Smart Sensor
Multi-Controller
ZS-MDC (Ver 2.0)
User's Manual
Multi-Controller
Cat. No. Z209-E1-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZS-MDC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omron ZS-MDC

Summary of Contents for Omron ZS-MDC

  • Page 1 Smart Sensor Multi-Controller ZS-MDC (Ver 2.0) User's Manual Multi-Controller Cat. No. Z209-E1-01...
  • Page 2 ZS-MDC. When using the ZS-MDC, be sure to observe the following: • The ZS-MDC must be operated by personnel knowledgeable in electrical engineering. • To ensure correct use, please read this manual thoroughly to deepen your understanding of the product.
  • Page 3 APPLICATION CONSIDERATIONS (Please Read) INTRODUCTION FEATURES SECTION 1 INSTALLATION & CONNECTION SECTION 2 SETUP SECTION 3 APPLICATION SETTING EXAMPLES SECTION 4 APPENDIX SECTION 5 Section User's Manual Smart Sensors Multi-Controller ZS-MDC...

  • Page 4: Warranty

    PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. In no event shall responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted. IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS REGARDING THE PRODUCTS UNLESS OMRON’S ANALYSIS CONFIRMS THAT THE PRODUCTS...

  • Page 5: Performance Data

    Performance data given in this document is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of OMRON’s test conditions, and the users must correlate it to actual application requirements. Actual performance is subject to the OMRON Warranty and Limitations of Liability.
  • Page 6 The information in this document has been carefully checked and is believed to be accurate; however, no responsibility is assumed for clerical, typographical, or proofreading errors, or omissions. PROGRAMMABLE PRODUCTS OMRON shall not be responsible for the user’s programming of a programmable product, or any consequence thereof. COPYRIGHT AND COPY PERMISSION This document shall not be copied for sales or promotions without permission.

  • Page 7: Precautions For Safe Use

    (3) Others • Do not attempt to dismantle, repair, or modify the product. • Dispose of this product as industrial waste. Introduction Precautions for Safe Use ZS-MDC User’s Manual...

  • Page 8: Precautions For Correct Use

    • Before connecting/disconnecting the Peripheral device, make sure that the Multi-Con- troller is turned OFF. The Multi-Controller may break down if the Peripheral device is connected or disconnected while the power is ON. • Use only combinations with Sensor Controllers specified in this manual. ZS-MDC User’s Manual...
  • Page 9 The circuits are still unstable immediately after the power supply is turned ON, so measured values may fluctuate gradually. (5) Maintenance and Inspection Do not use thinner, benzene, acetone or kerosene to clean the Multi-Controller. Precautions for Correct Use Wrong Introduction ZS-MDC User’s Manual...

  • Page 10: Editor's Note

    Inputs do not undergo logical operation when “None” is set. Example: The operation “-B” is per- formed when “None” is set to input A, “3CH” is assigned to input B and A-B is selected. Supplementary Explanation Helpful information regarding operation and reference pages are introduced here using symbols. ZS-MDC User’s Manual Section 3 Description Description...
  • Page 11 [aa]. ■ Visual Aids Indicates points that are important to ensure full product performance, such as operational precautions and application procedures. Indicates pages where related information can be found. Indicates information helpful in operation. Introduction Editor's Note ZS-MDC User’s Manual...
  • Page 12 Introduction Editor's Note MEMO ZS-MDC User’s Manual...

  • Page 13: Table Of Contents

    Setting Assignments Setting Logic Operation Methods Setting I/O Assignments Switching banks by external signal input Changing Output Assignments Changing Linear Output Assignments About Digital Output Introduction Contents 2-10 3-13 3-14 3-14 3-15 3-16 3-16 3-17 3-17 3-17 ZS-MDC User’s Manual...

  • Page 14: Contents

    Error Messages and Countermeasures Q&A Glossary Specifications and External Dimensions Multi-Controller Panel Mount Adapters RS-232C Cable for Connecting to a Personal Computer Controller Link Unit Version Up Information Index Revision History ZS-MDC User’s Manual 4-10 4-12 4-14 4-17 5-10 5-11 5-12 5-13 5-16...

