Hazard Avoidance
If the number of Traffic Advisories on the TIS-A display decreases and then
increases, a new audio alert is sounded. The TIS-A audio alert is also generated
whenever TIS-A service becomes available. The following TIS-A audio alerts are avail-
able:
• "Traffic"—TIS-A traffic alert received.
• "Traffic Not Available"—TIS-A service is not available or out of range.
Adjusting TIS-A audio:
1) From the Main Menu, touch Tools > Setup > Sound.
2) Touch the 'TIS Audio' Enable Button to toggle the TIS Audio on/off.
TRAFFIC WARNING WINDOW
When a traffic threat is imminent, the Traffic Warning Window is shown. The Traffic
Warning Window shows a small pop-up map in the lower left corner. The Range Rings
on the pop-up alert are spaced every whole mile/kilometer/nautical mile. Touch the
Traffic Warning Window to acknowledge and remove it.
NOTE: The Traffic Warning Window is disabled when the aircraft ground speed
is less than 30 knots or when on the approach leg of a route.

TRAFFIC GROUND TRACK

Traffic ground track is indicated on the aera screen by a "target track vector,"a short
line shown in 45-degree increments, extending in the direction of target movement.

DISPLAYING TRAFFIC DATA

TIS-A traffic can be displayed on the Navigation Map.
Adjusting TIS-A settings on the navigation map:
1) From the Main Menu, touch Map > Menu > Set Up Map.
2) Touch the Dedicated Page Icon and touch the Map group.
3) Touch the Traffic button and touch the desired setting (Off, Auto, or
range settings).
