Clever Little Box avid3bt Installation Manual

In-wall amplifier with bluetooth

Download this manual

Installation Guide

Before installation please take the time to read and understand the enclosed information.

What's included in the box?

1x AVID3BT Amplifier, 1x 24v DC 1.25A PSU, 1x IR Remote Control Unit and

1 x Wallmount Bracket for Remote Control.

Specifications:

Output Power

Line Inputs

Bluetooth Input

Line Output

Frequency Response

Input Sensitivity

Power Requirements

Dimensions

Weight

2 x 15W @ 4W

Stereo Phonos (L & R)

Stereo 3.5mm Jack

Screw Terminal (Rear PCB)

A2DP profile

Fixed level (Unbalanced) 1v 47kW

40Hz ~ 20KHz

(Lo) 200mv / (Hi) 1v

24v DC, 1.25A

165(W) x 100(H) x 40(D) mm

0.26kg

12/16

Need help?

Do you have a question about the avid3bt and is the answer not in the manual?

Page 1 Before installation please take the time to read and understand the enclosed information. What’s included in the box? 1x AVID3BT Amplifier, 1x 24v DC 1.25A PSU, 1x IR Remote Control Unit and 1 x Wallmount Bracket for Remote Control. Specifications:...
Page 2 Before installation please remove the Facia Trim Plate from around the front edge of the unit. This can be refitted once the installation is finished and any decorating is completed. The compact depth of the AVID3BT unit will allow installation into standard UK 2-gang EO boxes, with a minimum of 40mm depth.
Page 3 Connectors Important Information: It is important to note that if using the audio input located on the rear of the AVID3BT that the signal applied is at full line level. When using this application an appropriate screened cable is required to reduce the possibility of external signal interference.
Page 4 Using the supplied IR Remote Control will give access to further features and functions of the AVID3BT and will allow adjustments to the sound levels and tone settings. The LED display panel will show the settings as any adjustments are made as follows: • The overall volume level (0 lowest ~ 20 highest)
