Page 2: Air Conditioner
AF28FVSDA Series AF28FVZDA Series Air Conditioner user & installation manual imagine the possibilities Thank you for purchasing this Samsung product. DB68-03955A-02 EN TH IN VI S-east_MEMORY_IBIM_03955A-02_co_EN.indd 3 2014-10-31 오후 1:49:14...
Page 3 Features of your new air conditioner Samsung Air Solution! Cool, Clean and refreshing feeling at once Cool Air : Your air conditioner uses air flow direction control which provide direct air flow in hot days and indirect air flow when you are cooled down.
Page 4: Table Of Contents
Contents USING PARTS Safety precautions ..................... . . 4 Checking before use .
Page 5: Safety Precautions
If you have any questions, call your nearest contact center or find help and information online at www.samsung.com. Important safety symbols and precautions: Hazards or unsafe practices that may result in severe personal WARNING injury or death.
Page 6 Do not install this appliance near a heater, inflammable material. Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops). Do not install this appliance in a location where gas may leak.
Page 7 Safety precautions FOR POWER SUPPLY WARNING When the circuit breaker is damaged, contact your nearest service center. Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook the power line over a metal object, place a heavy object on the power line, insert the power line between objects, or push the power line into the space behind the appliance.
Page 8 Do not operate the appliance with wet hands. f This may result in electric shock. Do not strike or pull the air conditioner with excessive force. f This may result in fire, injury, or problems with the product. f Importantly, if the support bracket is excessively impacted, it may become damaged.
Page 9 Safety precautions FOR USING WARNING Do not insert your fingers or foreign substances into the air inlet/outlet of the air conditioner. f Take special care that children do not injure themselves by inserting their fingers into the product. Do not use this air conditioner for long periods of time in badly ventilated locations or near infirm people.
Page 10 Do not spray volatile material such as insecticide onto the surface of the appliance. f As well as being harmful to humans, it may also result in electric shock, fire or problems with the product. Do not drink the water from the air conditioner. f The water may be harmful to humans.
Page 11 Safety precautions FOR CLEANING CAUTION Take care when cleaning the surface of the heat exchanger of the outdoor unit since it has sharp edges. f To avoid cutting your fingers, wear thick cotton gloves when cleaning it. Do not clean the inside of the air conditioner by yourself. f For cleaning inside the appliance, contact your nearest service center.
Page 12: Checking Before Use
Checking before use Using indoor unit Make sure that curtain does not block the air inlet. f It may decrease cooling performance by blocking air circulation. In Cool mode, set the appropriate desired temperature. f If the desired temperature is too low, it may be harmful for human body and power consumption will also increase.
Page 13: Operation Ranges
Checking before use Auxiliary power switch Turn on the auxiliary power switch which is installed separately. (Only applicable for outdoor unit with separate power supply) Auxiliary power switch (NFB, ELB, etc.) • Auxiliary power switch is not included in the package. Purchase and install it separately. NOTE • Auxiliary power switch is a device for preventing over-current or short circuit.
Page 14: Checking The Name Of The Parts
Checking the name of the parts Your air conditioner may slightly look different from illustration depending on the model. Indoor unit Display Smart sensor(Camera) Arise automatically when turning on the air conditioner Remote controller receiver Air inlet Intake outdoor air Air control panel Full HD filter Move with selected air...
Page 15 Checking the name of the parts Display Fan speed Mute Virus doctor good'sleep Air conditioner operation mode Timer Temperature Cleaning mode Current operation mode is displayed. Outdoor unit Smart sensor operation operation Buttons on control panel On/Off button Temperature control button Increase or decrease the temperature by 1 ˚C Individual control button...
Page 16 Operation with control panel 1. Press the Power button to operate the air conditioner. f The air outlets will open in order with melody sound and the air conditioner will operate with auto mode. Stop Press the Power button one more time. 2.
Page 17: Checking The Remote Controller
Checking the remote controller Function may be different depending on the model. f Point the remote controller towards the remote control receiver of the unit. f When the button is pressed, you will hear ringing or beep sound and Transmit indicator ( ) will appear on the remote controller display.
