A
B
C
2 Rotate and lift the connector cover to disengage it
from the radio.
3 To attach the accessory connector cover, insert
the hooked end of the cover into the slot above
the connector.
4 Press downward on the cover's top to seat it in the
slot.
5 Once in place, tighten by rotating the thumbscrew
clockwise by hand.

Attaching the Belt Clip

1 Align the grooves of the belt clip with those of the
radio and push down until you hear a click.
See the following picture for MFK radio.
See the following picture for two knobs
radio.
25
English