  • Page 15: Section 1 Features

    Section 1 FEATURES Multi-Controller Features Multi-Controller Applications Basic Configuration Part Names and Functions ZS-MDC User’s Manual...

  • Page 16: Multi-Controller Features

    List of Setup Items p.3-9 (3) Completely Digitally Based Logic Operation Processing Logic operations are batch-executed digitally on controller information. Even in multi- point measurement applications, corruption-free measurement results can be output. ZS-MDC User’s Manual Sensor Controllers...
  • Page 17 (Sold separately). This software also supports the display and setup of data such as monitoring of waveforms and designation of area that is not possible on the Sensor Controller alone. Section 1 Multi-Controller Features ZS-MDC User’s Manual...

  • Page 18: Multi-Controller Applications

    Logic operations can be performed on measured values obtained from multiple Sensor Controllers to measure steps in stepped workpieces. ● Measurement of Average Workpiece Height Logic operations can be performed on measured values obtained from multiple Sensor Controllers to measure the average height of workpieces. ZS-MDC User’s Manual...
  • Page 19 Communications commands can be used to batch-acquire the measurement results of gang-mounted Sensor Controllers. About Digital Output p.3-17 You can also use the optional software “SmartMonitor Zero” to batch-display on the digital displays and batch-log measurement results. SmartMonitor Zero (sold separately) Section 1 Multi-Controller Applications ZS-MDC User’s Manual...
  • Page 20 The state of gang-mounted Sensor Controllers can be monitored. The operating state of each Sensor Controller can be batch-monitored. The waveforms of each Sensor Controller can be displayed simultaneously. ZS-MDC User’s Manual * The screen shown here may differ from the actual screen.

  • Page 21: Basic Configuration

    For details, refer to the User's Manual for the Sensor Controller. ZS-XCN This unit is for gang-mounting controllers. S82K-01524 (DC24V, 0.6 A) S82K-05024 (DC24V, 2.1 A) Prepare the required number of (1) and (2) power supplies above. Section 1 Basic Configuration p.2-5 ZS-MDC User’s Manual...

  • Page 22: Part Names And Functions

    The Main Display shows measured values after operations have been performed. (5) Sub-display The sub-display shows thresholds and additional information during measurement. (6) LCD screen RUN mode TEACH mode FUN mode ZS-MDC User’s Manual (1) Laser indicator (2) Zero Reset indicator (3) ENABLE indicator (4) Main display (5) Sub-display...

  • Page 23: Control Keys

    The I/O cable connects the Sensor Controller to the power supply and external devices, such as timing sensors or programmable controllers. (17) USB port Connect the USB cable to the USB port to connect to a personal computer. Section 1 Part Names and Functions ZS-MDC User’s Manual...
  • Page 24 Section 1 Part Names and Functions MEMO ZS-MDC 1-10 User’s Manual...

  • Page 25: Section 2 Installation & Connection

    Section 2 INSTALLATION & CONNECTION About Installation and Connection Multi-Controller Attaching the ferrite core Installing the Multi-Controller About the I/O cable 2-10 ZS-MDC User’s Manual...

  • Page 26: About Installation And Connection

    Before installing and connecting the Multi-Controller, be sure to turn it OFF. Also read “Precautions for Safe Use” and “Precautions for Correct Use” at the begin- ning of this manual, and check the power supply and wiring. ZS-MDC User’s Manual...

  • Page 27: Multi-Controller

    The Multi-Controller may break down if the Multi-Controller is connected or disconnected while the power is ON. Attaching the ferrite core Attach the ferrite core (provided with the Multi-Controller) to the I/O cable of the Multi- Controller. Multi-Controller Ferrite core Section 2 ZS-MDC User’s Manual...

