notification  In a multi-browser environment, the <HTTP Port> should be set to 80 (private port). Select one between 4505 and 4530 for RTSP • Network Overview Cable/ADSL Router (External IP: 109.112.92.133, Modem Local IP: 192.168.1.1 Internet DDNS Server (www.samsungipolis.com) DVR 1 DVR 2 Local PC...
  • Page 74 main menu • 1st Set Port Forwarding Setting Port Forwarding is 4520~4524 (4520, 4521, 4522, 4523, 4524) Port Forwarding is 80 SRD-894 SRD-894 192. 168. 1. 200 192. 168. 1. 200 4520 4520 • 2nd Set Port Forwarding Setting Port Forwarding is 4525~4529 (4525, 4526, 4527, 4528, 4529) Port Forwarding is 81 SRD-894...
  • Page 75 Connecting and Setting the Network Networking may differ from the connection method, check your environment before setting the connection mode. When no router is used • Static mode - Internet connection : Static PPPoE, leased line, and LAN environments allows connection between the DVR and remote user.
  • Page 76 main menu When a router is used  To avoid IP address conflict with the DVR's static IP, check followings : • Setting the DVR with a static IP - Internet connection : You can connect the DVR to a router which is connected to an ADSL/Cable modem or a router in a Local Area Network (LAN) environment.
  • Page 77 • Setting Router’s Port Forwarding 1. Set the protocol to <TCP>. Connection Mode Port 2. External Port Range : Enter the TCP Port set in the Interface Alarm <Device Port> in <Port> menu of the connected DVR. Protocol Type Device Port 4520 4524 If more than one DVRs are connected to the router, the...
  • Page 78 DDNS Site : iPOLiS • DDNS Settings of the Router Select the corresponding menu for the network transfer protocol of the router. • SETTING UP SAMSUNG iPOLiS DDNS Go to Your PC 1. Open your browser and go to http://www.samsungipolis.com and click <LOGIN>.
  • Page 79 Quick Connect Not Used DDNS Host Address http://www.samsungipolis.com/ Cancel 3. Under Product ID, enter the product ID you created on the DDNS Samsung iPOLiS website. Under Quick Connect, select <Use> and click <OK>. DDNS Site iPOLiS Server Name www.samsungipolis.com Product ID...
  • Page 80 main menu Live Transfer Sets the quality of the image that is transferred from the DVR to the network. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Network> window to Live Transfer move to <Live Transfer>, and press [ENTER] button. The Live Transfer window appears.
  • Page 81 • Sender Address : Use the virtual keyboard to enter the sender’s e-mail address.  Refer to “Using Virtual Keyboard”. (Page 44) • E-mail Test : Conducts the test on the server settings. 4. When the SMTP setup is done, press <OK>. Event Setting You can set the interval and type of the event that will be sent to the user.
  • Page 82 main menu Recipient Setting You can add/remove a recipient(s) to/from the specified group and edit the group if necessary. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Network> window to Mailing Service move to <Mailing Service>, and press [ENTER] button. Recipient SMTP Event...

  • Page 83: Controlling A Ptz Device

    CONTROLLING A PTZ DEVICE The DVR enables you to adjust the settings of a PTZ camera as well as an ordinary one to your preference. PTZ Device The PTZ device can be activated only if a channel in connection with the PTZ camera is selected. Getting started with PTZ The PTZ camera is available, only if a channel is selected, in the following way : ...
  • Page 84 main menu Using the PTZ camera You can use one camera to perform all functions of PAN, TILT and ZOOM for monitoring multiple places and set the preset to your preference in a desired mode. 1. Launch the <PTZ Control> menu. 2015-01-01 01:10:25 As the <...
  • Page 85 • Select <Camera Setup> in the PTZ Control menu. 2015-01-01 01:10:25 The camera-specific menu appears.  You can configure the settings of those cameras that support the protocols of Samsung-E/Samsung-T/Pelco-D/Pelco-p/Panasonic/ Phillips/AD/DIAMOND/ERNA/KALATEL/VCL TP/VICON/ELMO/GE. Camera Setup  If you are setting Auto Pan or Pattern in the camera menu, press and hold the appropriate button for a certain time so that the ...

