TECHNICAL SPECIFICATIONS
PERFORMANCE
Recommended amplifier power
(Watts RMS)
Continuous power handling
(Watts RMS)
Peak power handling (Watts)
Sensitivity (2.83 Volts @ 1 m)
Nominal impedance (Ohms)
Frequency response (-6 dB)
DRIVE UNITS
High frequency
Low frequency
CROSSOVER
Crossover frequency
Crossover type
CONSTRUCTION
Enclosure type
Volume
Dimensions (H x W x D)
(incl. plinth* & grille)
Net weight
Finish
ECLIPSE MINI
15 - 60
30
140
86 dB
8
58 Hz – 32 kHz
28 mm (1.1") Nitro-urethane
damped layer woven polyester
dome, neodymium magnet system
100 mm (4") Multi-fibre coated
pulp paper cone
2.2 kHz
Passive low loss 2nd order
low pass, 3rd order high pass
Rear ported reflex
3.0 (0.11 cu. ft.)
litres
225.0 x 145.0 x 175.0 mm
(8.9 x 5.7 x 6.9")
2.9 kg (6.4 lbs)
Black Oak
ECLIPSE CENTRE
15 - 90
45
180
90 dB
8
67 Hz – 32 kHz
28 mm (1.1") Nitro-urethane
damped layer woven polyester
dome, neodymium magnet system
2 x 100 mm (4") Multi-fibre
coated pulp paper cone
2.4 kHz
Passive low loss 2nd order low
pass, 3rd order high pass
Rear ported reflex
5.6 (0.2 cu. ft.)
litres
157.0 x 400.0 x 160.0 mm
(6.2 x 15.8 x 6.3")
3.6 kg (7.9 lbs)
Black Oak
