5.3.3 Press down the print head module firmly.
Cutter
Note:
The "Feed" button will not drive the printer to cut.
The cutting work can be executed only when the software
setting is ready.
19
www.meteorbarcode.it - info@meteorbarcode.it

6. Operator Controls

6.1 Power Switch

Controls printer power
On-normal operation
Off-the power should be turned off before connect or disconnect
the communication cables and power cables

6.2 Buttons

There are three buttons, each has two basic functions
BUTTON Pressed at normal status
FEED Feed a label.
■ Stop the printing process.
PAUSE
■ Resume the printing job
after press it again.
■ Interrupt and delete the
CANCEL
printing job.
■ Force the printer to
continue working after an
error had been recovered.
.
Pressed during power-on
Perform a self-test for
configuration report.
Perform the media
calibration.
Reset the settings at
2
E PROM.