  • Page 86: Search & Play

    search & play SEARCH You can perform the search for recorded data by the time or by the search criteria such as an event. You can access the <Search> menu directly in Live mode. 1. In Live mode, right-click any area of the screen. 2015-01-01 01:10:25 The Live menu appears.
  • Page 87 • Zoom In : The map enlarges in detail. Time Search It will switch in the sequence of 24 hours - 16 hours - 8 hours 2015-01-01 Go to First Go to Last - 4 hours. Overlapped Data List1 Zoom In Zoom Out 00:01 •...
  • Page 88 search & play POS Search You can search for data in the POS device that is connected to the DVR. You can use the mouse to select the related items. 1. Select <POS Search> in the <Search> menu. POS Search 2.

  • Page 89: Playback

    PLAYBACK Play You can play data stored in the HDD and backup a desired portion of the data. Using the mouse may help make setup easier. 1. In Live mode, click <Play> in the right-click menu or 2015-01-01 01:10:25 < >...
  • Page 90 search & play Using the Playback Button Part Names Functions Play Timeline Indicates the current playback point, and can be used to move. Skip Backward Moves backward by unit time. (Move by 10 minutes) Backward Fast Used for quick backward playback. (2 - 64x speed) Play Backward Slow Used for backward frame-by-frame search while in PAUSE.

  • Page 91: Web Viewer

    web viewer INTRODUCING WEB VIEWER What is Web Viewer? Web Viewer allows remote access to your DVRs. You have access to live video, archived video, PTZ control (if configured), etc. Product Features Network • Remote access from a standard browser •...

  • Page 92: Connecting Web Viewer (Windows)

    web viewer CONNECTING WEB VIEWER (Windows) 1. Open your web browser and type the IP address or URL of DVR into the URL address box.  “192.168.1.200” is set to IP by default.  Set to an available IP address in IP Installer or "Network > Connection Mode”.
  • Page 93 5. When a program installation wizard window appears, press the [Install] button to install the program. 6. When the program is installed, open the web viewer again to login. Live Viewer's main screen appears when you log in successfully after installing the program. English _93...

  • Page 94: Using Live Viewer (Windows)

    web viewer USING LIVE VIEWER (Windows) The Live Viewer screen consists of following : Menu Functions Menu Selection Switches into corresponding menu screen by clicking each menu. Address, Name, Time Displays the IP, model name, time, etc. of connected DVR. DVR Time, PC Time Select <DVR Time>...
  • Page 95 Menu Functions Controls connect PTZ camera(s). Goes to the relevant menu screen of a camera, which supports OSD menu and changes OSD Menu the menu. Display Pane Displays the video of camera connected to DVR. Logout Click Logout icon for logout. User ID Displays the user's ID.
  • Page 96 web viewer Split-Screen Click split mode selection button to switch to the corresponding screen mode. SINGLE MODE SINGLE MODE QUAD MODE QUAD MODE NINE MODE To switch to full screen mode Click < >. Current split screen appears in full screen. Press the [ESC] key to exit the full screen mode.
  • Page 97 Changing the Live Screen Mode  9-split mode does not support “Sequence”, “Previous” and “Next”. • : When this button is clicked, the previous screen appears. - In SINGLE MODE, the channel numbers are switched in reverse order. - In QUAD MODE, the screens are changed like 1st 4 channels (1~4) ...
  • Page 98 web viewer To print a screen 1. Click < > button. 2. Print current camera’s video image with the printer connected to the PC operating the Web Viewer. To save as AVI 1. Click < > button. When “AVI Setup” window appears, select the record saving path and capacity.