Page 18: Remote Controller Display
Remote controller display Operation mode Transmit indicator indicator Low battery indicator Set temperature/ Time indicator Fan speed indicator On/Off Time indicator Auto Medium Air flow direction High indicator ❋ ❋ Heat mode will be displayed on the remote controller and reception sound will be ringing but the air conditioner will not operate the heat mode.
Page 19: Basic Operation
Basic operation Basic operation is an operation mode that can be selected by pressing the Mode button. Auto In Auto mode, the air conditioner will automatically set the operation mode in Cool/Dry/Fan mode to provide refreshing air throughout your indoor area. f In Auto mode, the air conditioner will automatically set the operation mode depending on the indoor surrounding.
Page 20 Press the button to turn on the air conditioner. Press the button to set Solo/Family mode. • Solo : Select this function if you are alone in the room or want to save your electricity bill. • Family : Select this function if there are lots of people in the room or require powerful cooling. Family mode Solo mode Remarks The middle air outlet will be closed when the air conditioner reaches the desired temperature in solo mode. When selecting the solo mode in purity mode, the upper and middle air outlets are closed.
Page 21: Turbo Operation
Turbo operation Turbo function will be helpful to cool your room quickly and effectively. Press the button on the remote controller in the Cool mode. f Turbo indicator appears on the remote controller display and the air conditioner will operate in Turbo function for 30 minutes. Cancel Press the Turbo, Mode, Quiet, Smart Sensor or good`sleep button.
Page 22: Good'sleep Operation
good'sleep operation For a comfortable sleep, the air conditioner will operate in Fall asleep  Sound sleep  Wake up from good’ sleep mode. When the air conditioner is on and in cool mode. 1. Press the good'sleep button on the remote controller to select the good'sleep mode. f good'sleep indicator appears and Off timer indicator starts blinking on the remote controller display.
Page 23 good'sleep operation Temperature and fan speed changes in good'sleep mode 1. Fall asleep mode : Provides you with a comfortable environment for a good sleep by rapidly cooling your room and releasing a breeze that induces sleep. 2. Sound sleep mode : The sound sleep mode adjust temperature and air flow in waves to maintain healthy skin temperature while it aids deep sleep.
Page 24: Setting The On/Off Timer
Setting the On/Off timer You can set the air conditioner to turn on/off automatically at desired time. Setting On timer while the air conditioner is off / Off timer while the air conditioner is on. 1. Press the On timer or Off timer button. f On/Off timer indicator will blink on the remote controller display.
Page 25 Setting the On/Off timer Combining On Timer and Off Timer If the air conditioner is Off If the air conditioner is On Preset time on On timer is shorter than Off timer Preset time on On timer is longer than Off timer Ex) On timer : 3 hours, Off timer : 5 hours Ex) On timer : 3 hours, Off timer : 1 hour - The air conditioner will turn on after 3 hours...
Page 26: Smart Sensor Operation
Smart sensor operation In Cool mode, camera on the top of the indoor unit will detect the movement within the indoor and when there is no movement for certain time, air conditioner will adjust the indoor temperature or turn off power automatically. Press the button during Cool mode.
Page 27: Quiet Operation
Quiet operation This function can reduce the noise generated during air conditioner operation. Press the button to select Quiet function. icon will appear on the remote controller display. Cancel Press the Quiet, Mode or Fan button once again. Lighting You can adjust the desired temperature by 1 °C within the range of 18 °C~30 °C. (Auto), pressing the Fan Since the fan speed is fixed as button will...
Page 28: Cleaning The Air Conditioner
Cleaning the air conditioner • Make sure to turn off the circuit breaker when cleaning the air conditioner. CAUTION Cleaning the indoor unit f Wipe the surface of the unit with a slightly wet or dry cloth when needed. f Brush away the dust on the narrow gap of air conditioner. • Since the panel of the product can be scratched easily, use the exclusive cleaning cloth (micro fiber) for cleaning.
Page 29 Cleaning the air conditioner Cleaning the Full HD filter Full HD filter filters the big dust of incoming air. Pull out the Full HD filter in the arrow direction. Remove dust with a vacuum cleaner or running water. f Before pulling out the lower Full HD filter, take out f When the dust is serious, clean the filter with the Zero filter first.
