User's Manual
PPC-090T
DMP Vortex86 DX2 / DX3 Processor
Compact Panel PC with 9" Touchscreen
PPC-104T User's Manual
PPC-090T-D2 Series with DX2 processor
PPC-090T-D3 Series with DX3 processor
(Revision 1.4A)
IUMPPC104T-01 Ver.1.0A Mar, 2016
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPC-090T-D2 Series and is the answer not in the manual?

Questions and answers

Related Manuals for DMP Electronics PPC-090T-D2 Series

Summary of Contents for DMP Electronics PPC-090T-D2 Series

  • Page 1 User’s Manual PPC-090T DMP Vortex86 DX2 / DX3 Processor Compact Panel PC with 9” Touchscreen PPC-090T-D2 Series with DX2 processor PPC-090T-D3 Series with DX3 processor (Revision 1.4A) PPC-104T User’s Manual IUMPPC104T-01 Ver.1.0A Mar, 2016...
  • Page 2 REVISION DATE VERSION DESCRIPTION 2014/1/22 Version 1.0A New Release 2014/3/11 Version 1.1A 4.3 Serial Ports Setting (RS232/422/485) 2015/9/15 Version 1.2A Change the SPEC of Section 3.1 Add the type with 2GB DRAM solution 2016/1/6 Version 1.3A Correct LED backlight lifetime Doesn't support DOS Touch Driver Change J33~J36 connectors as optional 2016/4/28...
  • Page 3 COPYRIGHT The information in this manual is subject to change without notice for continuous improvement in the product. All rights are reserved. The manufacturer assumes no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update or to keep current the information contained in this manual.
  • Page 4 SAFETY INFORMATION  Read these Safety instructions carefully.  Please carry the unit with both hands, handle carefully.  Make sure the voltage of the power source is correct before connecting the equipment to the power outlet.  Do not expose your Panel PC to rain or moisture in order to prevent shock and fire hazard.

  • Page 5: Table Of Contents

    Content Content ....................... iii Ch. 1 General Information ................1 1.1 Product Description ................2 1.2 Product Specifications ................ 3 1.3 Inspection standard for TFT-LCD Panel ..........5 1.4 Product Dimensions ................8 1.5 Panel Mounting Instruction ............... 10 1.6 Ordering Information ................. 12 Ch.

  • Page 6: Ch. 1 General Information

    General Information 1.1 Product Description 1.2 Product Specifications 1.3 Inspection standard for TFT-LCD Panel 1.4 Product Dimensions 1.5 Mounting Instruction 1.6 Ordering Information PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...

  • Page 7: Product Description

    1.1 Product Description DM&PTechnology Inc. is proudly going to release a brand new Panel PC, which offers fanless design, low power consumption, and IP65 front panel. The PPC-090T is powered by DMP’s Vortex86DX2 and DX3 SoCs, the 3 generation SoCs of Vortex86 family, and dual -channel 1GB / 2GB DDRII (DDDRIII) chipset that handles processing more efficiently and provides faster performance.

  • Page 8: Product Specifications

    1.2 Product Specifications CPU BOARD SPECIFICATIONS DM&P Vortex86DX2- 933MHz / DX3-1GHz DX2: L1:16KB I-Cache, 16KB D-Cache L2: 256KB Cache Cache DX3: L1:32KB I-Cache, 32KB D-Cache L2: 512KB Cache BIOS AMI BIOS Memory 512MB/1GB/2GB DDR2(DDR3) onboard Software Programmable from Watchdog Timer 30.5u to 512 seconds x 2 sets Integrated 10/100M Ethernet X1 Giga Ethernet (Optional) X1...
  • Page 9 Storage Temperature -30~+70°C (-22~ +158°F) 0% ~ 90% Relative Humidity, Operating Humidity Non-Condensing Dimensions 242x156.5x44mm (9.68"x6.26"x1.76") Weight 1.36 Kg Protection IP65 Front Panel Certification CE / FCC / VCCI / Vibration / Shock LCD SPECIFICATIONS Display Type 9” WSVGA TFT LCD Backlight Unit Display Resolution 1024(W) x 600(H)

  • Page 10: Inspection Standard For Tft-Lcd Panel

    1.3 Inspection standard for TFT-LCD Panel DEFECT TYPE LIMIT φ＜0.15mm Ignore Note SPOT 0.15mm≦φ≦0.5mm N≦4 0.5mm＜φ 0.03mm<W≦0.1mm, L≦5mm N≦3 Note FIBER VISUAL 1.0mm＜W, 1.5mm＜L INTERNAL DEFECT φ＜0.15mm Ignore POLARIZER Note 0.15mm≦φ≦0.5mm N≦2 BUBBLE 0.5mm＜φ Mura It’ OK if mura is slight visible through 6%ND filter A Grade B Grade Note...
  • Page 11 W: Width[mm]; L: Length[mm]; N: Number; φ: Average Diameter. [ Note 1 ] (a) White / Black Spot (b) Polarizer Bubble Bright dot is defined through 6% transmission ND Filter as following. [ Note 2 ] Display area [ Note 3 ] C Area: Center of display area O Area: Outer of display area Judge the defect dot and the adjacent dot as following.
  • Page 12 R Defect Dot Adjacent Dot The defects that are not defined above and considered to be problem shall be reviewed and discussed by both parties. Defects on the Black Matrix, out of Display area, are not considered as a defect or counted.