  • Page 99: Controlling A Connected Ptz Camera

    CONTROLLING A CONNECTED PTZ CAMERA Controlling PTZ If PTZ camera is connected, the < > icon appears on screen. When selecting corresponding camera channel, the PTZ tab is provided to allow you to control the PTZ. Part Names Functions Direction Adjustment Adjusts the direction of a camera.
  • Page 100 web viewer To set a preset 1. Click < > button to display “Preset” window. 2. Click < > to select a desired preset number. 3. Enter the name of preset. 4. Use direction keys to adjust the direction which camera aims at.
  • Page 101 Controlling OSD Menu If connected PTZ camera supports the OSD menu, press the < > to enter camera’s menu screen to change its settings. Part Names Functions Direction Adjustment You can go to a desired menu. ENTER Selects a desired item. Menu On/Off You can On/Off camera’s OSD menu settings.

  • Page 102: Using Search Viewer

    web viewer USING SEARCH VIEWER The Search Viewer screen consists of following :  Up to 3 users can access simultaneously. Menu Functions Menu Selection Switches to the corresponding menu screen by clicking each menu. Address, Name, Time Displays the IP, model name, time, etc. of connected DVR. Split Mode Selection Selects the type of split screen and selects the channel displayed in Display Pane.
  • Page 103 Menu Functions Play Control Adjusts current video’s playback speed and played time position. Displays the corresponding color depending on recorded data type if you place your Recording Color mouse cursor on that area. Display Pane Plays corresponding data on the screen if you select a search result. Logout Click Logout icon for logout.
  • Page 104 web viewer Names and Functions of Play Buttons Moves backward by 10 minutes from the current playing point. Plays in reverse at doubled speed. The playback speed is doubled up to 64x speed. Moves backward by 1 second from current playing point. Moves forward by 1 second from current playing point.

  • Page 105: Viewer Setup

    VIEWER SETUP You can configure the DVR settings remotely on the network. To configure the DVR settings, click <Setup>. System You can configure the various settings of the DVR system. Date/Time/Language For more information, refer to <Date/Time/Language> in the <System Setup> menu. (Page 42) 1.
  • Page 106 web viewer Holiday You can set specific dates to Holidays according to your preferences. For more information, refer to <Setting Holiday> in the <System Setup> menu. (Page 43) Permission Management For more information, refer to <Permission Management> in the <System Setup> menu. (Page 44) •...
  • Page 107 • User You can add, change or remove a user or users. • Setup You can set the user permission. System Management For more information, refer to <System Management> in the <System Setup> menu. (Page 48) • System Information You can see information of the current system. Check the Software Version, Broadcast Format and MAC Address.
  • Page 108 web viewer Device You can check a list of devices that are connected to the DVR and configure the necessary settings. Click <Device> in the menu screen. For more information, refer to “Setting the Device”. (Page 52) Camera • Camera You can configure the settings of the camera that is connected to the DVR.
  • Page 109 Storage Device You can check and change the settings of the storage device. • Device You will see a list of storage devices that are connected to the DVR. You can check the type, used/total, usage and status of the device. •...
  • Page 110 web viewer POS Device You can set the channel, preset and communication port of the POS device that is connected to the DVR.  You cannot set to use the POS device remotely. Monitor • Monitor You can configure the monitoring screen settings and set the output system.
  • Page 111 Record For more information, refer to <Setting the Recording>. (Page 62) Recording Schedule If you set a recording schedule for a specific date and time, the recording will start at that specific time. - Apply to All CH : Click <Apply to All CH> to display the confirmation window.
  • Page 112 web viewer REC Quality & Resolution • Standard/Event You can set the resolution, frame rate and recording quality for each channel. Record Option You can set the Disk End Mode. Event For more information, refer to <Setting the Event>. (Page 65) Sensor Detection You can set the sensor operation mode and the synchronized camera as well as the alarm output type and the duration.
  • Page 113 Motion Detection You can set the motion detection mode and the sensitivity as well as the alarm output type and the duration. • Motion Region Set the target motion detection area. Video Loss Detection You can set the alarm output time if a video loss occurs. Tampering Detection You can set whether to generate alarm and its dwell time for video tampering events.
  • Page 114 web viewer Alarm Schedule You can schedule the alarm output according to the day of the week and the time. The default setting is Event Sync, which activates the alarm only if an event occurs. Network For more information, refer to <Network Configuration>. (Page 70) Connection Mode A remote user can access the DVR via the network to check the current mode and the IP address.
  • Page 115 • Alarm Set the alarm. DDNS You can check the DDNS settings. Live Transfer Sets the quality of the image that is transferred from the DVR to the network. • Live Transfer A remote user can set the image resolution of the transferred data. English _115...
  • Page 116 web viewer Mailing Service You can specify the SMTP server that sends a mail if an event occurs and set the recipient group and users. • SMTP You can set the server that sends mails and specify if you use the authentication process.