Page 30 Cleaning the Zero filter Zero filter traps small dust particles within the air. It is washable and it can be used semi-permanently. Remove the lower Full HD Soak the filter in the water and shake it up and down for filter.
Page 31: Troubleshooting
Troubleshooting Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expenses. PROBLEM SOLUTION • Check power status and then operate the air conditioner again. The air • Switch on the circuit breaker and then operate the air conditioner conditioner again.
Page 32 PROBLEM SOLUTION • Check if your batteries are depleted. • Make sure nothing is blocking your remote controller sensor. Remote • Check whether there are strong lighting apparatus near the air controller is not conditioner. Strong light which comes from fluorescent bulbs or working.
Page 33 Troubleshooting PROBLEM SOLUTION • Depending on the status of the air conditioner usage, noise can be Noise is heard when refrigerant flow movement changes. It is normal. generated • Crackling sound may occur during the operation of the air conditioner, push the Zero filter to the end. Water is • Water may be generated because of the temperature difference.
Page 34: Open Source Announcement
It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-ROM; a minimal charge will be required. The following URL http://opensource.samsung.com/opensource/Memory/seq/0 leads to the download page of the source code made available and open source license information as related to this product. This offer is valid to anyone in receipt of this information.
Page 35: Installation Parts
Installation parts Safety precautions Carefully read the content of this manual before installing the air conditioner and store the manual in a safe place in order to be able to use it as reference after installation. Hazards or unsafe practices that may result in severe personal injury or death. WARNING Hazards or unsafe practices that may result in minor personal injury or property damage.
Page 36 WARNING f Do not assemble the power cord on your own, use two cables together to extend the cable length or tangle the cable. - Bad connection, isolation and over voltage may cause fire or electric shock. f Make sure to turn off the main power when setting up the indoor unit electrical circuit or power cords. - There is a risk of electric shock.
Page 37: Required Tools
Required tools General tools ① Vacuum pump ② Torque wrench ③ Pipe cutter ④ Reamer ⑤ Pipe bender ⑥ Spirit level ⑦ Screw driver ⑧ Spanner ⑨ Drill ⑩ L wrench ⑪ Measuring tape Tools for test operations ① Thermometer ②...
Page 38: Choosing The Installation Location
Choosing the installation location Indoor unit f Install the unit at a place close to the wall facing the outside as it is necessary to perform piing connection with the outdoor unit. - It is effective to install the unit at the place where air flow is not blocked and the cool air can be distributed throughout the room.
Page 39: Indoor/Outdoor Unit Installation Diagram
Indoor/outdoor unit installation diagram Installation space for floor type indoor unit f To minimize the waste of space due to installation, install the indoor unit as shown in below figure. - Top view ❋ ❋ After completing the installation, remove the protection vinyl. (Be careful of static electricity).
Page 40 Fixing outdoor unit Follow below method to firmly fix the outdoor unit. f Using rubber leg - Put the rubber leg to the outdoor unit leg. (Refer to illustration on the right.) f Using anchor bolt Anchor bolt fixing dimension 660 mm - On a flat, rigid ground, use 4 anchor bolt (M10) to fix the unit.
Page 41: Accessories
Accessories Indoor unit accessories Remote controller Fixing bracket for indoor unit Batteries Remote controller holder M4 x 16 screws User & installation manual Cleaning cloth (micro fiber) Outdoor unit accessories Indoor/outdoor unit Indoor/Outdoor unit power Rubber leg Main power cable communication cable cable Installation accessories...
Page 42: Drilling A Hole And Fixing The Indoor Unit
Drilling a hole and fixing the indoor unit f Drill a hole with diameter of 60~65 mm towards the outside. f If the indoor unit is installed on unstable ground, it may be shaken by an external force or children, and eventually get knocked down.
Page 43 Connecting pipes 2. Bend the connection pipe to an appropriate length using a bender depending upon the installation place. 3. Perform pipe bending process. - Perform bending of the pipe using the pipe bender which has a specified bending radius. - Be sure to take full care to perform bending of the pipe successfully at one time.