  • Page 13: Product Dimensions

    1.4 Product Dimensions PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...
  • Page 14 PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...

  • Page 15: Panel Mounting Instruction

    1.5 Panel Mounting Instruction Cut a mounting hole in the panel. (Refer to PPC‐090T Dimensions on page 11~12.) (Note 1) Check and remove the twelve M3 screws in a diagonal pattern as image below if necessary. Place PPC‐090T face‐down on a clean, flat surface. Slide the panel cutout around the back of PPC‐090T, until the panel rests directly on the gasket.
  • Page 16 Note 1: It is strongly recommended that a pr ofessional machine shop cut the mounting hole in the panel. Note 2: The length for all twelve M3 screws will be according to the thickness of mounting panel. For example: The l ength of standard M3 screws for PPC-090T is 6mm.

  • Page 17: Ordering Information

    1.6 Ordering Information PART NUMBER DESCRIPTION PPC-090T-D2N4N 9” Panel PC w/DX2/1GB Memory 3USB/AUDIO/LAN/2COM/DC12~24V PPC-090T-D2N4N-GE 9” Panel PC w/DX2/1GB Memory 3USB/AUDIO/LAN/GIGA LAN/2COM/ DC12~24V PPC-090T-D2N4N-G7CP 9” Panel PC w/DX2/1GB Memory 3USB/AUDIO/LAN/GIGA LAN/7COM/ PPC-090T-D2W4N-GE 9” Panel PC w/DX2-800MHz/1GB Memory/3USB/AUDIO/LAN/GIGA LAN/2COM/DC12~24V/Wide Temp PPC-090T-D3G4N 9” Panel PC w/DX3/1GB Memory 3USB/AUDIO/LAN/2COM/DC12~24V PPC-090T-D3G4N-GE 9”...

  • Page 18: Ch. 2 System Installation

    System Installation 2.1 CPU Board Outline 2.2 Connector Summary 2.3 Connector Pin Assignments 2.4 External I/O Overview 2.5 External I/O Pin Assignment 2.6 Watchdog Timer PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...

  • Page 19: Cpu Board Outline

    2.1 CPU Board Outline PPC CPU Board PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...

  • Page 20: Connector Summary

    2.2 Connector Summary Description Type of Connections Pin # Power Terminal Connector External Power Plug 3-pin COM1 (RS232/422/485) External D-Sub Male Connector 9-pin External USB Connector 6-pin External USB Connector 6-pin PS/2Keyboard External Mini DIN Socket 6-pin External USB Connector 6-pin Internal USB Connector 5-pin...

  • Page 21: Connector Pin Assignments

    2.3 Connector Pin J7: USB Assignments Pin # Signal Name Pin # Signal Name USBD4- J1: Power Terminal Connector USBD4+ Pin # Signal Name +12~24V J8: USB (WLAN Optional) Pin # Signal Name Pin # Signal Name USBD1- J3 & J14: COM1 & 2 (RS232/422/485) USBD1+ Pin # Signal Name...
  • Page 22 J33/J34/J35/J36: GPIO 180-pin (Optional for I/O extension board on Ch.5) Signal Signal Signal Signal Signal Signal Signal Signal Pin# Pin# Pin# Pin# Pin# Pin# Pin# Pin# Name Name Name Name Name Name Name Name SBHE GP34 GP35 RSTDRV IRQ3 GP36 GP37 GP90 GP91...

  • Page 23: External I/O Overview

    2.4 External I/O Overview Power Switch PS/2 KB USB 2.0 PORT Audio-Out 10/100Mbps GIGA Ethernet RS-232/422/485 +12 ~ 24VDC Ethernet (Optional) NOTE GIGA LAN, Wireless are optional RS232/422/485 is selected by BIOS setting PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...

  • Page 24: External I/O Pin Assignment

    2.5 External I/O Pin Assignment Power Switch J4/J5/J7: USB Pin # Status Pin # Signal Name USB0- Power Connector DC-IN +12~24V USB0+ Pin # Signal Name +12~24V GGND GGND RJ45 PS/2 Keyboard Signal Signal Pin # Signal Name Name Name KBCLK FTXD+ FTXD-...

  • Page 25: Watchdog Timer

    2.6 Watchdog Timer There are two watchdog timers in PPC-090T, we also provide DOS, Linux and WinCE example for your reference. PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...

  • Page 26: Ch. 3 Hardware Installation

    Hardware Installation PPC-090T supports various kinds of storages for industrial application, divided into SATA Slim, CompactFlash or SD card (optional). 3.1 Installing the SATA Slim 3.2 Installing the Compact Flash PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...