  • Page 28: Installing The Multi-Controller

    When performing operation from SmartMonitor Zero or an external device, select the controller to be set up by its channel No. The following shows how channel Nos. are assigned when Sensor Controllers are gang-mounted. Multi-Controller Sensor Controller ZS-MDC User’s Manual Sensor Controller Sensor Controller Sensor Controller...
  • Page 29 DIN track first may impair the mounting strength of the DIN track attachment. Section 2 Multi-Controller DIN track (sold sepa- rately) PFP-100N (1 m) PFP-50N (0.5 m) PFP-100N2 (1 m) End plate (sold separately) PFP-M Hook on connector Hook on I/O cable ZS-MDC User’s Manual...
  • Page 30 Controller Link Unit. Slide the Controller Link Unit and remove from the connector on the Multi- Controller. Install the cover on the coupler of the controller. ZS-MDC User’s Manual Controller Link Unit (sold separately) Indented...
  • Page 31 Pull the hook on the I/O cable end downwards. Lift up the Sensor Controller from the I/O cable end, and remove it from the DIN track. Section 2 Multi-Controller Hook on I/O cable ZS-MDC User’s Manual...
  • Page 32 Controller from the rear of the panel towards the front. Install the small Mount Adapters on the four holes on the Multi-Controller and Sensor Controller. Install the small Mount Adapters on all gang- mounted Controllers. ZS-MDC User’s Manual Multi-Controllers Sensor Panel Panel Mount Adapter...
  • Page 33 Attach two mounting fixtures each on all gang- mounted Multi-Controllers Controllers. Make sure that the Multi-Controller and Sensor Controllers are firmly fixed on the panel. Panel Mount Adapter Panel Mount Adapter Sensor Section 2 Multi-Controller Panel Mounting fixture ZS-MDC User’s Manual...

  • Page 34: About The I/O Cable

    (3) OUT0 (HIGH output) This outputs judgment results (HIGH). (4) OUT1 (PASS output) This outputs judgment results (PASS). (5) OUT2 (LOW output) This outputs judgment results (LOW). ZS-MDC 2-10 User’s Manual Brown (1) Power supply Blue (2) GND...

  • Page 35: Linear Output

    This is used to execute and clear a zero reset. This is used for switching banks. Specify the bank No. in combinations of A and B. Section 2 About the I/O cable ZS-MDC 2-11 User’s Manual...
  • Page 36 Section 2 About the I/O cable ■ I/O Circuit Diagrams ● NPN type (ZS-MDC11) Current voltage/ output selector switch 40 Ω ZS-MDC 2-12 User’s Manual Brown DC24V Load OUT0 Green OUT1 Black OUT2 Pink OUT3 Gray OUT4 Blue GND(0V) Yellow...
  • Page 37 OUT3 Load Gray OUT4 Load Load Blue GND(0V) Yellow Light blue Purple White Orange Co-axial (black) Linear output Current output: 300 Ω or less Load Voltage output: 10 kΩ or more Shielded Linear GND Section 2 ZS-MDC 2-13 User’s Manual...
  • Page 38 Section 2 About the I/O cable MEMO ZS-MDC 2-14 User’s Manual...

  • Page 39: Section 3 Setup

    Setting the Sensor Controller to Obtain Sensing Information from 3-14 Setting Assignments Setting Logic Operation Methods Setting I/O Assignments Switching banks by external signal input Changing Output Assignments Changing Linear Output Assignments About Digital Output 3-13 3-14 3-15 3-16 3-16 3-17 3-17 3-17 ZS-MDC User’s Manual...

  • Page 40: Setting Flow

    External I/O Set how measured values are to be output. Save Setup Data Save the data you have set. Sensor Controller User's Manual, Section 3 Setup ZS-MDC User’s Manual Section 2 p.2-2 Installation & Connection p.3-14 Sensor Controller User's Manual, Section 3 Setup p.3-16...
  • Page 41 Setting Flow An error message has appeared When [Error] is Displayed on the p.5-3 Main Display Sensor Controller User's Manual, Section 3 Setup Sensor Controller User's Manual, Section 3 Setup Sensor Controller User's Manual, Section 3 Setup User’s Manual ZS-MDC...

