- Page 1 INSTALLATION GUIDE 9800 Series Wireless Graphic Touchscreen Keypad...
- Page 2 © 2016 Digital Monitoring Products, Inc. Information furnished by DMP is believed to be accurate and reliable. This information is subject to change without notice. 9800 Series Keypad Installation Guide...
-
Page 3: Touchscreen Display
DMP Keypad Features DMP 9800 Series Wireless Graphic Touchscreen Keypads offer flexible features and functionality in a stylish design. Each keypad provides: • AC Power/Armed LED • Full color touchscreen display • Built-in proximity card reader • Internal speaker • Wireless communication •... -
Page 4: Panic Icons
NOT apply directly onto the touchscreen. After cleaning, wipe the touchscreen dry with a soft, lint-free cloth. Touch the blue mini shield that displays in the upper left corner to return to the Main Screen. 9800 Series Keypad Installation Guide... -
Page 5: Internal Speaker Operation
Micro SD Card 9800 Series Wireless Graphic Touchscreen Keypads provide a spring-loaded Micro SD card slot on the right edge of the keypad housing. This is used to load a custom logo onto the main screen. Insert the Micro SD card straight in, with the contacts facing the wall, pressing in until a click occurs from the spring mechanism. -
Page 6: Backlighting Brightness
The LCD displays the keypad model number and firmware version and date in the top right corner of the screen. The user cannot change this information. 9800 V109 072214 SN 14500000 BRIGHTNESS TONE VOLUME INSTALLER OPTIONS Figure 7: Options Screen 9800 Series Keypad Installation Guide... -
Page 7: Installing The Keypad
The 9862 keypad housing is designed to easily install on any single-gang switch box or flat surface. Figure 9 shows the keypad housing base mounting hole locations. Selecting the Proper Location 9800 Series Wireless Graphic Touchscreen Keypads provide Building Wall a built-in survey capability in the Installer Options menu to... - Page 8 Slide the leg upwards until the top ridge seats in the rectangular opening. See Figure 10. Repeat the process to attach the second side of the stand. Slide Lock Figure 10: Attaching the Deskstand 9800 Series Keypad Installation Guide...
-
Page 9: Power Supply
3. Fit the adapter plugs through the square opening in the plastic strap and wrap the strap around the power supply until the two holes line up. See Figure 12. Figure 12: 9862USB Power Supply Connection 9800 Series Keypad Installation Guide... - Page 10 7. Plug the micro USB end of the cable into the back of the 9862USB keypad. See Figure 13. Micro USB Port Micro USB end Transformer USB end Strap Figure 13: 9862USB Power Supply Keypad Connection 9800 Series Keypad Installation Guide...
-
Page 11: Standby Battery
5. Properly dispose of the used battery. Caution: Risk of fire, explosion, and burns. Do not disassemble, heat above 212°F (100°C), or incinerate. Battery Strap J3 Battery Connection Battery Figure 14: Battery Connection 9800 Series Keypad Installation Guide... - Page 12 A maximum of four wireless keypads are allowed on each panel. To pair a 9800 Series keypad with an XTLplus panel, power up both the panel and the keypad. A 10 minute pairing timer begins. The auto pairing process starts immediately and the keypad displays Pairing Keypad With System.
- Page 13 Arming Type Auto Detect (on select panels) When an XTLplus panel’s arming type (A/P , H/S/A, Area) is changed, 9800 Series keypads (Version 109 or higher) will automatically sync their arming type to match the panel.
-
Page 14: Installer Options Menu
Press the display to enter the user code digit length being used by the panel. Default is 5. When searching the bit string for the user code, the digits are identified and read from left to right. 9800 Series Keypad Installation Guide... -
Page 15: Custom Card Definitions
Site Code Position SITE CODE: Enter the site code start position in the data string. Press POSITION any select area to enter a number between 0-255. Press CMD to save the entry. Default is 1. 9800 Series Keypad Installation Guide... - Page 16 Select ADD to upload the file. The keypad will display ADDING LOGO SURE? Select SURE? NO YES YES to proceed. While the logo is being uploaded, the keypad displays ADDING LOGO. ADDING LOGO COMPLETED displays to confirm a successful upload. 9800 Series Keypad Installation Guide...
-
Page 17: Carousel Z-Wave Items
LIST REMOVE displays. When the icon is pressed on the Favorites Edit Icon screen, the keypad prompts for a User Code. Enter a valid user code and FAVORITE NUMBER: - displays. For more information on Z-Wave devices and Favorites please see the panel user guide. 9800 Series Keypad Installation Guide... -
Page 18: Select Language
The display shows OKAY each time a good proximity read is received. Exiting the Installer Options Press the CMD key until the display returns to the Installer Options screen. Select STOP to exit the Installer Options function. 9800 Series Keypad Installation Guide... - Page 19 Users can also manually enter their user code into the keypad. The keypad verifies the user code and its authority with the panel. Internal Access Control Reader 9800 Series Wireless Graphic Touchscreen Keypads provide a built-in proximity card reader designed to read DMP/HID 1300 Series proximity credentials. 9800 Series Keypad Installation Guide...
- Page 20 ALL SYSTEM OFF. If the system is disarmed when you present your card, once the card is validated, HOME SLEEP AWAY displays. Manually select HOME, SLEEP , AWAY or after a short time-out, all areas automatically arm in the AWAY mode. 9800 Series Keypad Installation Guide...
- Page 21 Area systems provide a delay to allow selected areas only to be disarmed. USER MENU ENTER CODE: - ENTER CODE: - HOME RESET RESET HOME CHIME PERIM SLEEP CHIME PERIM SLEEP Entry delay starts. The System disarms the area. Figure 26: Entry Delay 9800 Series Keypad Installation Guide...
-
Page 22: Fcc Information
Compliance Specifications The keypad LED brightness setting must be set above the minimum setting. Do not mount keypad on metal surfaces or metallic electrical boxes. 9800 Series Keypad Installation Guide... - Page 23 9800 Series Keypad Installation Guide...
-
Page 24: Specifications
Specifications Operating Voltage 12VDC Standby Current 120 mA @ 12VDC Alarm Current 206 mA @ 12VDC Dimensions 5.8” W x 4.135” H x 0.6” D Compatibility Compatible with XTL Series, XT30/XT50 Series, XR100/XR500 Series, XR150/XR350/XR550 Series panels. Accessories Power Harness Model 300-9800-4 Replacement 4-wire Power Harness Proximity Credentials...
