SELECTOR

Selector Switch

OFF turns air conditioner off.
operation without cooling.
speed operation without cooling.
speed operation without cooling.
*For fan only operation,
Energy Saver Switch must be in
LOW COOL permits cooling with
low fan speed operation.
medium fan speed operation.
HIGH COOL permits cooling
with high fan speed operation.
10
THERMOSTAT

Thermostat Control

When you turn the Thermostat
Control to the desired setting, the
thermostat will automatically-control
the temperature of the indoor air.
The higher the number selected,
the cooler the indoor air will be.
Saver Swikh
NORM
ENERGY
SAVER
SAVE D
The Energy Saver Switch controls
the fan operation. When it's in the
NORM position, the fan will
circulate room air continuously.
When it's in the SAVE position, the
fan will automatically cycle on and
off with the compressor.
4
HOUR
TIMER

Timer Control

(on
models so equipped)
When
.
to the MANUAL setting. the air
conditioner starts immediately and
operates continuously if the
Selector Switch is at any setting
other than OFF.
When used with the Delay
Start/Stop Switch, the Timer
Control turns the air conditioner
on or off at preset times.
To delay the stirt of the air
conditioner anywhere from
1 to ~ hours:
1. Set the Timer Control for the
number of hours you want to delay
the start of the air conditioning
operation.
2. Set the Delay
DELAY
Start/Stop Switch
START
at DELAY START.
TIMER
3. Turn the
Selector Switch to
DELAY
the desired setting.
STOP
To stop the air conditioning
operation from 1 to ~ hours later:
1. Set the Timer Control for the
number of hours you want the air
conditioner to operate before
shutting off automatically.
2. Set the Delay Stirt/Stop Switch
at DELAY S~P.
3. Turn the Selector Switch to the
desired setting.