  • Page 42: About Setup

    Section 3 About Setup About Setup The ZS-MDC Series can be set up on the Multi-Controller or on the SmartMonitor Zero software utility. This manual describes setup on the Multi-Controller. For details on how to set up the ZS-L Series on SmartMonitor Zero, refer to Help contained on the SmartMonitor Zero CD-ROM.
  • Page 43 FUN Mode Directly sets the No. preceding the items displayed on the LCD screen. The function changes depending on the settings. • Scrolls pages in list menus. • Selects the digit of numerical values. Section 3 About Setup ZS-MDC User’s Manual...
  • Page 44 The “Complete!” message is displayed. Press the MENU key to return to the top menu. Pressing the ESC key returns to the previous menu. ZS-MDC User’s Manual FUN Mode Changes numerical values during numerical value input. Displays the top menu of the FUN mode.
  • Page 45 HELP Description Measured Value Display Not used Changes sub-display content. Section 3 About Setup Display Customize Menu Directly select functions. The function changes depend- ing on the settings. • Scrolls pages in list menus. • Selects digits. ZS-MDC User’s Manual...
  • Page 46 ← LEFT key → RIGHT key ↑ UP key ↓ DOWN key MENU key SET key ESC key ZS-MDC User’s Manual Measured Value Display ↑ UP key: Executes trigger input. ↓ DOWN key: Executes reset input. Displays the display customize menu.

  • Page 47: List Of Setting Items

    SCALING OFF, ON (AUTO, MAN) TYPE OFF, PEAK, BOTTOM, P-P, AVERAGE, SAMPLE TRIGGER EXT, SELF-UP, SELF-DN DELAY OFF, ON (T-DELAY, T-TIME) TYPE REAL REAL, HOLD OFFSET -999.99 to 999.999 Section 3 About Setup Option/Range Pages p.3-14 p.3-15 ZS-MDC User’s Manual...
  • Page 48 Section 3 About Setup I/O SET JUDGE ANALOG INPUT I/O SET BANK SYSTEM (RS-232C) ZS-MDC 3-10 User’s Manual Settings Default Value NO-MEAS CLAMP 20 µm TIMER FOCUS ADJUST TASK TASK1 ANALOG TASK1 DIGITAL CHANGE BANK1 CLEAR SAVE INIT CYCLE INFO...
  • Page 49 TRIGGER EXT, SELF-UP, SELF-DN DELAY OFF, ON (T-DELAY, T-TIME) TYPE REAL REAL, HOLD OFFSET -999.99 to 999.999 (same as when TASK1 is selected) (same as when TASK1 is selected) Section 3 About Setup Page Option/Range p.3-15 ZS-MDC 3-11 User’s Manual...

  • Page 50: Run Mode

    To call the display customize menu, press the MENU key in the RUN mode. RUN mode DIGITAL ■ TEACH Mode This is the mode for setting the threshold values TEACH Mode ZS-MDC 3-12 User’s Manual Settings Default Value 0 to 5...

  • Page 51: Selecting Tasks

    TASK1 is selected, only items specific to that task can be set.Items common to all tasks are as fol- lows: • SEL CH • NO-MEAS • JUDGE • ANALOG • IN • I/O SET BANK and SYSTEM can also be changed whichever task is selected. Section 3 Selecting Tasks Description ZS-MDC User’s Manual 3-13...

  • Page 52: Setting The Sensor Controller To Obtain Sensing Information From

    INPUT E (input E) INPUT F (input F) INPUT G (input G) INPUT H (input H) INPUT I (input I) ZS-MDC 3-14 User’s Manual Description Assigns the target Sensor Controller to input A. Range: None, 1CH onwards (largest CH of gang-mounted Sensor Controllers) (default: 1CH.

  • Page 53: Setting Logic Operation Methods

    During thickness input, the mode changes to the measurement mode, and the current thickness value is displayed on the main dis- play. For this reason, during thickness input enter in a measurement ready state. Section 3 ZS-MDC 3-15 User’s Manual...

  • Page 54: Setting I/O Assignments Switching Banks By External Signal Input

    BANK4 • Bank switching is begun 0.5 seconds after the input state changes. • At most it takes about 10 seconds to switch banks. • During bank switching the BUSY output becomes ON. ZS-MDC 3-16 User’s Manual Description Select to task for enabling the external signal lead. Note, however, that reset input and bank inputs affects tasks at all times.

