4. Loading the Ribbon

Note:
This section is not applicable to the direct thermal printing.
4.1 Press the cover locks on both sides to open the top cover
Cover Lock
5
www.meteorbarcode.it - info@meteorbarcode.it
4.2 Unlatch the print head module by pushing the two green
release levers on the sides toward the rear.
4.3 This allows print head module to rotate upward
automatically and expose the ribbon supply holder.
Print Head Module
Release Lever
Ribbon Supply Holder
6
