- Page 1 054-8258-2 Jigsaw INSTRUCTION IMPORTANT: Read and understand this instruction manual thoroughly before MANUAL using the product.
-
Page 2: Table Of Contents
headline bars TAbLe Of CONTeNTS Technical Specifications Safety Guidelines 5–8 Key Parts Diagram Important Information 10–11 continuation tabs Assembly Instructions 12–13 Operating Instructions 14–16 Maintenance Troubleshooting notes Part list 19–20 Warranty 21–22 warnings NOTe: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928 SAVe THeSe INSTRUCTIONS • This manual contains important safety and operating... -
Page 3: Technical Specifications
054-8258-2 | contact us 1.800.689.9928 RULeS fOR SAfe OPeRATION TeCHNICAL SPeCIfICATIONS WARNING! Rated power input Rated voltage 120V~, 60Hz Safety symbols in this Instruction Manual are used to flag possible dangers. The safety symbols and their explanations require your full understanding. The safety warnings do not, by themselves, No load speed 800–3000 SPM... - Page 4 054-8258-2 | contact us 1.800.689.9928 eLeCTRICAL SAfeTy • Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety • Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter measures reduce the risk of starting the power tool accidentally. plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of • Store idle power tools out of the reach of children and do not allow persons unfamiliar with the...
- Page 5 054-8258-2 | contact us 1.800.689.9928 SAfeTy gUIdeLINeS fOR jIgSAw PACKAge CONTeNTS: • Hold the power tool by the insulated gripping surfaces when performing an operation where the Jigsaw, edge guide, hex key (installed on the tool), wood cutting blade and instruction manual. cutting accessory may contact hidden wiring or its own cord. If a cutting accessory contacts a “live”...
-
Page 6: Important Information
054-8258-2 | contact us 1.800.689.9928 IMPORTANT INfORMATION THe fOLLOwINg CHART CAN HeLP yOU PICK THe PROPeR SPeed ANd bLAde Before attempting to use this tool, become familiar with all of its operating features and safety requirements. -
Page 7: Assembly Instructions
054-8258-2 | contact us 1.800.689.9928 ASSeMbLy INSTRUCTIONS ATTACHINg THe edge gUIde (fig 5) fig 3 fig 5 1. Loosen the two edge guide locking knobs. INSTALLINg THe SAw bLAde (fig 3) 2. Insert the bar of the edge guide through the slots 1. -
Page 8: Operating Instructions
054-8258-2 | contact us 1.800.689.9928 OPeRATINg INSTRUCTIONS geNeRAL CUTTINg 1. Make sure that the workpiece is firmly clamped to prevent the workpiece from moving while cutting. TURNINg ON ANd Off (fig 7) fig 7 2. -
Page 9: Maintenance
054-8258-2 | contact us 1.800.689.9928 PLUNge CUTTINg (fig 9) MAINTeNANCe fig 9 Plunge cutting is useful and time-saving for making befORe eACH USe rough openings in soft materials. It makes it unnecessary to drill a hole for an inside or pocket cut. -
Page 10: Troubleshooting
054-8258-2 | contact us 1.800.689.9928 TROUbLeSHOOTINg exPLOded VIew Problem Possible Causes Solution The motor does not start The tool is not connected to a Connect the tool to a power power source source Blade cannot be removed... - Page 11 3704216000 Pendulum Plate 3700164000 Square Nut 3704217000 Counterweight 4870475000 Trigger Switch This Mastercraft product is guaranteed for a period of 3 years from the date of original retail purchase 5700184000 Needle Bearing 3126146000 Lock Button against defects in workmanship and materials, except for the following components: 5650248000 Washer...
-
Page 12: Warranty
054-8258-2 | contact us 1.800.689.9928 additional Limitations This warranty applies only to the original purchaser and may not be transferred. Neither the retailer nor the manufacturer shall be liable for any other expense, loss or damage, including, without limitation, any indirect, incidental, consequential or exemplary damages arising in connection with the sale, use or inability to use this product.