  • Page 55: Changing Output Assignments

    For details on commands, refer to the “Communication Command Reference” (provided separately). When multi-channel waveforms are plotted or logging is performed on SmartMon- itor Zero, the details set on SmartMonitor Zero are automatically reflected in this setting. Section 3 Setting I/O Assignments Description Description Description ZS-MDC User’s Manual 3-17...
  • Page 56 Section 3 Setting I/O Assignments MEMO ZS-MDC 3-18 User’s Manual...

  • Page 57: Section 4 Application Setting Examples

    Measuring the Thickness of Multiple Points (sandwiched thickness)4-2 Measuring the Relative Difference between Steps Measuring the Reference Difference between Steps Measuring Flatness Measuring the Average Height Measuring the Twist of a Workpiece Measuring the Warp of a Workpiece 4-10 4-12 4-14 4-17 ZS-MDC User’s Manual...

  • Page 58: Measuring The Thickness Of Multiple Points (Sandwiched Thickness)

    A to F to be used for the expression. INPUT A:1CH INPUT B:2CH INPUT C:3CH INPUT D:4CH INPUT E:5CH INPUT F:6CH ZS-MDC User’s Manual Input C Input E Thickness Input A Input B Input C Input D Input E Input F Input D...
  • Page 59 TASK3 TASK4 INPUT X INPUT Y THICK Input A Input B THICK 0 1 0 . 0 0 0 SETOK THICK 0 1 0 . 0 0 0 Complete! Input C Input E Input D Input F ZS-MDC User’s Manual...
  • Page 60 • To linear-output the operation result [I/O SET]-[I/O SET]-[ANALOG] Select [TASK4] so that the thickness differ- ence can be linear-output. The calculation results of each CH can be batch-acquired if you use the communication command. ZS-MDC User’s Manual TASK1 TASK2 TASK3...

  • Page 61: Measuring The Relative Difference Between Steps

    Input B Input C Step difference Input A Input B Input C The operation and/or measurement results are output as judgement output or linear output. Section 4 INPUT A INPUT B INPUT C TASK1 TASK2 TASK3 TASK4 ZS-MDC User’s Manual...
  • Page 62 To output judgment on the difference between point B and point C: Set TASK2 to I/O SET To output judgment on the difference between point C and point A: Set TASK3 to I/O SET ZS-MDC User’s Manual INPUT X INPUT Y...
  • Page 63 C and point A: Set TASK3 to I/O SET The calculation results of each CH can be batch-acquired if you use the communication command. Measuring the Relative Difference between Steps TASK1 TASK3 Section 4 TASK2 TASK4 ZS-MDC User’s Manual...

  • Page 64: Measuring The Reference Difference Between Steps

    Assign the CH No. of the controller to inputs A to C to be used for the expression. INPUT A:1CH INPUT B:2CH INPUT C:3CH Press MENU key - ESC key. Select [TASK1]. ZS-MDC User’s Manual Input A Input B Input C Reference difference...
  • Page 65 The calculation results of each CH can be batch-acquired if you use the communication command. Section 4 INPUT X INPUT Y Input A Input B Input C Input A Input B Input C TASK1 TASK2 TASK3 TASK4 TASK1 TASK2 TASK3 TASK4 ZS-MDC User’s Manual...

  • Page 66: Measuring Flatness

    INPUT C: 3CH INPUT D: 4CH INPUT E : 5CH INPUT F : 6CH INPUT G: 7CH INPUT H: 8CH INPUT I : 9CH ZS-MDC 4-10 User’s Manual Input C Input I Input A Input B Input C CH0 CH1 CH2 The operation and/or measurement results are output as judgement output or linear output.
  • Page 67 The calculation results of each CH can be batch-acquired if you use the communication command. Section 4 Measuring Flatness TASK1 TASK2 TASK3 TASK4 INPUT A INPUT B INPUT C TASK1 TASK2 TASK3 TASK4 TASK1 TASK2 TASK3 TASK4 ZS-MDC User’s Manual 4-11...