  • Page 117: Information

    • Recipient You can add a user or users who will receive the mail. SNMP You can configure the settings for the SNMP protocol. INFORMATION Click <Information>. Displays the model name of connected DVR and the version of Web Viewer. English _117...

  • Page 118: Connecting Web Viewer (Mac)

    web viewer CONNECTING WEB VIEWER (Mac) Safari on MAC. If you want to use SRD-Series DVR Web Viewer with Safari Browser on a Mac, please refer to this user guide and install Multi Viewer with firmware upgrade if necessary. • Mac OS versions available : 10.6 or later version •...
  • Page 119 • If Microsoft Silverlight plug-in is already installed 1. Use a web browser to connect to the DVR. 2. If Silverlight plug-in is already installed, you will see the login screen as shown. 3. If the login screen does not appear, check if the DVR set is connected properly with a valid IP address.

  • Page 120: Using Live Viewer (Mac)

    web viewer USING LIVE VIEWER (Mac) The Live Viewer screen consists of following : Menu Functions Name, Address Displays a connected DVR’s IP address and model name. Menu Selection Consists of < Live > ,< About > and < LOGOUT > menu. These buttons are used for the screen split and full screen mode.

  • Page 121: Mobile Viewer

    Menu Functions Channel Indicates connected DVR's channels. Controls connect PTZ camera(s). Display Pane Displays the video of camera connected to DVR. MOBILE VIEWER What is Mobile Viewer? Mobile Viewer is management software that enables you to connect to DVR (Digital Video Recorder) remotely and control the video playback and PTZ operations (if configured) in real time.

  • Page 122: Backup Viewer

    backup viewer SEC BACKUP VIEWER You can play a file that is backed up in the format of SEC. Backup in SEC format produces backup data file, library file and self-executable viewer file. If you run the backup file viewer, the backup data file will be automatically played. SRD-894_CAM 01 Recommended System Requirements PCs with a lower specification than the recommended below may not fully support forward/backward and...
  • Page 123 Part Names Functions Set the screen’s aspect ratio to be displayed. Split Screen The screen switches to the selected split screen mode. Enlarge the image by up to 100 times as big as the current one. Press the Zoom In ( ) button the enlarge the image;...

  • Page 124: Appendix

    PRODUCT SPECIFICATION Details Item SRD-494 SRD-894 4channel BNC 8channel BNC Inputs 1080P/720P AHD Camera 1080P/720P AHD Camera Video NTSC/PAL NTSC/PAL Resolution 1920 x 1080, 1280 x 720, 960 x 480, 704 x 480 / 960 x 576, 704 x 576...
  • Page 125 Details Item SRD-494 SRD-894 Record Stream) 1M ~ 2M (240fps, Record Stream) 1M ~ 2M (120fps, 200fps), 4CIF (NTSC : 240fps, 200fps) 100fps), 4CIF (NTSC : 120fps, 100fps) Transmission speed Network Stream) 4CIF / 2CIF / CIF Network Stream) 4CIF / 2CIF / CIF...
  • Page 126 DC/2A, 250V AC/0.25A DC/2A, 250V AC/0.25A Remote notification Notification via e-mail Ethernet 1 RJ45 10/100/1000 Base-T Serial interface RS-232/RS-485(Full Duplex) for PTZ, Samsung System Keyboard USB 2.0, 2 ports e-SATA 2 External SATA ports Connections Application Supoort Mouse, Remote Controller...

