Overview

MAP OVERLAYS

The VFR, IFR, Terrain, Topography, or Weather map overlays can be displayed or
removed.
Displaying/removing map overlays:
1) From the Main Menu, touch Map > Menu.
2) Touch VFR, IFR, Terrain, Topo Shading, Weather, or Animate
Weather to display or remove the map overlay.

MAP SYMBOLS

Refer to Appendix H for a list of map symbols.

MAP DETAIL

The map can be adjusted to declutter (remove unwanted items, such as highways)
on the map.
Adjusting the declutter level of the navigation map:
1) From the Main Menu, touch Map > Menu.
2) Touch the desired Map Detail level (-1, -2, -3) on the right side of the
screen. The currently selected level is highlighted green.
22
Map Detail
