Specifications

Specifications:
INPUT Module:
Power
Ground
Inputs x 4
MIC/LINE in
Phantom power
MIC impedance
MIC level input
LINE impedance
LINE input level
Cat5 termination
Dimensions
OUTPUT Module:
Power requirements
Outputs x 4
MIC/LINE out
MIC out impedance
MIC level output
LINE out impedance
LINE level output
Dimensions
General:
Channels
Bandwidth
Crosstalk
Signal to Noise Ratio
Cable Spec
Cable length
Cat5 terminators
Protected against short circuit on Cat5 cable to ground
Over Cat5 cable
Over Cat5 cable screen (or spare pair)
Balanced XLR female
Selectable by jumper
15v jumper selectable
600R
10mV RMS
50K
700mV RMS (1.5v RMS max)
Screw terminals
145(W) x 85(H) x 35(D)mm
24v DC @ 100mA
Balanced XLR male
Selectable by jumper
600R
20mV RMS (into 600R)
20K
700mV RMS (into 20K)
145(W) x 85(H) x 35(D)mm
Four, individually configurable
100Hz to 20KHz (-3dB)
>60dB
>60dB
Screened Cat5e cable (can use UTP but one pair required for ground
meaning only three channels would be available)
1000m maximum
Screw terminals