  • Page 127: Product Overview

    PRODUCT OVERVIEW • SRD-494 unit : mm(inch) 370,0 (14,57”) English _127...
  • Page 128 appendix • SRD-894 unit : mm(inch) 440 (17.32”) 128_ appendix...

  • Page 129: Default Setting

    DEFAULT SETTING This returns the factory default settings. The settings are made as follows; • Use System/Load Factory Default in MENU  The default settings are based on SRD-894.  The default administrator ID is “admin”, and the password must be set when the user log in at the first time. To prevent from your personal information being exposed, please change your password every 3 months.
  • Page 130 appendix Category Details Factory Default Baudrate 9600 Parity None Data Remote Device Stop bit System Keyboard Remote Control ON(0) POS Device Event Display Display Device Multi CH SEQ Time 5 sec Monitor VGA/HDMI 1920 x 1080 HDMI Resolution Auto Detection Monitor Multi Spot Spot Out...
  • Page 131 Category Details Factory Default Sensor Operation Camera Camera No. Sensor Detection Alarm None Alarm Duration 10 sec Mode Sensitivity Level10(high) Motion Detection Alarm None Alarm Duration 10 sec Event Motion Region All Area Video Loss State Video Loss Detection Alarm None Alarm Duration 10 sec...
  • Page 132 appendix Category Details Factory Default IP Type Static Transfer Bandwidth 2Mbps IP Address 192.168.1.200 Interface Gateway 192.168.1.1 Subnet Mask 255.255.255.0 168.126.63.1 Connection Mode Protocol Type Device Port 4520~4524 Port HTTP Port Secure Video Transmission Disconnect Alarm Output Port Alarm Duration DDNS DDNS Site Network...

  • Page 133: Troubleshooting

    TROUBLESHOOTING Symptom Countermeasures The system does not turn on and the indicator on the Check if the power supply system is properly connected. front panel does not work at all. Check the system for the input voltage from the power source. If the problem persists even after you have taken the above actions, check the power supplier and replace it with a new one if neccessary.
  • Page 134 appendix Symptom Countermeasures I've found that the DVR does not recognize as many It takes time for the DVR to recognize multiple external HDDs. Try again disks as installed when I have connected multiple in a moment and if the problem (of failure to recognize as many HDDs external HDDs to the DVR.
  • Page 135 Symptom Countermeasures Recording does not work. If your player does not display a Live image at all, that indicates recording does not work so first check if you see an image on the screen. Recording does not work if the recording settings are not properly configured.