Page 44 f Tightening of connection parts Alight the pipes to be connected and tighten the flare nuts with your hands first and then with a torque wrench, tighten it in a direction shown in below illustration. - You can avoid of gas leakage by applying refrigerant oil on the flare connection part. Pipe Flare connection part Monkey...
Page 45: Connecting Drain Hose
Connecting drain hose 1. Slightly hit the hole, for drain hose, with your hands or hammer. 2. Insulate the drain hose with drain insulation tube and fix it with tape. 3. Direct the drain hose downward to establish natural draining. - Make sure to check for proper drainage after connection • Fix the drain hose tightly to prevent any water leakage.
Page 46: Electrical Work
Electrical work • The electrical work should be performed by a specialist qualified for the work. • Avoid using multi-concent but use rate power supply for air conditioner. (Use separate power cable for outdoor CAUTION unit.) Wiring standard f Always make sure that the power supply is compliant with current safety standards. Always install the air conditioner in compliance with current local safety standards.
Page 47 Electrical work Safety information on outdoor unit power supply f Power supply cords of parts of appliances for outdoor use shall not be lighter than polychloroprene sheathed flexible cord. (Code designation IEC:60245 IEC 66 / CENELEC: H07RN-F ) - Rated voltage: 450/750V, H07RN-F (60245 IEC 66) - Use cable over 2.5 mm (Distance : 15 m or less) Type of outdoor unit power supply...
Page 48: How To Connect Your Extended Power Cables
How to connect your extended power cables f Items to prepare Tools Crimping plier Connection sleeve (mm) Insulation tape Contraction tube (mm) Spec MH-14 20 x Ø6.5(H x OD) Width 19 mm 70 x Ø8.0(L x OD) Shape 1. As shown in the figure, peel off the shields from the rubber/wire of the power (Unit: mm) Power cable(provided by us) cable.
Page 49 Electrical work 4. Wrap it with the insulation tape twice and position your contraction tube in the middle of the insulation tape. f Method 1 f Method 2 Insulation tape Insulation tape 40 mm 35 mm 5. Apply heat to the contraction tube to contract it. Contraction tube 6.
Page 50: Vacuum Pump
Vacuum pump Vacuuming pipe 1. Completely connect the indoor/outdoor unit pipes. 2. Connect the manifold gauge to the service valve port of the low pressure side on the outdoor unit. 3. Execute vacuum pump for over 30 minutes. - If the pipe extension is larger, time of the vacuum pump should also get longer. 4.
Page 51: Performing Leak Test
Performing leak test f Use leak tester or soapsuds on the pipe connection part after performing vacuum pump. Check for leakage Check for leakage Test part for outdoor unit Test part for indoor unit f Before inspecting the leakage, use a torque wrench to close the cap for the service valve.(Comply with a tightening torque for each size of the diameter, and tighten the cap firmly to prevent any leakage.) f To check for any possible leakage, insert inert gas into the pipes connected to indoor/outdoor units and check the connection part of the indoor/outdoor units with soap lather or liquid for leakage test.
Page 52: Installing The Earth Wire
Installing the earth wire Earthing must be done by the installation specialist for your safety. f Connect grounding electrode and the air conditioner. Charging refrigerant 1. Connect the manifold gauge in the low pressure side (gas) and press Set/Cancel, Mode, Temp + button simultaneously for 5 seconds to enter the refrigerant charging mode.
Page 53: Check And Test Operation
Check and test operation 1. Supply power to the air conditioner. 2. Turn on the air conditioner. 3. While pressing and holding the Set/Cancel button on the remote controller, press the Power button for 3 seconds to display the temperature of indoor heat exchanger. - Write down the displayed temperature.
Page 54 MEMO S-east_MEMORY_IBIM_EN_03955A-02_EN.indd 53 2014-10-28 오후 12:01:04...
Page 55 MEMO S-east_MEMORY_IBIM_EN_03955A-02_EN.indd 54 2014-10-28 오후 12:01:04...
Page 56 MEMO S-east_MEMORY_IBIM_EN_03955A-02_EN.indd 55 2014-10-28 오후 12:01:04...