  • Page 68: Measuring The Average Height

    Assign the CH No. of the controller to inputs A to C to be used for the expression. INPUT A:1CH INPUT B:2CH INPUT C:3CH Press MENU key - ESC key. Select [TASK1]. ZS-MDC 4-12 User’s Manual Input A Input B Input C Input A Input B Input C...
  • Page 69 The calculation results of each CH can be batch-acquired if you use the communication command. Section 4 Measuring the Average Height INPUT A 2INPUT B 3INPUT C TASK1 TASK2 TASK3 TASK4 TASK1 TASK2 TASK3 TASK4 ZS-MDC User’s Manual 4-13...

  • Page 70: Measuring The Twist Of A Workpiece

    FUN Mode-[SENSING]-[SEL CH] Assign the CH No. of the controller to inputs A to C to be used for the expression. INPUT A:1CH INPUT B:2CH INPUT C:3CH ZS-MDC 4-14 User’s Manual Input A Input D Input C Input A Input B Input C...
  • Page 71 Measuring the Twist of a Workpiece TASK1 TASK2 TASK3 TASK4 INPUT X INPUT Y Input A Input B Input C Input A Input B Input C Input A Input B Input C ZS-MDC User’s Manual Input D Input D Input D 4-15...
  • Page 72 • To linear-output the operation result [I/O SET]-[I/O SET]-[ANALOG] Select [TASK3] so that the twist value can be linear-output. The calculation results of each CH can be batch-acquired if you use the communication command. ZS-MDC 4-16 User’s Manual TASK1 TASK2...

  • Page 73: Measuring The Warp Of A Workpiece

    A to C to be used for the expression. INPUT A:1CH INPUT B:2CH INPUT C:3CH Measuring the Warp of a Workpiece Input B Input C Input A Input B Input C CH0 CH1 CH2 CH3 INPUT A INPUT C Section 4 INPUT B ZS-MDC 4-17 User’s Manual...
  • Page 74 INPUT X: INPUT A INPUT Y: INPUT C Following the same procedure as 2 to 3, set up TASK2. INPUT K:0 INPUT m:1 INPUT n:-0.5 INPUT X: INPUT B INPUT Y:TASK1 ZS-MDC 4-18 User’s Manual TASK1 TASK2 TASK3 TASK4 INPUT A INPUT B...
  • Page 75 Select [TASK2] so that the warp value can be linear-output. The calculation results of each CH can be batch-acquired if you use the communication command. Section 4 Measuring the Warp of a Workpiece TASK1 TASK2 TASK3 TASK4 TASK1 TASK2 TASK3 TASK4 ZS-MDC User’s Manual 4-19...
  • Page 76 Section 4 Measuring the Warp of a Workpiece MEMO ZS-MDC 4-20 User’s Manual...

  • Page 77: Section 5 Appendix

    Section 5 APPENDIX Troubleshooting Error Messages and Countermeasures Q&A Glossary Specifications and External Dimensions Version Up Information INDEX Revision History 5-12 5-13 5-16 ZS-MDC User’s Manual...

  • Page 78: Troubleshooting

    The main display remains on [-----]. The measured values fluctuate and are not stable depending on day and time. ZS-MDC User’s Manual Probable cause and possible countermeasure • Are all cables connected correctly? • Is the signal line disconnected? • Are reset inputs short-circuited? •...

  • Page 79: Error Messages And Countermeasures

    • The sensor is standing by • When hold is set, start sam- for measurement. pling and apply the hold • No channels are assigned value. to inputs. (Assignments • Assign the channels. are set to “NONE”.) Section 5 Countermeasure Countermeasure Countermeasure ZS-MDC User’s Manual...

  • Page 80: Q&A

    When scaling is executed, an error appears and settings cannot be made. When focusing is executed, an error appears and settings cannot be made. ZS-MDC User’s Manual Answer Scaling cannot be set for one of the following reasons: • Scaling has been attempted when the measured value is outside the measuring range.

  • Page 81: Glossary

    SmartMonitor Zero This is software that runs on a personal computer. This software enables communication with ZS-MDC, sets the measurement conditions of the Multi-Controller and gang-mounted Sensor Controllers, saves setting data, and dis- plays measurement results as a graph.