  • Page 136: Open Source Announcement

    OPEN SOURCE ANNOUNCEMENT The software included in this product contains copyrighted software that is licensed under the GPL/LGPL. You may obtain the complete Corresponding Source code from us for a period of three years after our last shipment of this product by sending email to help.cctv@hanwha.com If you want to obtain the complete Corresponding Source code in the physical medium such as CD-ROM, the cost of physically performing source distribution might be charged.
  • Page 137 c) Accompany it with the information you received as to the offer to 10. If you wish to incorporate parts of the Program into other free distribute corresponding source code. (This alternative is allowed programs whose distribution conditions are different, write to the author only for noncommercial distribution and only if you received the to ask for permission.
  • Page 138 GNU GENERAL PUBLIC LICENSE a computer network, with no transfer of a copy, is not conveying. An interactive user interface displays “Appropriate Legal Notices” to the Version 3, 29 June 2007 extent that it includes a convenient and prominently visible feature that (1) displays an appropriate copyright notice, and (2) tells the user that Copyright ©...
  • Page 139 notices of the absence of any warranty; and give all recipients a copy of A separable portion of the object code, whose source code is excluded this License along with the Program. from the Corresponding Source as a System Library, need not be included in conveying the object code work.
  • Page 140 permits relicensing or conveying under this License, you may add to a In the following three paragraphs, a “patent license” is any express covered work material governed by the terms of that license document, agreement or commitment, however denominated, not to enforce a provided that the further restriction does not survive such relicensing or patent (such as an express permission to practice a patent or covenant conveying.
  • Page 141 15. Disclaimer of Warranty. Finally, software patents pose a constant threat to the existence of any free program. We wish to make sure that a company cannot effectively THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT restrict the users of a free program by obtaining a restrictive license from PERMITTED BY APPLICABLE LAW.
  • Page 142 2. You may modify your copy or copies of the Library or any portion of containing this object code plus portions of the Library will still fall under it, thus forming a work based on the Library, and copy and distribute Section 6.) such modifications or work under the terms of Section 1 above, Otherwise, if the work is a derivative of the Library, you may distribute...
  • Page 143 10. Each time you redistribute the Library (or any work based on the How to Apply These Terms to Your New Libraries Library), the recipient automatically receives a license from the original licensor to copy, distribute, link with or modify the Library subject to If you develop a new library, and you want it to be of the greatest these terms and conditions.
  • Page 144 documentation included with this distribution is covered by the same 1.3. “Covered Software” means (a) the Original Software, or (b) copyright terms except that the holder is Tim Hudson (tjh@cryptsoft. Modifications, or (c) the combination of files containing Original Software com).
  • Page 145 b) under Patent Claims infringed by the making, using, or selling of version will be given a distinguishing version number. Except as Modifications made by that Contributor either alone and/or in provided in Section 4.3, no one other than the license steward has the combination with its Contributor Version (or portions of such right to modify this License.
  • Page 146 8. U.S. GOVERNMENT END USERS. We specifically permit and encourage the inclusion of this software, with or without modifications, in commercial products. We disclaim all The Covered Software is a “commercial item,” as that term is defined in warranties covering The FreeType Project and assume no liability related 48 C.F.R.
  • Page 147 As you have not signed this license, you are not required to accept it. License is also granted to make and use derivative works provided that However, as the FreeType Project is copyrighted material, only this such works are identified as “derived from the RSA Data Security, Inc. license, or another one contracted with the authors, grants you the right MD5 Message-Digest Algorithm”...
  • Page 148 Component Name License License URL librtp 1.20 BSD 2.0 http://www.opensource.org/licenses/bsd-license.html For more additional information, send email to help.cctv@hanwha.com. 4. Neither the name of the University nor of the Department may be used to endorse or promote products derived from this software without specific prior written permission.
  • Page 149 Copyright © 2003 Sun Microsystems, Inc., 4150 Network Circle, Santa THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND Clara, California 95054, U.S.A. CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED All rights reserved. WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A Use is subject to license terms below.
  • Page 150 Part 9: ScienceLogic, LLC copyright notice (BSD) THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED Copyright (c) 2009, ScienceLogic, LLC WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A All rights reserved.
  • Page 151 THE AUTHORS OF THIS SOFTWARE DISCLAIM ALL WARRANTIES Copyright (c) 1999 Tommi Komulainen. WITH REGARD TO THIS SOFTWARE, INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS, IN NO EVENT All rights reserved. SHALL THE AUTHORS BE LIABLE FOR ANY SPECIAL, INDIRECT OR Redistribution and use in source and binary forms, with or without CONSEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER modification, are permitted provided that the following conditions are...
  • Page 152 Samsung cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Samsung’s devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive.
  • Page 153 MEMO...
  • Page 154 6, Pangyo-ro 319beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82-70-7147-8753, 8764 Fax : +82-31-8018-3740 www.samsungsecurity.com SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 2nd Floor, No. 5 The Heights, Brooklands, Weybridge, Surrey,...

This manual is also suitable for:

Srd-894

Table of Contents
