Fujitsu ARYG45LMLA Service Manual page 14

OUTDOOR UNIT
INDICATOR PCB
K10BC-1000YUE-D0
PUMP DOWN
SELECT
2013.01.21
D401 SLR-325 L6
<ORANGE>
D402 SLR-325 L5
<ORANGE>
D403 SLR-325 L4
<ORANGE>
D404 SLR-325 L3
<ORANGE>
D405 SLR-325 L2
<ORANGE>
D406 SLR-325 PUMP DOWN L1
<ORANGE>
D407 SLR-325 ERROR
<RED>
D408 SLR-325 POWER / MODE
<GREEN>
SW5
SW4
EXIT
SW3
ENTER
SW2
SW1
MODE
KSM8WBTS x 5
OUTDOOR UNIT
CAPACITOR PCB
K05FB-1000HUE-P0
W12
B
WHITE
C200 - C203
R200
660/
220k
450V
<2W>
x 4
W13
B
VIOLET
13
P
+ + +
+
N
POWER_G
( CN401-1 )
( CN401-2 )
( CN401-3 )
( CN401-4 )
( CN401-5 )
( CN401-6 )
( CN401-7 )
( CN401-8 )
( CN401-9 )
( CN401-10 )
( CN401-11 )
( CN401-12 )
( CN401-13 )
( CN401-14 )
( CN401-15 )
( CN401-16 )
W7
B
YELLOW
W8
B
BLUE