  • Page 27: Installing The Sata Slim

    3.1 Installing the SATA Slim [SPEC] JEDEC SFF-8156 standard form factor 53 x 32 x 4.0 mm SDM-SST-SLIM(M)4G SDM-SST-SLIM(M)8G SDM-SST-SLIM(M)16G SDM-SST-SLIM(M)32G [STEP] Remove the nine screws in a diagonal pattern as the image below. Place the SATA slim horizontally aligned and gently put into the socket until you feel a click.

  • Page 28: Installing The Compact Flash

    3.2 Installing the Compact Flash [STEP] Remove the nine screws in a diagonal pattern as the image below. Gently insert the CF card along the track. Caution: Please watch out for the direction which the CF card has to be face up. Insert all nine screws into the screw holes.

  • Page 29: Ch. 4 Driver Installation

    Driver Installation 4.1 PPC-090T Development Note 4.2 BIOS Default Setting 4.3 Serial Ports Setting (RS232/RS422/RS485) PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...
  • Page 30 The Vortex86DX2 / DX3 processor is integrated RDC Display chip which is an ultra-low powered graphics chipset with total power consumption at around 1-1.5 W. The Vortex86DX2 / DX3 processor is integrated 10/100Mbps Ethernet controller that supports both 10/100BASE-T and allows direct connection to your 10/100Mbps Ethernet based Local Area Network for full interaction with local servers, wide area networks such as the Internet.

  • Page 31: Ppc-090T Development Note

    4.1 PPC-090T Development Note < WINDOWS DEVELOPMENT GUIDE > Windows Embedded CE 6.0 BSP, Windows Embedded Compact 7 BSP, and Windows Embedded Standard 2009 t rial image with development notes. < LINUX INSTALLATION NOTE> Please visit Linux technical website to get more information at ftp://ftp.dmp.com.tw/Linux_DEMO/Vortex86_Linux_Support_List.htm.

  • Page 32: Bios Default Setting

    4.2 BIOS Default Setting If the system cannot be boot ed after BIOS changes are made, Please follow below procedures in order to restore the CMOS as default setting. Press < End > Key, when the power on Press < Del > to enter the AMI BIOS setup Press <...

  • Page 33: Serial Ports Setting (Rs232/422/485)

    4.3 Serial Ports Setting (RS232/422/485) For DX2 processor: Please press <Del> to get into the BIOS settings after booting the machine, and follow the steps below: [Step 1] Use the arrow key to select the category “Chipset” on the top of the menu, then select SouthBridge Configuration in the sub menu and press <Enter>...
  • Page 34 [Step 2] Use the arrow key to select “TXDEN Serial Port Type Configuration” and press <ENTER> [Step 3] Choose the port you would like to change. For example, choose TXDEN1 for COM1 and press <Enter>. You will then see three options; select the desired type and press <Enter>...
  • Page 35 The Serial Ports setting is finished [Step 4] Press <Esc> twice to get back to the T op Menu. Use the arrow key to the category “Exit”, and select the option “Save Changes and Exit”. PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...
  • Page 36 Press <Enter> and choose [OK] to keep your changes, then the device will reboot automatically. PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...
  • Page 37 For DX3 processor: Please press <Del> to get into the BIOS settings after booting the machine, and follow the steps below: [Step 1] Use the arrow key to select the category “Advanced” on the top of the menu, then select "Serial/Parallel Port Configuration" in the sub menu and press <Enter>...
  • Page 38 The Serial Ports setting is finished [Step 3] Press <Esc> twice to get back to the T op Menu. Use the arrow key to the category “Exit”, and select the option “Save Changes and Exit”. PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...
  • Page 39 Press <Enter> and choose [OK] to keep your changes, then the device will reboot automatically. PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...

  • Page 40: Ch. 5 Extension I/O (Optional)

    Extension I/O (Optional) 5.1 Extension I/O Overview 5.2 External I/O Pin Assignment PPC-090T User’s Manual IUMPPC090T-01 Ver.1.4A Apr, 2016...

  • Page 41: Extension I/O Overview (Optional)

    5.1 Extension I/O Overview (Optional) NOTE: Those COM ports are only for RS232 signals. DSub-25pin only can be set to be either one of COM5 & COM6 18-bit GPIO by hardware settings, and user can't change hardware setting there. Thus, please contact your region sales person to order correct part number in advance.

  • Page 42: Extension I/O Pin Assignment (Optional)

    5.2 Extension I/O Pin Assignment (Optional) COM3, 4 and 9 (RS232) (Change setting by BIOS) Pin # Signal Name Pin # Signal Name DCD1 RXD1 TXD1 DTR1 DSR1 RTS1 CTS1 COM5 & 6 (RS232) or 18-bit GPIO Pin # Signal Name Pin # Signal Name VCC (+5V_Output)

  • Page 43: Warranty

    Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be i n good working order at any time during this period, we will, at our option, replace or repair it at no add itional charge except as set forth in the following terms.
