  • Page 1 O W N E R ʼ S M A N U A L...

  • Page 2: Table Of Contents

    If you suspect a problem with a Tannoy product then, in the first instance, discuss it with your Tannoy dealer. If you require further assistance then we ask that you deal directly with your local Tannoy distributor. If you cannot locate your distributor please contact Customer Services, Tannoy Ltd at the address given below.

  • Page 3: Introduction

    INTRODUCTION Thank you for selecting Tannoy loudspeakers developed in the UK by our dedicated team of design engineers. They are the choice of discriminating music lovers the world over. Musical excellence is designed into our loudspeakers from the start. Careful selection of the very best components combined with strict quality control procedures in the production process ensures this level of excellence is maintained.

  • Page 4: Cable Choice

    It is strongly recommended that you store all the packaging to allow protected transportation in future. (See fig.1) FLOOR STANDING MODELS Revolution floor-standing models perform best with carpet piercing spikes fitted. These are supplied, along with lock nuts, and should be inserted into the threaded holes in the base of the cabinet. Level the speaker and then tighten the lock nuts firmly but without using undue force.

  • Page 5: Stand Mounting Models

    Positioning and fine-tuning. INSTALLATION To avoid potential damage to your loudspeaker, ensure that the amplifier is switched OFF prior to connecting or disconnecting any cables. Before switching on double check that all connections are secure and that polarity is correct. REVOLUTION MANUAL...

  • Page 6: Connection In Single Wire Mode

    Switch the amplifier on with the volume control set at its lowest setting. Select a favourite source and slowly turn up the volume to a low level. Check that bass and treble information is being reproduced from both speakers - if not, switch off the amplifier and recheck the connections. (See fig. 4) REVOLUTION MANUAL...

  • Page 7: Bi-Amping

    (See fig. 5) POSITIONING AND FINE-TUNING To get best results from your new Tannoy Revolution loudspeakers it is worthwhile spending a little time finding the optimum set-up configuration. Begin by angling the speakers towards your chosen listening position, usually this is on the centre line of the room, so that when seated you can just see the inner side panel of each speaker.

  • Page 8: Grilles

    Total design compatibility, ensuring all models share the same acoustical balance and dispersion characteristics, means that it is essential that an Revolution A/V system is built around only Revolution Dual Concentric™ models (it is not possible to mix in products with other driver types) as the acoustic integration of each has been optimised only for use as a complete system.

  • Page 9: Centre Channel Speaker

    The Revolution DC LCR centre channel can be wired in single wire, bi-wire or bi-amp modes. Please refer to figs. 3, 4 & 5 for connection guidance bearing in mind that connection should be made to the dedicated centre channel output on your A/V processor amplifier/s.

  • Page 10: Technical Specifications

    TECHNICAL SPECIFICATIONS Revolution DC4 Revolution DC4 T Revolution DC4LCR PERFORMANCE Recommended amplifier power 20 – 100 20 – 125 20 – 125 (Watts RMS) Continuous power handling (Watts Peak RMS) Peak power handling (Watts) Sensitivity (2.83 Volts @ 1m) 87dB...

  • Page 11: Set-Up Diagrams

    SET-UP DIAGRAMS Fig.1 Unpacking _011 REVOLUTION MANUAL...
  • Page 12 POSITIVE(+) TE LOW FREQUENCY LOW FREQUENCY LOW FREQUENCY LOW FREQUEN NEGATIVE(-) TERMINAL POSITIVE(+) TERMINAL TIVE(-) TERMINAL POSITIVE(+) TE Fig.3 Single Wire Mode TO RIGHT TO RIGHT SPEAKER SPEAKER POWER AMPLIFIER POWER AMPLIFIER LINKS IN PLACE LINKS IN PLACE 012_ REVOLUTION MANUAL...
  • Page 13 LINKS REMOVED Fig.5 Bi-Amp Mode TO RIGHT TO RIGHT SPEAKER SPEAKER HIGH FREQUENCY HIGH FREQUENCY POWER AMPLIFIER POWER AMPLIFIER LOW FREQUENCY LOW FREQUENCY POWER AMPLIFIER POWER AMPLIFIER LINKS REMOVED LINKS REMOVED TO RIGHT TO RIGHT SPEAKER SPEAKER _013 REVOLUTION MANUAL...
  • Page 14 Fig.6 Recommended Positioning - Stereo Pair 0.5 Metres or more 0.5 METRES OR MORE 1.5 TO 4.5 METRES 1.5 to 4.5 Metres 1 METRE 1 Metre or OR MORE more Fig.7 Recommended Positioning - Home Cinema REAR Rear REAR Rear 014_ REVOLUTION MANUAL...
  • Page 15 NOTES _015 REVOLUTION MANUAL...
  • Page 16 T: 00 1 (519) 745 1158 E: inquiries@tannoyna.com Tannoy Deutschland T: 00 49 (180) 1111 881 E: anfragen@tannoy.com Tannoy France T: 00 33 (0)1 7036 7473 E: ventes@tannoy.com Tannoy adopts a policy of continuous improvement and product specification is subject to change.

This manual is also suitable for:

Revolution dc4Revolution dc4 tRevolution dc4lcr
