CONTENTS
1. Checking Your Box................................... 1
2. Power Supply.......................................... 2
3. Parts and Features.................................... 3
4. Loading the Ribbon.................................. 5
5. Loading the Media.................................... 10
5.1 Standard Mode
5.2 Peel Off Mode
5.3 Cutter Mode
Operator Controls.................................... 20
6.
6.1 Power Switch
6.2 Buttons
6.3 LED Indicators
Performing Calibration.............................. 23
7.
8. Printing Configuration Report..................... 24
Returning to Factory Default Settings............ 26
9.
10. Hooking up the Printer and the Computer...... 27
11. Communicate with the Printer..................... 28
11.1 Before installation
11.2 Installing Driver
11.3 Installing the USB Driver (Plug and Play)
11.4 Set Parameters
11.4.1 For Win 98
11.4.2 For Win 2000
11.4.3 For Win NT 4.0
11.4.4 For Win XP
12. Troubleshooting....................................... 51
12.1 Problems on media
12.2 Problems on ribbon
12.3 Miscellaneous
12.4 Recovery
Page
www.meteorbarcode.it - info@meteorbarcode.it
13. Caring for Your Printer............................. 54
13.1 Cleaning the print head (THP)
13.2 Cleaning the roller
13.3 Cleaning the media compartment
14. Reference Technical Information.................. 55
14.1 General Specifications
14.2 Fonts, Bar Codes and Graphics Specification
14.2.1 Printer Programming Language A, PPLA
14.2.2 Printer Programming Language B, PPLB
14.2.3 Printer Programming Language Z, PPLZ
14.3 Interface Specifications
14.3.1 Introduction
14.3.2 Serial
14.3.3 USB
14.3.4 Connection with host
14.3.5 Parallel ( Centronics )
14.3.6 Auto Polling
14.4
ASCII TABLE
15. Appendix.................................... ............
15.1 Appendix A : Printer Status
15.2 Appendix B : Stand-Alone Operation
15.3 Appendix C : Dispenser Kit Installation
15.4 Appendix D : Cutter Installation
65