  • Page 82: Specifications And External Dimensions

    Section 5 Specifications and External Dimensions Specifications and External Dimensions Multi-Controller ZS-MDC11/MDC41 52.50 ZS-MDC User’s Manual 10.80 13 10 (Unit: mm)
  • Page 83 10 to 150 Hz, 0.7-mm double amplitude, 80 min each in X, Y, and Z directions Section 5 ZS-MDC41 PNPtype PNPopen-collector 50 mA max. residual voltage;1.2V max. ON: Supply voltage short-cir- cuited or within supply volt- age -1.5 V OFF: Open (leakage current: 0.1 mA max.) ZS-MDC User’s Manual...
  • Page 84 Specifications and External Dimensions Item Shock resistance (destructive) Ambient temperature Ambient humidity Materials Weight ZS-MDC User’s Manual ZS-MDC11 300 m/s 3 times each in six directions (up/down, left/right, forward/ backward) Operating: 0 to 50°C Storage: -15 to +60°C (with no icing or condensation)

  • Page 85: Panel Mount Adapters

    Note 1: Dimensions are shown for a panel thickness of 2.0 mm. ZS-XPM1 (for 1st unit) ZS-XPM2 (for 2nd unit onwards) 3 times each in six directions (up/down, left/right, forward/backward) Section 5 (Unit: mm) DIN track Note 1) ZS-MDC User’s Manual...

  • Page 86: Rs-232C Cable For Connecting To A Personal Computer

    Ambient temperature Ambient humidity Dialectic strength Insulation resistance Vibration resistance Shock resistance Materials Weight ZS-MDC 5-10 User’s Manual 2000 9-pin square connector PVC insulated round cable 3.89 mm dia. core (conductor cross-section: 0.013 mm Note 1: Connector is socket type.

  • Page 87: Controller Link Unit

    10 to 150 Hz, 0.7 mm double amplitude, 80 min each in X, Y, and Z directions Shock resistance 300 m/s Materials Polycarbonate (PC), etc. Weight Approx. 10g Specifications and External Dimensions ZS-XCN 3 times each in six directions (up/down, left/right, forward/backward) Section 5 (Unit: mm) 4.60 ZS-MDC 5-11 User’s Manual...

  • Page 88: Version Up Information

    RS-232C “delimiter”, and “CompoWay/F”, “Non-procedural” and “Node” were added to the communication specifications. The Data Storage unit (ZS-DSU) was supported. SmartMonitor Zero was supported. ZS-MDC 5-12 User’s Manual Description of Change *Refer to the User’s Manual for the Sensor Controller.

  • Page 89: Index

    RUN mode SEL CH 2-10 SENSING STEP CALC 2-10 Sub-display 2-13 3-17 3-14 TASK TEACH Mode THICK CALC 3-15 Threshold Selector Switch Section 5 Index 3-17 2-10 3-17 2-10 2-10 2-10 5-10 3-14 3-14 3-15 3-13 3-15 ZS-MDC 5-13 User’s Manual...
  • Page 90 Section 5 Index port Voltage/Current switch wiring Zero reset indicator ZS-MDC 5-14 User’s Manual 2-10...
  • Page 91 Section 5 Index MEMO ZS-MDC 5-15 User’s Manual...

  • Page 92: Revision History

    A manual revision code appears as a suffix to the catalog number at the bottom of the front and back covers of this manual. Cat. No. Revision code Date October 2004 ZS-MDC 5-16 User’s Manual Z209-E1-01 Revision code Original production...

  • Page 93: Terms And Conditions Of Sale

    9. Cancellation; Etc. Orders are not subject to rescheduling or cancellation unless Buyer indemnifies Omron against all related costs or expenses. 10. Force Majeure. Omron shall not be liable for any delay or failure in delivery resulting from causes beyond its control, including earthquakes, fires, floods,...
  • Page 94 For US technical support or other inquiries: 800.556.6766 OMRON CANADA, INC. Milner Avenue Toronto, Ontario M 416.286.6465 OMRON ON-LINE Global - http://www.omron.com USA - http://www.omron.com/oei Canada - http://www.omron.ca Z209-E1-01 11/05 ©2005 OMRON ELECTRONICS LLC Printed in the U.S.A. Specifications subject to change without notice.
