Operating Your Air Conditioner Controb
OFF
LO
SELECTOR
Selector Switih
OFF
turns air conditioner off.
LO FAN
provides low fan speed
operation without cooling.
FAN
HI provides high fan speed
operation without cooling.
LO COOL provides cooling with
low fan speed operation.
HI COOL
provides cooling with
high fan speed operation.
cOOLER>
45
3
2
18
THERMOSTAT

Thermostat Control

When you turn the Thermostat
Control to the desired setting, the
thermostat will automatically-control
the temperature of the indoor air.
The higher the number selected,
the co;ler the indoor air will be.
AIR IN
6
7

Ventilation Control

When the AIR IN and AIR OUT
buttons are in the out position, the
vent door is closed and only the air
inside the room can be circulated
and conditioned.
Push the AIR IN button and it will
stay in, and the vent door will open
to allow a small amount of outdoor
air to enter the room. Push the AIR
IN button again and it will return to
the out position and the vent door
will close.
Push the AIR OUT button and it
will stay in, and the vent door will
open to allow air, smoke and odors
to be exhausted from the room.
Push the AIR OUT button again
and it will return to the out position
and the vent door will close.
AIR OUT
