- Page 1 User’ s Guide Shop online at omega.com e-mail: info@omega.com For latest product manuals: omegamanual.info FTB600B Series Ultra-Low Flow Sensors...
- Page 2 It is the policy of OMEGA Engineering, Inc. to comply with all worldwide safety and EMC/EMI regulations that apply. OMEGA is constantly pursuing certification of its products to the European New Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification.
-
Page 3: Table Of Contents
B. Frequency Output ... 7 C. Frequency Ranges ... 8 D. Cable Requirements ... 8 Section 5 Installation ... 10 Section 6 Specifications ... 14 Section 7 Pressure Drop Curves ... 15 FTB600B Series Ultra-Low Flow Sensors TABLE OF CONTENTS Page... - Page 4 FTB600B Series Ultra-Low Flow Sensors NOTES:...
-
Page 5: Section 1 - Introduction
This unique patented design makes the FTB600B Series a very accurate, repeatable, linear device. Not only is the FTB600B Series precise, but it is also a rugged, trouble- free flow meter, which can be used in a wide variety of industries including: medical, pharmaceutical, chemical processing, pulp &... -
Page 6: Material Characteristics Of Pvdf
(Polyvinylidene Fluoride) 1. Material of construction Trade name - Kynar All wetted parts of the FTB600B Series are PVDF, excluding the O-ring. Wetted parts include any part of the meter that will or could come in contact with the fluid. -
Page 7: Operation Parameters
180°F not be exceeded. Exceeding 180°F can cause irreparable damage to the circuit boards. B. Flow Ranges The FTB600B Series is available in six different sizes, which cover a flow range from 0.1 to 120 lpm. Specific flow ranges FTB601B 0.1 to 2 lpm... -
Page 8: Section 2 Operation Parameters
FTB600B Series Operation Parameters... -
Page 9: Recommended Viscosity
C. Recommended Viscosity Range 1-5 cSt (w/o correction) The effects of changing viscosity on the FTB600B Series are the same as any other turbine flow meter. It is important to remember that a turbine meter is a viscosity dependent device, where as the viscosity increases the linearity of the flow meter will decrease. -
Page 10: Silicone Treatment
FTB600B Series Silicone Treatment Section 3 - Silicone Treatment Silicone treatment is standard for all types of the FTB600B Series series electronics. -
Page 11: Section 4 - Infrared Sensor
8. Output signal cycle 66.7% (i.e. at 100 Hz there is a 6 millisecond “on” time and a 4 millisecond “off” time) 9. TTL/CMOS circuit compatibility. The FTB600B Series has an operational amplifier output, which has a high input impedance and a low output impedance. -
Page 12: Frequency Ranges
FTB600B Series Infrared Sensors C. Frequency Ranges for (non-cartridge models) Model Frequency (Hz) FTB601B FTB602B FTB603B FTB604B FTB605B FTB606B D. Cable Requirements 1. 20 to 22 AWG (American Wire Gauge) 2. 4 conductor-shielded cable. Avoid influences of strong electromagnetic forces as they can damage components on the PC boards. - Page 13 FTB600B Series Infrared Sensors Figure 4-1. Output Frequency Waveforms...
-
Page 14: Installation
FTB600B Series. The fluid must also meet filtration requirements as listed in 3D. B. Install the FTB600B series in the fluid line with the arrow pointing in the direction of the flow. C. While installing the FTB600B Series in the fluid line be careful not to over-torque the end caps (on hose-barbed flowmeters) or other fittings on the flowmeter. - Page 15 FTB600B Series Installation Figure 5-1. Supply Voltage and Signal Output Connections...
- Page 16 FTB600B Series Installation Table 5-1. Piping Table...
- Page 17 FTB600B Series Installation Table 5-1. Piping Table Con't.
-
Page 18: Specifications
FTB600B Series Specifications Section 6 - Specifications Accuracy: Repeatability: Linearity: Viscosity Range: Working Pressure: Wetted Materials: Power Supply: Output Signal: Pressure Drop: ±3% of reading ±0.1% of reading ±1% of reading 1 to 15 centistokes 150 PSIG at 175°F PVDF... -
Page 19: Pressure Drop Curves
Section 7 - Pressure Drop Curves Pressure Drop FTB600B Series Liquid Turbine - Flowmeter FTB601 FTB600B Series Pressure Drop Curves Liters/minute... - Page 20 FTB600B Series Pressure Drop Curves Pressure Drop FTB600B Series Liquid Turbine - Flowmeter FTB602 Liters/minute 10.0...
- Page 21 Pressure Drop FTB600B Series Liquid Turbine - Flowmeter FTB603 Pressure Drop Curves Liters/minute FTB600B Series...
- Page 22 FTB600B Series Pressure Drop Curves Pressure Drop FTB600B Series Liquid Turbine - Flowmeter FTB604 Liters/minute...
- Page 23 Pressure Drop FTB600B Series Liquid Turbine - Flowmeter FTB605A Pressure Drop Curves Liters/minute FTB600B Series...
- Page 24 FTB600B Series Pressure Drop Curves Pressure Drop FTB600B Series Liquid Turbine - Flowmeter FTB606A Liters/minute...
- Page 25 © Copyright 2005 OMEGA ENGINEERING, INC. All rights reserved. This document may not be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form, in whole or in part, without the prior written consent of OMEGA ENGINEERING, INC.
- Page 26 Where Do I Find Everything I Need for Process Measurement and Control? OMEGA…Of Course! Shop online at omega.com TEMPERATURE Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies Wire: Thermocouple, RTD & Thermistor Calibrators & Ice Point References Recorders, Controllers & Process Monitors...
