3. Grounding
A ground (earth) connection must be provided and installed in accordance with state and local codes. In
the absence of these codes, grounding must conform to applicable requirements of the National Electrical
Code ANSI/NFPA NO. 70-LATEST EDITION, or in Canada, the installation must conform to applicable
Canada Standards: Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION. The
ground connection may be to a proven earth ground at the location service panel.
For added personal safety, when possible, it is suggested that a separate ground wire (sized per local codes)
be connected from the ground connection of the dryer to a grounded cold water pipe. DO NOT ground to
a gas pipe or hot water pipe. The grounded cold water pipe must have metal to metal connections ALL
the way to the electrical ground. If there are any nonmetallic interruptions, such as, a meter, pump, plastic,
rubber, or other insulating connectors, they must be jumped out with no. 4 wire and securely clamped to
bare metal at both ends.
IMPORTANT: For personal safety and proper operation, the dryer must be grounded.
4. Electrical Service Specifications (per pocket)
IMPORTANT: The dryer must be connected to the electrical supply shown on the dryer data label.
WARNING: Any damage done to dryer components due to improper voltage application or
connections will automatically VOID THE WARRANTY.
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT:
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage.
NOTES:
A.
When fuses are used they must be dual element, time delay, current limiting, class RK1 or
RK5 ONLY . Calculate/determine correct fuse value, by applying either local and/or National
Electrical Codes to listed appliance amp draw data.
B.
Circuit breakers are thermal-magnetic (industrial) motor curve type ONLY . For others,
calculate/verify correct breaker size according to appliance amp draw rating and type of
breaker used.
C.
Circuit breakers for 3-phase (3Ø) dryers must be 3-pole type.
SERVICE
PHASE
VOLTAGE
120
208
240
* AWG Stranded Wire Type – size wire as per National Electrical Code or local codes.
NOTE: Contact factory for electrical information not listed.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
GAS
WIRE
AMP DRAW
SERVICE
60 Hz
1
2
9.7
1
3
9.7
1
3
9.7
APPROX.
MINIMUM
WIRE SIZE
50 Hz
*
—
*
—
*
—
17
CIRCUIT
BREAKER
15
15
15
4/14/09
